MEZZANINE GATE SYSTEM
It is the MEZZANINE GATE owner's responsibility to ensure that all
workers installing or using this system are thoroughly trained. Provide
workers with this Installation Manual and make sure they understand
its contents. Read it to them if necessary. Letting poorly trained
workers use this system can result in property damage and/or serious
injury or death to personnel.
MEZZANINE GATE System must be installed according to the
instructions outlined in this manual. Failure to do so could result in
serious injury or death to personnel!
To prevent serious injury or death, MEZZANINE GATE System must be
installed using hardware provided by Garlock Equipment Company!
To prevent serious injury or death, Installers of System must use
OSHA-approved Tie-Off device to install or remove this System.
INSTALLATION
AND OPERATION
INSTRUCTIONS
Keep this Manual with the MEZZANINE
GATE system at all times. This will allow
new users to read it before using system.
WARNING!
Distributed by
CAI Safety Systems

Advertisement

loading

Summary of Contents for CAI MEZZANINE GATE

  • Page 1 GATE system at all times. This will allow new users to read it before using system. It is the MEZZANINE GATE owner’s responsibility to ensure that all workers installing or using this system are thoroughly trained. Provide workers with this Installation Manual and make sure they understand its contents.
  • Page 2 FAILURE BY INSTALLER OR USER TO FOLLOW ANY OR ALL OF THESE INSTRUCTIONS COULD CAUSE SERIOUS INJURY OR DEATH FROM FALLS. Left Frame Outside Gate Inside Gate Right Frame Figure 1. DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 3 Standard Gate System handles 48” wide pallets and weighs 270 lbs. Consult factory for weights of custom size Gate Systems. DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 4: Installation Instructions

    Left Frame Mark holes through the Plates Drill holes in mezzanine floor. Use ½” diameter drill bit to show you where to drill holes DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 5 Garlock Equipment Co. Continue this process until all 10 bolts have been installed and Left Frame is completely secured to mezzanine floor. DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 6 Gate will rest on Vertical Post of Right Gate. Install Bumpers (155397) into the tops of the vertical posts of the Right Frame of the Mezzanine Gate. DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 7 Locking Collars (152797) and Allen Wrench. Make sure Key is still in its proper place inside key slot. Lift Inside Gate into upright position. DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 8 Inside Gate. Using drill bit supplied with Gate, drill through Rod. Insert bolt and nut supplied with Gate through this hole and secure with wrenches. DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 9 Use 3/8 x 1.25 Bolt and Lock Nut Install a Rubber Pad (424357) on each side of the Left Frame Assembly as shown to cushion the Gate Stops. DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 10 If Outer Gate is closed, use Pole Option (p/n 405980) to open it. See Pg. 11. From Ground, using Forklift, place pallet inside loading area. DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 11 Installation of Hardware for Pole Option. Install hardware as shown through the hole in square tube of Outer Gate. Pole hooks onto threaded portion of Bolt DISTRIBUTED BY CAI SAFETY SYSTEMS | Phone: (888) 246 6999 | Web: caisafety.com | Email: info@caisafety.com...
  • Page 12 Washer also from back side of Frame. Repeat this procedure on the other end of Gate system with the second Slam Stopper. Distributed by CAI Safety Systems 555 Monica Circle Corona, CA 92880 Phone: 951.272.6999 Toll-Free: 888.246.6999 Fax: 951.272.8066 info@caisafety.com...
