- Page 1 USER MANUAL HYGENIQ FOGGER HYGENIQ Lenteweg 15, 7532 RV Enschede, The Netherlands Model: HYGENIQ FOGGER +31(0)53 428 28 60 Product code: E150004 info@hygeniq.com Date: 17/09/2020 www.hygeniq.com Version: A...
-
Page 2: Preface
It also makes disinfecting surfaces much more effective when combined with the approved HYGENIQ Mist. Due to the 24V Li-ion battery and refillable tank, you can keep disinfecting for as long as you wish. Please read the user manual carefully and become familiar with the operation and maintenance procedures. -
Page 3: Table Of Contents
HYGENIQ FOGGER Content PREFACE ........................2 Packing List ........................4 Safety Instructions ...................... 5 Product Description ....................6 Setup ..........................9 Operation ........................11 Maintenance ......................133... -
Page 4: Packing List
HYGENIQ FOGGER Packing List Accessory 1 x Battery 1 x Charger 1 x Power cable The battery & charger kit is provided according to customer order requirement. It may not be in the machine package. Please contact the supplier. -
Page 5: Safety Instructions
Only use approved HYGENIQ Mist and batteries for safe use of the machine. Using other consumable items in the machine invalidates the warranty and will lead to damage of the internal parts of the machine and could possibly pose a risk to operator. -
Page 6: Product Description
HYGENIQ FOGGER Product Description... - Page 7 HYGENIQ FOGGER Item Specification Product weight 7.9KG (W/O battery) Product dimension Main body: 200x595x225mm Included harness: 300x600x315mm Tank capacity 3.5L Battery weight 1.3KG Battery voltage DC24V Duration of battery above 50 minutes Charger input voltage AC100~250 Voltage Charging time 2.5 Hours...
- Page 8 HYGENIQ FOGGER...
-
Page 9: Setup
Take off the liquid tank from the machine, and place and secure it in a upright position. Unscrew the cap off the liquid tank, and pour the approved HYGENIQ Mist into the tank. Insert the liquid tank back to the machine which should also be placed in an upright position. - Page 10 HYGENIQ FOGGER 4. Installation of the nozzle in spray handle Select the appropriate nozzle for the application. Nozzle size Droplet size Spray distance Duration (3.5L) Appliccation 0.3mm(3x) ~20um 5~6m 35minutes indoor 0.5mm ~30um 5~6m 30minutes indoor 0.8mm ~40um 5~6m 25~30minutes indoor 1.0mm...
-
Page 11: Operation
HYGENIQ FOGGER Operation 1. Place the machine body on the table, and then place the spray nozzle on the lower hook. 2. Place the machine on the back and adjust the straps and the belt to for an optimal/comfortable operating position. - Page 12 HYGENIQ FOGGER 4. Additional information: For larger spaces / rooms one should fog the higher part of the room. The Mist will agglomerate with the particles present where the antimicrobial effect will do its job. Secondary effect is that the particles get heavier and via laws of Gravity descend.
-
Page 13: Maintenance
5. Spray nozzles need to be stored in the small tool box, together with the screw driver. The tool box can be hooked on to the backpack harness spring hook (3 nozzles in the tool box and 1 in the spray handle). 6. If there is any issue with your fogger please contact HYGENIQ.
