- Page 1 MANY0739A.GB – Metacentre DX Box User Manual DX Box...
-
Page 2: Health And Safety
Metacentre DX Box Index 1.0 Introduction Management System Connectivity Health and Safety Basic Function Refer to Metacentre Safety Manual Operation 2.0 Operation User Interface Display Status Symbols Indications Compressor Identification Operation Power Failure Auto-Restart Failure Modes Compressor Fault 2.10 DX Box Fault 2.11 Pressure Sensor Fault... - Page 3 User Manual 1. INTRODUCTION Any number of DX Boxes can be connected to The DX Box is designed to connect two an system management unit as long as the load/unload air compressors to a system total number of single compressors and/or management unit, using a 2-wire RS485 data groups does not exceed the total number of cable up to 500m (1650ft) in length.
- Page 4 Metacentre DX Box 1.3.2 Automatic Mode (Ar) The DX Box ‘group’ unit should be set as a variable output unit on the management system. The management system will fully utilise the variable output capacity capability of the DX Box ‘group’ and report the percentage of utilisation of the ‘group’...
-
Page 5: Operation
User Manual When viewing the status or pressure 2. OPERATION information for a compressor the ‘network address’ and DX Box identification will be show on the upper display (for example, “C.03.1” indicates that the compressor is connected to the DX Box as compressor #1 and the DX Box is represented on the system management unit as compressor number “03”). - Page 6 Metacentre DX Box Compressor Status: on the system management unit as compressor number “03”. Compressor Running Operation Compressor On Load Flashing - Not Responding, Compressor The DX Box is always active (started) and Not Running When required to load. cannot be stopped. The DX Box will automatically switch between ‘Remote’, when...
- Page 7 User Manual 2.10 DX Box Fault The DX Box has two ‘shutdown’ fault conditions: E:0821 Short Circuit Condition Detected, check all DX Box controller inputs and outputs. E:0135 System Pressure Sensor Fault. If one of these fault conditions occur the DX Box will switch ‘off.
-
Page 8: Parts List
Metacentre DX Box 3.0 Parts List DX Box Item Part No. Description Y07ENER10.00 Unit, DX Box Y07CM14.00 Manual, User CD Y07CM20.00 Controller, S1 DX Y05CM31.00 Unit, XPM-TAC24 KPY0617.00C PCB, Terminal EX Y07CM49.00 Gland, Set - Pg13.5 Required For Each Compressor: AirMaster S1 Item Part No. -
Page 9: Wiring Diagram
User Manual 5.0 Wiring Diagram C001 + VDC C002 C009 Multi485 C003 C010 + VDC C004 Multi485 C005 + VDC C006 C007 C007 not used A-GND C008 C008 4-20mA C006 C009 System Press. C005 C010 4-20mA C004 Pressure #2 C003 C011 C002 4-20mA... - Page 10 Metacentre DX Box XPM-TAC24 BLUE BLACK BROWN ORANGE WHITE GREEN VIOLET T3.15A T1.6A T1.6A T1.0A VOLTAGE SELECT 230V +-10% 230V 115V 115V +-10% T1.0A 5x20mm 24Vac/1 24Vac/2 N L E isolated earthed Page 9...
