Aerial Connections

• To enjoy a clearer picture, we recommend that you use an outdoor aerial lead. The following is a
brief explanation of the types of connection that are used for coaxial:
Aerial Lead: Connect the cable from the aerial to a
standard DIN45325 plug (IEC169-2) and plug it
into the aerial terminal at the back of the TV set.
Rear of TV
Typical connection (VCR and TV)
through the RF terminal
Aerial IN
Scart Terminal
75-ohm coaxial cable (round cable)
Outdoor aerial
(not supplied)
Aerial Lead
(not supplied)
Rear of TV
Aerial Lead
(not supplied)
Aerial Lead
(not supplied)
SCART Lead
(not supplied)
RF Out
Back of VCR
Antenna in
3
