- Page 1 700TV High Speed Dome Camera User Manual INSTRUCTION MANUAL Please read this manual throughly before use and keep it handy for future reference...
-
Page 2: Warnings And Cautions
WARNINGS and CAUTIONS WARNINGS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK. DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY MEALMETALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHERS OPENINGS ON THE EQUIPMENT. CAUTIONS RISK OF ELECTRIC SHOCK DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER(OR BACK). -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS High Speed Dome with IP 67 rated outdoor housing is specially unique & creative designed for strong durability & extremely reliability. This camera o ers perfect prevention of dew condensation and clear image at operating temperature from -50℃~ 50℃. Especially, this mechanism supports greatly increase accuracy and decreasing operation noise. -
Page 4: Table Of Contents
TABLE OF CONTENTS - WARNINGS AND CAUTIONS - IMPORTANT SAFEGUARDS - TABLE of CONTENTS - PACAGE CONTENTS - INSTALLATION & CONFIGURATION -- Addres switch setting -- Wall Mount Installation -- Ceiling Mount Installation -- Interface Cable Wiring - DIMENSION - SPECIFICATION - OPERATION &... - Page 5 PACKAGE CONTENS The following parts are supplied with the speed dome system. 1. Dome camera Unit 2. Body (W/O Sunshield) 3. Trimring Bubble Dome 4. Wrench-3mm 5. User’s manual Dome Camera Unit Bubble Dome Ass’y Housing Body Sunshield (Option) Manual Wrench (W/O Sunshield) Wall Bracket...
-
Page 6: Addres Switch Setting
INSTALLTION Each Part Name ① ③ Dome Camera Unit Rear View Pin description Dip switch for protocol and baud rate Address switch ② Address Switch Setting - Before installation, please set the address switch as described in this manual. (You have to set the “Address switch” as you want before installation.) Protocols Setting Default (0,1) - If you are going to use pelco-D, pelco-P protocols to communicate... -
Page 7: Wall Mount Installation
INSTALLTION Wall Mount Bracket - Camera Set Assemble STEP 1. STEP 2. Connect the dome camera unit to housing body Ass’y. Remove the holder screw. (Turn the 4ea of each screw to the right) ① Alarm cable connection ② RJ45 jack connection ③... -
Page 8: Ceiling Mount Installation
INSTALLTION Wall Mount Installation STEP 6. Assemble the xed screws using the wrench supplied. STEP 5. Fix the camera set by used screw as the picture. STEP 8. Close the bracket cover and x it by knob bolt. Fix the steel cover supplied on the upper of the bracket using screw CM3x8L. -
Page 9: Dimension
INSTALLTION Each Part Name - Cable connection Power Video CONT. COLOR PMC14H BRIGHT TINT UNDER VOLUME S-VIDEO POWER SCAN ① Interface cable RJ45 Brown / White Black / White Alarm IN Alarm 0 Red / White Black Alarm IN Alarm 1 Orange / Black Control Orange... -
Page 10: Menu Tree
SPECIFICATION & MENU TREE Camera 27X / 37X NTSC 27X / 37X PAL Image Sensor 1/4 inch, Interline Transfer CCD 1/4 inch, Interline Transfer CCD Zoom (Modul Specific) 37x Optical, f=3.4 to 129.5mm (F1.6~F3.9) 37x Optical, f=3.4 to 129.5mm (F1.6~F3.9) 27x Optical, f=3.5 to 94.4mm (F1.6~F2.8) 27x Optical, f=3.5 to 94.4mm (F1.6~F2.8) 16x Digital Zoom... - Page 11 OPERATION & PROGRAMMING Check points before operation Before power is applied, please check the cable carefully. The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked by reading Rotary switch of the camera. If your controller supports multi-protocols, the protocol must be changed to match to that of the camera.
- Page 12 OPERATION & PROGRAMMING SYSTEM : INFO <<<<< Main MENU >>>>> ██████████████████████████ ► SYSTEM > The system Information displays Serial Number/model Name /Running Version/Protocol/ DISPLAY > Communication Type/Address switch No.(Camera ID) / Camera internal temperature. DOME > CAMERA > System settings cannot be edited in this menu. This screen is for reference only.. ALARM >...
- Page 13 OPERATION & PROGRAMMING SYSTEM : EVENT LOG <<<<< Main MENU >>>>> ██████████████████████████ Event Log shows the current dome status and dome event logs. ►SYSTEM > If the dome have some problems, It displays error message and save the logs to EEPROM. DISPLAY >...
- Page 14 OPERATION & PROGRAMMING DISPLAY : AREA TITLES <<<<< Main Menu >>>>> ██████████████████████████ If user want to see the name of Area Title on the monitor, user have to save the Area Title from SYSTEM > ►DISPLAY > OSD SETUP Starting position to Stop position. >...
- Page 15 OPERATION & PROGRAMMING DOME : GENERAL SETUP BACK UP TASK : Even though event( alarm action) is occurred, the preset, tour, pattern and scan is operated ON (default) : When the event (alarm action ) is occurred, the camera move to object with detected zone even though camera already set preset, tour, pattern and scan <<<<<...
-
Page 16: Home
OPERATION & PROGRAMMING DOME : HOME This function enables to locate the camera to speci c position automatically if operator doesn’t operate the controller for a while. The Home time can be de ned as a interval from1 minute to 240 minute. Note. -
Page 17: Pattern
OPERATION & PROGRAMMING DOME : PATTERN <<<<< Main Menu >>>>> ██████████████████████████ Pattern function is that a camera memorizes the path by joystick of controller for assigned time SYSTEM > DISPLAY > GENERAL and revives the path exactly as it memorized. 8patterns are available. ►DOME >... -
Page 18: Camera : Focus/Zoom
OPERATION & PROGRAMMING CAMERA : FOCUS/ZOOM <<<<< Main Menu >>>>> ██████████████████████████ FOCUS SYSTEM > DISPLAY > There are three auto focus settings : > ►FOCUS/ZOOM DOME AUTO: If auto focus mode is set to auto. The camera will focus automatically. ►CAMERA >... -
Page 19: Exposure
OPERATION & PROGRAMMING CAMERA : EXPOSURE <<<<< Main Menu >>>>> ██████████████████████████ SYSTEM > The variety of Auto Exposure functions, which allow video signal to output the optimum image for DISPLAY > subjects from low light conditionto high light conditions, is available. DOME >... -
Page 20: Alarm
OPERATION & PROGRAMMING ALARM <<<<< Main Menu >>>>> ██████████████████████████ IN (4ea of ALARM INPUT) SYSTEM > DISPLAY > NO Normal Open. DOME > NC Normal Close. CAMERA > ►ALARM OUT (1ea of ALARM OUTPUT) EXIT 1. Go to “No.001”- > turn the joystick with clockwise. If you cancel, please turn the joystick with counter-clockwise.
