- Page 1 Engine Monitoring Unit Version 1.00 LXNAV d.o.o. • Kidričeva 24, 3000 Celje, Slovenia • tel +386 592 33 400 fax +386 599 33 522 marine@lxnav.com • marine.lxnav.com Page 1 of 14...
-
Page 2: Table Of Contents
Important Notices Limited Warranty Packing Lists Technical Data Inputs 2.1.1 Analog inputs 1-4 2.1.2 Tach inputs (marked Frequency input 1-2) Outputs Engine monitor connectors NMEA2000 M12 connector pinout Sensor connectors pinout Connector kit Crimping and inserting wires Sensor connection – resistive type sensors Sensor connection –... -
Page 3: Important Notices
This Engine Monitoring Unit product is warranted to be free from defects in materials or workmanship for two years from the date of purchase. Within this period, LXNAV will, at its sole option, repair or replace any components that fail in normal use. -
Page 4: Packing Lists
1.2 Packing Lists Engine monitoring unit Installation and user’s manual Female connector kit Male connector kit Page 4 of 14... -
Page 5: Technical Data
2 Technical Data 2.1 Inputs 2.1.1 Analog inputs 1-4 Engine monitoring unit features 4 fully configurable analog inputs for: Voltage sensors: 0-5V Resistive: European, ABYC (US) and Asian standards Current output sensor 4-20mA All of the analog inputs have an internal switchable pullup resistor to 5V, thereby relieving the user of manual resistor installation. - Page 6 Page 6 of 14...
-
Page 7: Engine Monitor Connectors
3 Engine monitor connectors 3.1 NMEA2000 M12 connector pinout NMEA2000 pinout NMEA2000 pinout Male connector (pins) Female connector (sockets) CAN_L CAN_L Shield Ground CAN_H CAN_H Ground Figure 1: NMEA2000 Male connector pinout 3.2 Sensor connectors pinout As shown on the picture below, the pinout is shown from the unit side (not from the included connector kit side). -
Page 8: Connector Kit
3.3 Connector kit This chapter guides you through crimping the correct wires into the EMU connectors provided. Tools needed: Crimping pliers (recommended Engineer PA-01) Wire stripper Signal connector kit Power connector kit Figure 2: Sensor connection kit Figure 2 shows the contents of the sensor connection kit. It contains: Male and female connector housing 8 crimp contacts for each connector (blade and socket) Watertight grommets... -
Page 9: Crimping And Inserting Wires
3.4 Crimping and inserting wires Step 1: Strip wires. Stripped length should be somewhere around 5mm Step 2: Insert the crimp contact into the crimping pliers (die head 0.5mm) and gently grip the contact so that it stays put. Note that the pliers must only “grab” the grip shell on the crimp contact. - Page 10 The result should look like the picture below Step 5: Now the crimp the insulating shell (see picture above – in the green box). Insert the crimped wire into the INS portion (or >2.5mm die size of a crimping plier) and apply pressure to the crimping tool.
- Page 11 Step 6: Pull the watertight grommet over the crimped contact like shown on the picture below: Step 7: Insert the crimped contact with the watertight grommet into the appropriate connector housing. Page 11 of 14...
- Page 12 Make sure that you hear a click sound and the grommet slides all the way inside (see picture below). Repeat Step 1 through Step 7 until all of the connection are wired. Final step: Insert the end cap into the connector so that it lines up with the outer shell. Page 12 of 14...
- Page 13 Signal connector 3.5 Sensor connection – resistive type sensors Ground for Analog input 4 Ground for Analog input 3 Ground for Analog input 2 Ground for Analog input 1 Resistive type sensor Analog input 2 Analog input 3 Analog input 4 Figure 3: Resistive type sensor connection Note: Use adjacent ground connections for sensor pairs.
- Page 14 4 Revision history Date Version Description June 2019 Initial release of this manual Page 14 of 14...
