Fosera Mobile One User Manual

Light!
Mobile One is solar power on the go. With 3 modes of brightness you can adjust the LED light
to your specific needs as well as extend your lighting hours.
• Light Mode 1: To switch on the light mode
1, press once. This mode gives you a very
long runtime.
• Light Mode 2: For medium lighting press
twice.
• Light Mode 3: For power lighting press a
third time.
• Press the button once more and the light
will turn off.
• Press and hold for one second to turn off
your mobile One from any setting.
Light Output Level Luminance
Light mode 1 16 lm
Light mode 2 88 lm
Light mode 3 200 lm
* Mobile phone charging or using Fosera appliances reduces the runtime of the
Additional Power!
This versatile flashlight can also power
an additional FOSERA lamp, charge a
mobile phone and run a radio. If you're
using a phone, which doesn't have a USB
included, fosera provides additional ad-
apters for many common phones.
The outlets can be turned on by pressing
the power button. They switch off automatically once the system is not used anymo-
re. To reactive the outlets, press the power button.
Fosera Solarsystems GmbH & Co KGaA
Beim Muehlbach 3 • 89171 Illerkirchberg • Germany
Tel.: +49 7346 9246973 • info@fosera.com • www.fosera.com
Light Output /
3 brightness settings: 200lm / 5:30 hrs; 88lm / 11 hrs; 16lm / 63 hrs
battery runtime*
Battery 3.8 Ah, 3.2 V Lithium-Iron-Phosphate (LiFePO
Solar Panel 2.5 Wp poly crystaline silicon panel with 6m cable
Outlets 1 USB outlet for phone charging and 1 outlet for
additional appliances like lamp or radio
Charge Controller Overcharge-, deep discharge- and over current protection
Battery Indicator 6-stage battery charge indication
Low Power Mode Automatically switches the mobile One to energy saving mode,
when battery runs low, allowing 1-2 additional hours of lighting.
Content: Mobile One Solar Torch / Solar Panel / User Manual
*Mobile phone charging or using Fosera appliances reduces the runtime of the

Warranty!

We trust in the quality of our products.
All fosera battery boxes, PV modules and lighting products come with 3 years war-
ranty. During this period we guarantee that our products are free from defects in
material or workmanship.
Please contact your dealer or local fosera sales agent if you experience any problems
with the product. Your local dealer will then assess the defect and decide whether
the product can be repaired or has to be replaced.
Fosera is not responsible for any consequential damage or damage that exceeds
the value of the product. A warranty repair does not extend the warranty period.
Appliances, like radio, TV, PAYG remote or fans are not included in the overall fose-
ra warranty for electronic components and may have different warranty terms. The
warranty becomes invalid if the device is used other than intended by the manufac-
turer. This warranty does not cover failures caused by incorrect installation, set up
or unusual use. The warranty is also void in case of repairs by any unauthorized or
untrained person.
Power Button
Battery Runtime*
63 hours
11 hours
5:30 hours
mobile One.
)
4
mobile One.
Engineered
in Germany
Mobile One is a durable and attractive solar torch, with three levels of brightness
powered by fosera's long lasting LiFePO
It's strong enough to double as a mini solar home system that can power a lamp,
mobile phone or radio using the load outlet or the USB port.
A unique 3-cornered design and hole at its base makes it easy to stabilize the
One
for hands free use, making it a flexible and portable addition to the FOSERA
product line.
Energy!
Always know how much energy is still in your

Battery State of Charge:

mobile
hold the power button to find out the state of charge.
100%
75%
50%
25%

Energy Saving Mode:

mobile One
The
that even if the battery charge is getting low, light is still
available for 1-2 more hours. All outlets are switched off and only
the lowest light output level can be turned on.
Battery empty:
If the LED blinks red, please recharge your
Recharge!
Charge mobile One anywhere with the provided solar panel or through
the USB outlet with the fosera USB cable (not included in the set).
When charging, the char-
ging symbol on the mobile
One will switch on.
Trouble?
The mobile One is protected against short circuit and over current.
If an error occurs, all LED's will turn on.
Please disconnect all loads.
If you have any problem with the system, you can restart your
by pressing the power button for 8 seconds.
mobile One
User Manual
battery.
4
One: Turn off your mobile One
Battery-
Indicator
comes with an Energy Saving Mode to ensure
mobile
If the battery is full the
charge indicator turns off.
mobile One
mobile
and press and
Charging-
Indicator
One.
