  • Page 1 DRV SERIES GROUND DRIVES PARTS AND INSTRUCTIONAL MANUAL DRV-3000 Shown JOHN BLUE COMPANY DIVISION OF ADVANCED SYSTEMS TECHNOLOGY, INC. 165 Electronics Blvd, Huntsville, AL 35824 Telephone: (256) 721-9090 • FAX: (256) 721-9091 Toll Free: 1-800-253-2583 www.johnblue.com Printed in U.S.A. 12-M-44...
  • Page 2 WARNING: USE OF THIS PRODUCT FOR ANY PURPOSES OTHER THAN ITS ORIGINAL INTENT, ABUSE OF THE PRODUCT, AND/OR MODIFICATION TO THE ORIGINAL PRODUCT IS STRICTLY PROHIBITED BY JOHN BLUE COMPANY. JOHN BLUE COMPANY RESERVES THE RIGHT TO DENY WARRANTY OR LIABILITY CLAIMS IN ANY/ALL SITUATIONS INVOLVING MISUSE, ABUSE OR MODIFICATION.
  • Page 3 Installation Instructions: DRV-3000, 3100, 3300 *refer to diagram on next page 1) Attach the Universal Mount (G) to the toolbar using the correct set of U-Bolts. 2) Using the Jack-Shaft Carrier Assembly (B), attach the Arm-Weldment (C) to the Universal Mount (G). 3) Attach Spring Assembly (-3300) or Gauge Adjustment (-3000, -3100) to the Arm-Weldment (C) and the Universal Mount (G) using the two gauge pins and cotter pins.
  • Page 4 Installation Diagram: DRV-3000, 3100, 3300 ** Note: Idler bracket positions are shown for Pull Type installation Direction of Travel - Pull Type Install DRV 3000, 3100 Gauge Adjustment DRV-3300 Spring Assembly Wheel Rotation List of major Assemblies and Parts A) Spindle Assembly B) Jack-Shaft Carrier Assembly C) Arm-Weldment **For item number descriptions...
  • Page 5 Installation Instructions: DRV 3200 Planter Drive **See pages 6 and 7 for part numbers of shared components Reverse idler bracket if chain rotation is opposite direction shown #54: U-bolts sold separately Attach to planter shaft #21a: 114932-01 #47a: 114934-01 #21b: 114936-91...
  • Page 6 Parts Diagram: All Models ** Note: Idler bracket positions are shown for Push Type installation Direction of Travel - Push Type Install Wheel Rotation...
  • Page 7 Parts List DRV-3000 DRV-3100 DRV-3300 DRV-3200 Item Part # Description Fixed Height Gage Wheel Spring Load Planter Mount Drive Only Drive 92031 ½-13 JAM NUT 92029 ½-13 HEX NUT 93012 7/16 FLAT WASHER A-401 IDLER SPOOL A-512 FERRULE 115944-01 IDLER BRACKET 90699 ½-13 X 3-1/4 BOLT 93018...
  • Page 8 When it is impractical to return the defective parts of such equipment to John Blue’s factory, then John Blue shall have no liability for the labor cost involved in repairing or replacing any such parts and shall be liable solely for supplying the material necessary to replace or repair the defective parts, provided that prior thereto John Blue Company shall have determined to its satisfaction that any such parts are thus defective.

This manual is also suitable for:

Drv-3000Drv-3100Drv-3300
