Introduction to this guide Thank you for choosing Philips EasyAir SNS210 MC. In this guide luminaire manufacturers will find the information required to design this product into a luminaire and configure it to suit specific applications. This design-in guide covers sensor functionality, mechanical mounting, wiring details, configuration and commissioning (grouping) method, application notes and frequently asked questions. -
Page 4: Warnings And Instructions
Warnings and instructions • EasyAir SNS210 MC must be used with Philips Xitanium SR LED drivers. • Do not apply mains power directly to the sensor. • Do not cover the sensor during operation or mount the sensor internal to the luminaire. -
Page 5: Introduction Of Easyair Sns210 Mc
Introduction of EasyAir SNS210 MC The Philips EasyAir SNS210 MC is the ideal solution for per-luminaire control of smart luminaires. It combines occupancy sensing, daylight harvesting and task tuning in a single, compact package for easy OEM luminaire assembly. EasyAir SNS210 MC operates with the established Xitanium... -
Page 6: Product Characteristics
• Zigbee/Bluetooth • Light sensor LE antenna • LED indicator EasyAir SNS210 MC is designed for a typical indoor environment (open/private offices, conference rooms, classrooms, corridors, etc.) in normally heated and ventilated areas. The sensor is normally mounted to a luminaire and is optimized for a sensor mounting height of 2.5 m to 3 m. -
Page 7: Motion Detector
Motion detector The occupancy sensor is a PIR (Passive Infrared) sensor that detects movement with an X-Y cross-area under an angle of X = 62° and Y = 84°. Two types of movements are defined as follows: • Major movement: movement of a person walking into or through an area. -
Page 8: Sensor View Shield
To prevent false triggers, the EasyAir SNS210 MC must be mounted more than 2 m away from air vents in all directions, see figures below: > 2m Luminaire > 2m > 2m > 2m Sensor view shield The sensor comes with an occupancy view shield that can be used to block the movement detection by the sensor in a certain area. -
Page 9: Light Sensor
The EasyAir SNS210 MC converts the illuminance signal into ON/OFF or dimming commands to the Philips Xitanium SR LED driver in order to maintain a constant light level on the desk. Window The sensor should be installed with a minimum distance of 0.6 m to the window to avoid the sensor looking outside. -
Page 10: Mechanical Design-In
Mechanical design-in Wire strip length Wiring Information Strip length Applicable wires 8.0 ± 0.5 mm Conductor size: solid 0.2 - 0.75 mm Conductor size: fine-stranded 0.2 - 0.75 mm Conductor size: fine-stranded 0.25 - 0.34 mm Conductor Insulation (with insulated formule) Conductor size: fine-stranded 0.25 - 0.34 mm [ Conductor: Bare Copper / Strand wire ]... -
Page 11: Wire Distance For Remote Mounting
Xitanium SR LED driver less than 15 m and meet the wire gauge requirement to guarantee the performance. Luminaire-to-luminaire distance If multiple luminaires with EasyAir SNS210 MC are used in the same area, the distance between the different sensors should be kept at least 1.5 m. This distance will minimize a sensor from “seeing”... -
Page 12: Mounting To A Luminaire
Mounting in a luminaire EasyAir SNS210 MC is a luminaire-mount sensor that is LED module directly powered by a Xitanium SR LED driver. It can be mounted to a slot or a cut-out in sheet metal. SNS210 Light shield Note: When daylight sensing is enabled, it is advised to... -
Page 13: Mounting In A Bracket (Smb-50)
Mounting in a bracket (SMB-50) 65 Max. The EasyAir SNS210 MC can be mounted in a bracket (SMB 50). Refer the figures for details on mounting and design-in into luminaire. All dimensions are in mm. 26 Max. 64 Max. 60 ± 0.2 24 Max. -
Page 14: Installing Easyair Sns210 Mc With Ceiling Mount Bracket (Sns210 Mccmp)
Installing EasyAir SNS210 MC with ceiling mount bracket (CMP/W) The ceiling mount CMP bracket is available as a bracket without any pre-mounted sensor or cable. The luminaire manufacturer needs to mount the sensor in the CMP bracket and attach cable to it. The cable and screws are available with the accessory. -
Page 15: Easyair Sns210 Mc With Multiple Philips Xitanium Sr Led Drivers (1:N Application)
DALI power supplies. NEUTRAL SGND LINE NFC ANTENNA Each SR driver provides approximately 55mA of current on the DALI bus, and EasyAir SNS210 MC is limited to 250mA. Connectors LED+ EasyAir SNS210 MC sends commands to all connected LED+ LED-... -
Page 16: Luminaire Production Test
Luminaire Production Test To ensure that a luminaire has been assembled correctly i.e. the wiring of the EasyAir SNS210 MC sensor to Xitanium SR driver is correct; a visible check can be made. The luminaire on power up dims up to 30% of maximum light output in the 1st second followed by dimming up to 100% in the next second. -
Page 17: Faq
Can you use a wall dimmer with EasyAir SNS210 MC? SNS210 MC can be used with a wireless wall dimmer, e.g., Zigbee green power switch. For list of supported switches, please visit our website How does EasyAir SNS210 MC compare to Philips ActiLume? Occupancy sensing and daylight harvesting are similar. - Page 18 Does EasyAir SNS210 MC make sense if I only want to do Yes. Keep “Occupancy Control” enabled in MC App and occupancy sensing? disable “Daylight Control” How does the daylight harvesting feature work? EasyAir SNS210 MC does inbuilt calibration to 500 lux at desk level.
-
Page 19: Contact Details
Contact details Philips EasyAir SNS210 MC Product information: www.lighting.philips.co.uk/oem-emea/products/easy-to- integrate-wireless-sensors.html Or contact your local Philips sales representative. Design-in Guide - EasyAir SNS210 March 2020... -
Page 20: Disclaimer
Disclaimer ©2020 Signify Holding B.V. All rights reserved. Note that the information provided in this document is subject to change. This document is not an official testing certificate and cannot be used or construed as a document authorizing or otherwise supporting an official release of a luminaire. The user of this document remains at all times liable and responsible for any and all required testing and approbation prior to the manufacture and sale of any... - Page 21 The information presented in this document is not intended as any commercial offer and does not form part of any quotation or contract. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. All other trademarks are owned by Signify Holding or their respective owners.
