Door Interlock Systems
Installation & Operation Manual
(DIS-4X-INTAS; DIS-4SV-INTAS; DIS-2X-INTAS)
Door Interlock Systems revised Ver. 2.0
On date 31 Jan 2019
Due to continuous technology up-gradation, product specifications and features are
subject to change without notice at any time.
It is Smart I's goal to supply accurate and reliable documentation. If you discover a
discrepancy in this document or Need Help, please e-mail your comments to
support@smartisystems.com
Page 1 of 19
Advertisement
Table of Contents
Summary of Contents for Smart I DIS-4X-INTAS
- Page 1 Due to continuous technology up-gradation, product specifications and features are subject to change without notice at any time. It is Smart I’s goal to supply accurate and reliable documentation. If you discover a discrepancy in this document or Need Help, please e-mail your comments to support@smartisystems.com...
-
Page 2: Table Of Contents
TABLE OF CONTENT WARNING & CAUTION ___________________________________________ 3 INTRODUCTION ________________________________________________ 4 PRODUCT FEATURE ____________________________________________ 4 PRODUCT SPECIFICATION _______________________________________ 5 BLOCK DIAGRAM FOR 2 DOORS DIS ______________________________ 6 BLOCK DIAGRAM FOR 4 DOORS DIS ______________________________ 7 GENERAL ARRANGEMENT DIAGRAM OF SYSTEM FOR 4DIS SYSTEM __ 8 MASTER 2-DIS BOARD CONNECTION DETAILS ______________________ 9 MASTER 4-DIS MASTER BOARD CONNECTION DETAILS _____________ 10 SLAVE 4-DIS SLAVE BOARD CONNECTION DETAILS ________________ 11... -
Page 3: Warning & Caution
WARNING & CAUTION ∅ Do not open system or places it near other heavy electrical equipments. The system is sensitive to Electro Static Discharge (ESD) ∅ Do not power on the system without reading this manual. Ensure proper power supply with Earthing. ∅... -
Page 4: Introduction
Introduction DIS is designed and manufactured state-of-the-art door interlock/access systems for clean rooms, containment suites, laboratories - in fact any critical area that requires door access control with additional security. DIS has Master-Slave Configuration and can be configured up to maximum 8 doors in loop. -
Page 5: Product Specification
Product Specification Specifications of 4 Door DIS MASTER Type Microcontroller based 4 Door DIS system Display & Keypad 16 X 2 Alphanumeric display & 12 Keys Keypad using Pro Keypad (Used only in Programming Logic mode) Outputs Potential free o/p X4 nos for Lock Contact Rating : 0.5 amp for 230 V AC 1.0 amp for 24 V DC Door LOCK LED indication X 4 nos... -
Page 6: Block Diagram For 2 Doors Dis
Block Diagram for 2 Doors DIS System Requirement for 2 Doors DIS Board : 1 No Power Supply : 12VDC, @2A Magnetic contact Switch : 2 No Electro-magnetic Lock : 2 No Page 6 of 19... -
Page 7: Block Diagram For 4 Doors Dis
Block Diagram for 4 Doors DIS System Requirement for 4 Doors DIS Board : 1 No Power Supply : 12VDC, @5A Magnetic contact Switch : 4 No Electro-magnetic Lock : 4 No Page 7 of 19... -
Page 8: General Arrangement Diagram Of System For 4Dis System
General Arrangement Diagram of system for 4DIS system Cable Specification Cable-A (Lock Cable) => 2 core cable (14/36; 22AWG) max 100 meter Cable-B (MC Cable) => 2 core cable (14/36; 22AWG) max 100 meter Page 8 of 19... -
Page 9: Master 2-Dis Board Connection Details
Master 2-DIS Board Connection Details DOOR 1 DOOR 2 LD14 LD15 LD12 POWER JP23 FIRE E+ E- EL+ EL- Page 9 of 19... -
Page 10: Master 4-Dis Master Board Connection Details
Master 4-DIS Master Board Connection Details KEYPAD DOOR 1 DOOR 2 LD14 LD12 LD15 POWER JP23 FIRE DOOR 3 DOOR 4 LD16 LD17 LD10 E+ E- EL+ EL- Page 10 of 19... -
Page 11: Slave 4-Dis Slave Board Connection Details
Slave 4-DIS Slave Board Connection Details DOOR 6 DOOR 5 LD14 LD15 POWER FIRE DOOR 8 DOOR 7 LD16 LD17 LD10 E+ E- EL+ EL- Page 11 of 19... -
Page 12: Dis Pcb Connector Details
4 DIS PCB Connector Details J1 Connection Details:- (Keypad and Display) Pin No. Description 1 to 16 KEYPAD and DISPLAY J2 Connection Details:- (Slave) Pin No. Legend Description 1 to 16 FRC cable is connected here which comes from Master board when we have to use it as 8-DIS.(Slave pin) Max distance slave to master 1.5 to 2 meter. - Page 13 J9 Connection Details:- (Door 1) Pin No. Legend Description MC1+ Connect to magnetic contact sensor or in LOCK MC1- Connect to P of J13 Connect to –ve of EML lock. Lock ---- Open ---- EG1+ ---- DOTL1 ---- J10 Connection Details:- (Door 2) Pin No.
-
Page 14: Dis Pcb Led Details
J13 Connection Details:- (Door 1) Pin No. Legend Description Potential free contacts of Relay1. J14 Connection Details:- (Door 2) Pin No. Legend Description Potential free contacts of Relay2. J15 Connection Details:- (Door 3) Pin No. Legend Description Potential free contacts of Relay3. J16 Connection Details:- (Door 4) Pin No. - Page 15 KKZ KEE d/KE &KZ D> >K< EML LOCK KKZ KEE d/KE &KZ ^dZ/< >K< STRIKE LOCK Door Connection for Magnetic Contact:- Magnetic Contact Page 15 of 19...
-
Page 16: Dis-Fp1-Alembic Connection Details
DIS-FP1-Alembic Connection Details Front side of DIS-FP1-Alembic LOCK OPEN Back side of DIS-FP1-Alembic 6 Pin Connector Details of DIS-FP1-Alembic J1 Pin No. Pin Details Wire color Green Yellow Door LOCK Orange Door Open Exit switch Brown DOTL Buzzer Black Page 16 of 19... -
Page 17: Dis-Fp1-Alembic Led Details
DIS-FP1-Alembic connection with 4 Door DIS Board Facia Relimate Plate Connector To 4 Door DIS Board Door-1 to Door-4 J1 Pin Pin Details Wire color Facia Pin Pin Details Wire color Green Green Yellow Yellow Door LOCK Orange LOCK Orange Door Open Open Exit switch... -
Page 18: Keypad Function Details For 4 Dis System
Keypad Function Details for 4 DIS system Function How to go? Note Default Value Normal Mode Key- *0 Admin Mode Key- *2 To come out from Admin Enter User ID(11111) mode press Press # key Key – *2 Enter Password(12345) Key –... - Page 19 Emergency door open Setting Key – *97 Value = 0 - It will open only that single Enter required particular door upon long press of 0 secs Emergency emergency door open egress. Door open configuration Setting Emergency door open Setting Key –...
-
Page 20: Dis Integration With Access Controller System
DIS Integration with Access Controller System Access DIS Board Controller Reader Facia Door Lock Plate Exit C1: Reader is connected to Access controller (as IN Reader). C2: Potential free contact o/p of Lock from Access controller is connected to egress I/P of DIS system. C3: Lock output from DIS system is connected to Door Lock. - Page 21 DIS Integration with Access Controller System Access DIS Board Controller Reader Door Lock C1: Reader is connected to Access controller (as IN Reader). C2: Potential free contact o/p of Lock from Access controller is connected to magnetic contact I/P of DIS system. C3: Lock output from DIS system is connected to Door Lock.
