Caravan
TITLE
EFFECTIVITY
Model
208
208B
DESCRIPTION
This service kit gives parts and instructions to install a new control quadrant cover, fuel condition lever (FCL),
emergency power lever (EPL) and emergency power control cable bracket.
APPROVAL
FAA approval has been obtained on technical data in this publication that affects airplane type design.
REFERENCE
CAB06-3
CHANGE IN WEIGHT AND BALANCE
Negligible
March 20, 2006
To obtain satisfactory results, procedures specified in this publication must be accomplished in accordance with accepted methods and
prevailing government regulations. Cessna Aircraft Company cannot be responsible for the quality of work performed in accomplishing the
requirements of this publication.
Cessna Aircraft Company, Product Support, P.O. Box 7706, Wichita, Kansas 67277, U.S.A. (316) 517-5800, Facsimile (316) 942-9006
Serial Numbers
20800001 thru 20800395
208B0001 thru 208B1170
COPYRIGHT © 2006
SK208-166
Page 1 of 8
Advertisement
Table of Contents
Related Manuals for Textron Cessna SK208-166
Summary of Contents for Textron Cessna SK208-166
- Page 1 Caravan SERVICE KIT SK208-166 TITLE CONTROL QUADRANT MODIFICATION EFFECTIVITY Model Serial Numbers 20800001 thru 20800395 208B 208B0001 thru 208B1170 DESCRIPTION This service kit gives parts and instructions to install a new control quadrant cover, fuel condition lever (FCL), emergency power lever (EPL) and emergency power control cable bracket. APPROVAL FAA approval has been obtained on technical data in this publication that affects airplane type design.
- Page 2 SERVICE KIT SK208-166 MATERIAL INFORMATION The parts below cover installation for one airplane. NEW P/N QUANTITY DESCRIPTION OLD P/N DISPOSITION SK208-166 Kit, consisting of the following parts: AN3-4A Bolt None AN3-5A Bolt None AN23-15 Bolt MS21045-3 None MS24665-86 Cotter Pin Same NAS1149F0332P Washer...
- Page 3 SERVICE KIT SK208-166 2601455-18 Cover Assembly 2601455 Discard 2601455-13 Guard Assembly 2601455 Discard In addition to the SK208-166 kit, airplanes without Engine Trend Monitoring (ETM) installed, order the following parts. NEW P/N QUANTITY DESCRIPTION OLD P/N DISPOSITION C489003 12 inches Wire Same Discard...
- Page 4 SERVICE KIT SK208-166 Install the SL6004-8 Emergency Power Lever (675 SHP engine) or SL6004-11 Emergency Power Lever (600 SHP engine) and the SL6004-9 Fuel Condition Lever (Standard) or the SL6004-10 Fuel Condition Lever (British certified airplanes) with the kept shaft and spacers. Assemble the quadrant.
- Page 5 SERVICE KIT SK208-166 10. (Refer to Figure 1, Detail A.) Install the new quadrant cover assembly. (Refer to the Maintenance Manual, Chapter 76, Quadrant Assembly and Controls - Maintenance Practices.) (Airplanes without ETM installed) Install shear wire and quadrant cover. Use the kept control column cover as a guide and mark the shear-wire hole location on the new 2613048-22 Cover Assembly (standard) or 2601455-13 Guard and 2601455-18 Cover Assembly (British).
- Page 6 SERVICE KIT SK208-166 Figure 1. Control Quadrant Modification (Sheet 1) SK208-166 Page 6...
- Page 7 SERVICE KIT SK208-166 Figure 1. Control Quadrant Modification (Sheet 2) SK208-166 Page 7...
- Page 8 SERVICE KIT SK208-166 Figure 1. Control Quadrant Modification (Sheet 3) SK208-166 Page 8...
