0. Overview of the parts.
6.
5.
2.
Front panel
Step 1. Assemble the bows
Put the bolts and nuts (2) in the bows (1)
make sure the nuts are facing outwards.
Take note that: when you are mounting the tent on a narrow trike the tent uses two seperate
bows (1), the small bow needs to be placed in the front of the box.
Manual Trike tent
4.
3.
1.
1.
Bow (2x)
2.
M6 x 30 bolt + nuts (8x)
3.
3.5 x 9.5 screw + press stud (4x)
4.
4.8 x 18 screw + cylinder (4x)
5.
Elastic (4x)
6.
Tent
Step 2. Pre-assembly left panel
Mount the assembled bow in the box by
pressing the bow together and snapping it
in the four holes on the side of the box. Re-
peat this step for the other side.
