ENGLISH NETBOX MS - USER INSTRUCTION Page 1. In the box 2. Instructions 3. Overview 4. Operation guide 5. Technical data 6. Dimensions... -
Page 4: In The Box
• DO NOT dismantle or modify the unit. • If in doubt, DON’T use it and contact an authorized dealer. • This unit must only be operated by adults. DO NOT allow children to tamper or play with it. User Manual - NETBOX MS V1.0 11/2019 4/20... -
Page 5: Overview
8. Art-NET (RJ45) 9. Power supply IN (powerCON TRUE1) P U S H P U S H P U S H User Manual - NETBOX MS V1.0 11/2019 5/20 P U S H P U S H P U S H... -
Page 6: Operation Guide
4. Operation guide A-Feature The NetBox MS is an ArtNet / DMX tool, it allows you to manage DMX to ArtNet and ArtNet to DMX data. The Netbox MS is provide with easy to use presets, those presets are made for non-specialist user and change all the configuration of the Netbox MS to go from Node to Merger or splitter in one step. - Page 7 >TIME BEFORE AUTOLOCK : NO AUTOLOCK >DMX OUT FRAME RATE : NORMAL >CONTRAST : 01 >EXIT >SAVE and EXIT 5 RESET / UPDATE >RESTORE DEFAULT SETTINGS ? : NO >UPDATE MODE : NO >EXIT User Manual - NETBOX MS V1.0 11/2019 7/20...
- Page 8 Merger in one step. You have 12 pre-programmed presets and 4 customisable presets. See next topic to have detailed list of those presets. 2 IP CONFIGURATION You could change IP and Mask of the Netbox MS in this Menu. Mask data could only reach 000 OR 255 values. 3 NETBOX ADVANCED CONFIGURATION This menu allows you to change all states of each DMX port of the Netbox MS.
- Page 9 >DMX OUT FRAME RATE : NORMAL By default (Normal) the Netbox MS transmit data at the same frame rate it receive it, if you have trouble with frame rate you could force it to 40 ms. Only two possibilities Normal or Slow.
- Page 11 Merge / 1rst : ARTNET 000 / 2nd : DMX 0A / HTP / NO Resend Port 02 Disable Port 03 Disable Port 04 Disable Port 05 Disable Port 06 Disable Port 07 Disable Port 08 Disable Port 0A Input / DMX Port 0B Disable User Manual - NETBOX MS V1.0 11/2019 11/20...
- Page 12 Merge / 1rst : DMX 0A / 2nd : ARTNET 000 / HTP / Resend 001 Port 02 Disable Port 03 Disable Port 04 Disable Port 05 Disable Port 06 Disable Port 07 Disable Port 08 Disable Port 0A Input / DMX Port 0B Disable User Manual - NETBOX MS V1.0 11/2019 12/20...
- Page 15 Port 03 Port 03 Port 04 Port 04 Port 05 Port 05 Port 06 Port 06 Port 07 Port 07 Port 08 Port 08 Port 0A Port 0A Port 0B Port 0B User Manual - NETBOX MS V1.0 11/2019 15/20...
- Page 17 User Manual - NETBOX MS V1.0 11/2019 17/20...
- Page 18 User Manual - NETBOX MS V1.0 11/2019 18/20...
- Page 19 User Manual - NETBOX MS V1.0 11/2019 19/20...
