- Page 1 BELLA 32 34 AUDIO INPUT NETWORK AUDIO MONITOR PRODUCT DETAILS 6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND. TEL: +44 (0) 1622 753662 Visit our Website at www.glensound.com FAX: +44 (0) 1622 762330...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or... - Page 4 32 Input Network Audio Monitor This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the following Union harmonisation legislation:...
- Page 5 RoHS DIRECTIVE RoHS 2 Directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for these purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%...
- Page 6 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR Page 6 of 27...
-
Page 7: Table Of Contents
BELA 32 GLENSOUND Handbook Contents Issue 1 Description Page No. Contents PRODUCT WARRANTY: ............................ 3 OVERVIEW ................................8 BELLA 32 PANEL LAYOUT ..........................9 Front Panel ............................... 9 Front Panel Features ............................9 Rear Panel ..............................13 Rear Panel Features ............................. 13 AUDIO BLOCK DIAGRAM .......................... -
Page 8: Overview
OVERVIEW Bella 32 is a multi buss summing matrix confidence monitor designed for outside broadcast trucks, studios, theatre and professional audio applications. It is perfect for easy and cost effective monitoring of multiple network audio sources, ideal for busy production environments and perfect for monitoring multiple network intercom & programme feeds. -
Page 9: Bella 32 Panel Layout
BELLA 32 PANEL LAYOUT Front Panel Level Meters/ Control Channel On/ Solo/ Position Indicator Group Select Select to adjust Switches Switch Right Panel Left Panel Cut Switch/ Loudspeaker Loudspeaker Indicator Clear Switch Audio Presence Headphone Dim Switch/ Indicator Socket Indicator Master Output &... - Page 10 3. Level Meters/ Control Position Indicator In normal use these audio level meters provide a PPM style visual indication of the left and right audio channels output levels. If however one of the channel on/ solo switches is pressed and held down, then the top meter will indicate a mono’d mix of the selected channel’s stereo output and the bottom meter is used to indicate the pan position of that channel’s output.
- Page 11 There is a 2 rear panel GPI circuit that can be used to cut just the internal loudspeakers. If this 2 GPI circuit is made (i.e. on) then the internal loudspeakers will be cut but the switches internal LED will not be on and this switch will continue to operate a cut on the analogue, AES3 and network outputs.
- Page 12 10. Headphone Socket This 6.35mm (1/4”) tip ring sleeve (TRS) jack socket provides a stereo output for monitoring the mix/ solo buss. Inserting a jack into this socket will cut the internal LS, the analogue and AES3 audio outputs and any network audio outputs affected by the cut circuit. It is suitable of use with headphones with impedances of 100 –...
-
Page 13: Rear Panel
Rear Panel AES3 Out Local Audio Mains Input Copper Ethernet Inputs Ports GPIO SFP Ethernet Analogue Update Slots socket Outputs Rear Panel Features 12. Mains Input The standard IEC mains plug is filtered and accepts external AC voltages of 100 -240 VAC +/- 10%. There is an internal fuse and maximum current consumption is 10 Watts. - Page 14 18. Update Socket The update socket is used by a Glensound authorised engineer in the unlikely event that new internal microprocessor code is required to be installed in the Bella 22. The internal microprocessor is a PIC.
-
Page 15: Audio Block Diagram
AUDIO BLOCK DIAGRAM Analogue Representation The above diagram is drawn as an analogue audio workflow, however the Bella 32 is a digital device and most functions are actually performed in the digital domain. Page 15 of 27... -
Page 16: Network Audio Outputs/ Mix Busses
NETWORK AUDIO OUTPUTS/ MIX BUSSES There is one main stereo mix buss within the Bella 22. This is referred to as ‘MIX/ SOLO’ or sometimes just ‘MIX’. In simple terms the ‘MIX/ SOLO’ outputs are derived after the front panel Channel On/ Solo buttons. - Page 17 OUTPUT FUNCTION NOTES Left Mix/ Solo Out (Not effected by DIM/ CUT) Right Mix/ Solo Out (Not effected by DIM/ CUT) Mono Mix/ Solo Out (Not effected by DIM/ CUT) Left Mix/ Solo Out Right Mix/ Solo Out Mono Mix/ Solo Out Left Mix/ Solo Out (Not effected by CUT) Right Mix/ Solo Out (Not effected by CUT) Mono Mix/ Solo Out (Not effected by...
-
Page 18: Connecting The Bella 32 To A Dante® Network
CONNECTING THE BELLA 32 TO A DANTE® NETWORK The Bella 32 is a network audio devices utilizing the reliable and versatile Dante® audio over IP protocol. Dante® is a proprietary system (although very widely used) the originators of which are Audinate. The information below is only meant as a very basic guide. -
Page 19: Running Dante Controller
The Bella 32 will have been named at the factory during test to allow them to be identified by the Dante controller. The format used for the factory name is: ‘GLENSOUND-BELLA-32-sn-XXX’ The ‘–sn-XXX’ refers to the serial number of the Bella 32 unit which can be found printed on the rear of the unit. -
Page 20: Dante Controller Tip
Note if you upload a new DNT file or clear the devices config then the name will change to Bella 32XX-xxXxXx whereby the ‘X’s refer to the devices MAC address. Dante Controller TIP If you have never run Dante controller before then make sure that on the bottom left of the Dante controllers’... -
Page 21: Device Not Showing Up In Dante Controller
Device Not Showing Up In Dante Controller ® ® If your Dante device does not show up in Dante Controller then the most likely issue is that the device’s IP Address is not appropriate for your network. A) It maybe that the device is set to obtain an IP address automatically using DHCP (this is the default configuration) and your network is setup for fixed IP addresses only and does not have a DHCP server. -
Page 22: Aes67 Mode
AES67 and therefore the Bella 32 can be set to AES67 mode for interaction with other AES67 devices. Please note however that Glensound are relying on Audinate’s AES67 interface and are unfortunately not able to provide full AES67 support for the unit. AES67 support should be sought directly from Audinate. - Page 23 2. Sending AES67 Audio To transmit AES67 audio to the network a multicast flow must first be setup. This is done by selecting the ‘Create New Multicast Flow’ Icon in the Device View. Tick the AES67 Flow check box, then select up to 4 channels to be included in the flow then click ‘Create’...
-
Page 24: Updating The Brooklyn Chipset
UPDATING THE BROOKLYN CHIPSET The Brooklyn module is a device supplied by Audinate that does most of the processing for the actual Dante/ AES67 network audio streams. There is one Brooklyn module in each Bella 32. We supply special code (a .dnt file) that sets up/ initiates the Brooklyn module and makes it work in particular way that is compatible to the Bella 32. -
Page 25: Specifications
SPECIFICATIONS Page 25 of 27... -
Page 26: Wiring Information
WIRING INFORMATION Standard XLR Pin Outs STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth 2: INPHASE/ POSITIVE/ MIC + 3: MATE/ NEGATIVE/ MIC - XLR PLUG (MALE) XLR SOCKET (FEMALE) Standard Headphone Wiring STANDARD HEADPHONE WIRING: RING TIP: A/ LEFT Ear RING: B/ RIGHT Ear SLEEVE SLEEVE: Common/ Earth... -
Page 27: D9 Wiring & Loop Interconnecting To External Equipment
D9 Wiring & Loop Interconnecting To External Equipment 9 Pin D Plug Fitted to Device 1) Loop Out 1 DIM LS 6) Loop Out 1 DIM LS 2) Loop Out 2 CUT LS 7) Loop Out 2 CUT LS 3) Input DIM LS 8) Input CUT LS 4) Input CUT INTERNAL LS (see note) 9) Spare Input...
