Summary of Contents for Ametek Land LSP-HD
- Page 1 LSP-HD PSU Module (UL Approved) Installation Guide Publication Nº 81212 Issue 1 Language: English 19 September 2018 © Land Instruments International, 2018...
- Page 2 Observe precautions for handling electrostatic discharge sensitive devices. Equipment Operation Use of this instrument in a manner not specified by AMETEK Land may be hazardous. Read and understand the user documentation supplied before installing and operating the equipment. The safety of any system incorporating this equipment is the responsibility of the assembler.
- Page 3 This manual is provided as an aid to owners of AMETEK Land’s products and contains information proprietary to AMETEK Land. This manual may not, in whole or part, be copied, or reproduced without the expressed written consent of AMETEK Land.
-
Page 4: Table Of Contents
LSP-HD PSU Module Installation Guide UL Approved Contents INTRODUCTION SYSTEM OVERVIEW LSP-HD Cable assembly Schematic Diagram SPECIFICATION MAINTENANCE INSTALLATION DIAGRAMS Preface... -
Page 5: Introduction
Installation Guide LSP-HD PSU Module UL Approved Introduction This document provides installation details for the range LSP-HD PSU Module (UL Approved) for Landscan LSP-HD infrared linescanners. Note The equipment must be used, maintained and serviced by properly trained personnel, capable of following the procedures given in these instructions. -
Page 6: System Overview
Publication Nº 805384 2.1 LSP-HD Cable assembly It is expected that the LSP-HD PSU (UL Approve) will be used with conduit. Remove the connector from the LSP-HD cable, pass through the conduit, and connect to the instrument terminals as shown in Drawing Nº 740.077 (Section 5 of this Guide. -
Page 7: Specification
Installation Guide LSP-HD PSU Module UL Approved Specification Landscan LSP-HD Power Supply Unit (UL508A Industrial Control Panel) (Land Part Nº 812674) Operating Temp Range: CE: 0 to 50’C UL: 0 to 40’C Voltage range: ~ 100 to 240Vac Frequency range:... -
Page 8: Maintenance
LSP-HD PSU Module Installation Guide UL Approved Maintenance The body of the accessories and mountings can be cleaned by wiping with a clean cloth moistened with either water or a mild, neutral detergent. DO NOT use alcohol, chemicals or abrasive cleaning products. -
Page 9: Installation Diagrams
Installation Guide LSP-HD PSU Module UL Approved Installation Diagrams Page 5...
