Polygroup Ashland TG76M4G64D02 Assembly Instructions

NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from Polygroup®! Carefully follow the instructions below on how to quickly
and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 1
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap before inserting
into the assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of
branch hinges.
7. Plug the adaptor into the wall outlet(see Fig. B). Your entire tree should now be lit. If some bulbs do not light or flickers,
search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in order to maintain the
performance and life expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out
one to the right, one to the left and one at the center of the main stem. (See Fig. C)
MODEL #: TG76M4G64D02
1-888-919-0070
OR
Tree top
Section 2
Unfold the legs and lay the
stand in a flat area. Then slide
the locking disc downward and
snap into place.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input:120V, 60Hz, 0.16A Max.
Output: 29V DC 0.28A
Insert Red Label
Plugs Into Red
Labeled Extension Cord
Control box
Insert Green
Label Extension
Cord into Adaptor
1
Adaptor
To Be Plugged
Into Wall
Outlet
