Milestone AV Technologies simplicity SLF3 Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
SLF3
(6903-002006 <00>)
Installation video available at simplicity-av.com
WOOD STUD
CONCRETE
METAL STUD
13 mm
5.5 mm
(1/2 in.)
(7/32 in.)
Milestone AV Technologies
2221 Hwy 36 West
Saint Paul, MN 55113 USA
Customer Service
888-333-1376 • 952-277-3956 • info@simplicity-av.com
www.simplicity-av.com
©2009 Milestone AV Technologies, a Duchossois Group Company.
All rights reserved. Simplicity is a Milestone brand.
All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.

Advertisement

loading
Need help?

Need help?

Do you have a question about the simplicity SLF3 and is the answer not in the manual?

Questions and answers

Related Manuals for Milestone AV Technologies simplicity SLF3

Summary of Contents for Milestone AV Technologies simplicity SLF3

  • Page 1 888-333-1376 • 952-277-3956 • info@simplicity-av.com www.simplicity-av.com ©2009 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Simplicity is a Milestone brand. All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
  • Page 2 English Español INSTRUCCIONES IMPORTANTES DE SEGURIDAD – CONSERVE ESTAS IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE INSTRUCCIONES – LEA TODO EL MANUAL ANTES DE UTILIZAR ESTE READ ENTIRE MANUAL BEFORE USING THIS PRODUCT PRODUCTO SLF3 Specifi cations SLF3 Especifi caciones ...
  • Page 3 English Concrete/Concrete Block Wood stud walls Steel Stud Walls Choose an Option Do Not Walls Français Murs en béton coulé ou en Structure de murs en bois Structure de mur en acier Sélectionnez une option Interdit blocs de béton Español Paredes con montantes de Paredes de hormigón o de Paredes con montantes de...
  • Page 4 CAUTION: English Español CAUTION: Avoid potential personal injuries and property damage! PRECAUCIÓN: Evite lesiones físicas y daños materiales.  Do not use this product for any purpose not explicitly specifi ed by  No utilice este producto para ningún otro propósito que no sea el Simplicity.
  • Page 5 Español English Supplied Parts and Hardware Piezas y Materiales Suministrados Before starting assembly, verify all parts are included and undamaged. If any parts Antes de iniciar el ensamblaje, comprobar que se encuentran incluidas y en buenas are missing or damaged, do not return the damaged item to your dealer; contact condiciones todas las piezas.
  • Page 6 M4 x 20mm M4 x 30mm M4 x 40mm [08] x 4 [09] x 4 [10] x 4 M5 x 20mm M5 x 30mm M5 x 40mm [11] x 4 [12] x 4 [13] x 4 M6 x 25mm M6 x 40mm M6 x 55mm [14] x 4 [15] x 4...
  • Page 7 Step 1 English Español ASSEMBLE THE MONITOR BRACKETS COLOQUE LOS SOPORTES DEL MONITOR Install the clamps [05] into the brackets [02]. Be sure the “V” on the clamps Instale las abrazaderas [05] en los soportes [02]. Asegúrese de que la “V” de point toward the large holes on the brackets.

  • Page 8: Install Brackets

    Step 2 CAUTION: English Français INSTALL BRACKETS INSTALLATION DES ÉTRIERS Determine the bolt diameter (4 mm, 5 mm, 6 mm, 8 mm) for your Avant d’installer les supports, déterminez le diamètre des boulons (4 monitor and your TV type. mm, 5 mm, 6 mm, 8 mm) pour le type de votre téléviseur: ...
  • Page 9 [02] [02] 4 mm 5 mm [20] [20] [26] [26] [08] [11] [21] [21] 6 mm 8 mm [20] [20] [27] [27] [14] [17] [22] [21] 6903-002006 <00>...
  • Page 10 [02] [02] 4 mm 5 mm [20] [20] [26] [26] [12] [09] [23] [23] 8 mm 6 mm [20] [20] [27] [26] [18] [15] [24] [24] 6903-002006 <00>...
  • Page 11 [02] [02] 4 mm 5 mm [20] [20] [26] [26] [10] [13] [24] [24] 8 mm 6 mm [20] [20] [27] [27] [16] [19] [25] [25] 6903-002006 <00>...
  • Page 12 Step 3 English Español INSTALL THE CROSS TUBES AND CENTER BRACKET INSTALE LOS TUBOS TRANSVERSALES Y EL SOPORTE CENTRAL Center the cross tubes [04] between the monitor brackets [02] + [03]. Conecte los tubos transversales [04] entre los soportes del monitor [02] + Tighten the clamps [05] + (A).
  • Page 13 6903-002006 <00>...
  • Page 14 Step 4 13 mm 5.5mm (1/2 in.) (7/32 in.) CAUTION: English Español WOOD STUD MOUNTING MONTAJE EN CASO DE MONTANTES DE MADERA Locate studs. Verify the center of the stud with an awl or thin nail or Localice los montantes. Verifi que el centro del montante con un use an edge to edge stud fi nder.
  • Page 15 < 16 mm 406 mm (5/8 in.) (16 in.) [01] 63.5 mm (2.5 in.) [01] [29] [28] 6903-002006 <00>...
  • Page 16 Step 5 English Español INSTALL THE ARM ASSEMBLY TO THE WALL PLATE INSTALE EL BRAZO EN LA PLACA MURAL The arm [07] can be adjusted side-to-side to customize your monitor El brazo [07] se pude ajustar de un lado al otro para personalizar la installation.
  • Page 17 Step 6 English Español INSTALL THE TV TO THE ARM INSTALE EL TELEVISOR EN EL BRAZO Slide the center bracket [03] onto the arm [07]. Be sure the locking tab Deslice el soporte central [03] hasta que ingrese en el brazo [07]. [T] engages.
  • Page 18 Step 7 English Español RUN CABLES AND INSTALL COVERS PASE LOS CABLES E INSTALE LAS CUBIERTAS Remove the upper cover on the arm (A) by pressing the front of the Retire la cubierta superior del brazo [A] presionando la parte delantera cover.

  • Page 19: Tension Adjustments

    Step 8 CAUTION: English Español TENSION ADJUSTMENTS AJUSTES DE TENSIÓN Adjust the tension as needed for ease of movement. .Ajuste la tensión según sea necesario para facilitar el movimiento. For clarity, TV is not shown. El monitor no se muestra para ofrecer una ilustración más ordenada. CAUTION: Never remove the adjustment nut (N).
  • Page 20 Step 9 English LEVEL THE TV Loosen the two screws on the back of the head. Adjust the TV position so that it is level. Tighten the screws. Français METTEZ LE TÉLÉVISEUR À L’HORIZONTAL [35] Desserrez les deux vis à l’arrière de la tête. Réglez la position du téléviseur pour qu’il soit de niveau.
  • Page 21 English Español REMOVE THE TV FROM THE WALL RETIRE EL TELEVISOR DE LA PARED Remove the safety screw [31]. Retire el tornillo de seguridad [31]. Disengage the locking tab (T) by pushing it toward the TV. Desconecte la palanca de bloqueo (T) empujándola hacia el monitor. Lift the TV up and slide it off the arm.
  • Page 22 Français Milestone AV Technologies et ses sociétés affi liées et ses fi liales (collectivement dénommées « Milestone »), se sont eff orcées de rendre ce manuel précis et complet. Cependant, Milestone ne garantit pas que les informations qu’il contient couvrent tous les détails et toutes les conditions...
