Savannah STOKER v3 Instruction Manual

For the wood pellet grill

Advertisement

Quick Links

SAVANNAH STOKER v3 INSTRUCTION MANUAL
SAVANNAH STOKER v3 TEMPERATURE CONTROLLER
Thank-you for purchasing the Savannah Stoker Pellet Grill Control
System. The Savannah Stoker is a PID based artificial intelligent
temperature controller that allows you to control your wood pellet grill or
smoker with "simplicity but infinite control".
FEATURES
• Set the desired cooking/smoking temperature from 160°- 550°F
or the max temperature your grill can reach in 1° increments.
• Typical temperature swings are 5-10°F when cooking above
250°F and 10-15°F when smoking below 225°F.
• Hardwired permanent installed temperature sensor, compatible
with the OEM temperature sensor.
• Grill cool-down cycle. The fan runs until the grill temperature
drops below 130°F.
• 3 Speed Fan selectable by the user. High for cooking; Medium
for Smoking, and Extra Low for cold smoking.
• Auger Bypass. Press a button and the auger runs 100% to get
to grilling temperatures faster.
• Optional interface with the STOKER® Power Draft System from
Rocks Bar-B-Que. Add the features of the STOKER like remote
temperature control and monitoring from a computer or
Smartphone or graph the cook with StokerLog running on a PC.
Requires an optional cable. The STOKER is available from
http://www.rocksbarbque.com.
SPECIFICATIONS
The Savannah Stoker is a direct replacement temperature controller for
most Traeger Wood Pellet Grills but it will not fit in the Traeger Junior or the
PTG. It will also control most smokers made by Blaz'n Grills Works Wood
Pellet Grills, Royall Wood Pellet Grills (except the tailgater), Camp Chef
Pellet Grill & Smoker and Smoke Daddy Pellet Pro. The Savannah Stoker
maybe compatible with other wood pellet grills but may requiring
modifications to the grill or wiring connectors.
Compatable with the OEM RTD and with K-Type
Input type
Thermocouple hardwired to the back of the controller
Accuracy
0.75%Full scale or ±2.2 ºC for K-Type thermocouple
Response Time
≤ 1.0s (when FILt=0)
Display Resolution
1°F
Automatic Control using PID based algorithims
Control Modes
Manual Control
STOKER® Control (optional interconnect cable required)
Fan Output
Zero crossing SSR, 85-240VAC/3A
Auger Output
Zero crossing SSR, 100-240VAC/3A
Igniter Output
Zero crossing SSR, 100-240VAC/10A
Power supply
100-240VAC 50-60Hz
Power consumption
300 Watts at startup, 60 Watts normal operation
Ambient temperature
0~50ºC, 32~122ºF
Fuse
5x20mm 4A 250V Cooper Bussmann #S500-4-R or equal
2015.01 Copyright © Sound Solutions, LLC. All Rights Reserved. Find us on Facebook.com/SavannahStoker , Pelletheads.com and LetsTalkBBQ.com
FOR THE WOOD PELLET GRILL
WARNING Electrical Shock Risk!
Electrical power is present to the controller
anytime the grill is connected to an AC Power
Source. Before attempting to remove or install
the controller the grill must be disconnected
from the AC Power Source. Failure to do so
could result in personal injury from electrical
shock and/or damage to the controller. When
not in use the grill should be disconnected from
the AC Power Source. The controller should be
protected from moisture at all times. It is highly
recommended the grill be connected to a GFCI
outlet or other protected circuit when in use.
WARRANTY
Sound Solutions, LLC, warrants to the original purchaser the controller
will be free from defects in material and workmanship under normal use
for a period of one (1) year from the date of original purchase. The
temperature sensors and the STOKER® interface cable are warranted
for a period of ninety (90) days.
The warranty shall not apply: (i) to any controller subjected to accident,
misuse, neglect, water damage, alteration, acts of God, improper
handling, improper transport, improper storage, improper use or
application, improper installation, improper testing or unauthorized
repair; or (ii) to cosmetic problems or defects that result from normal
wear and tear under ordinary use and do not affect the performance or
use of the product. If the controller develops a covered defect during
the warranty period, Sound Solutions, LLC, will, at its option, either
repair or replace the controller, the temperature sensor or the STOKER
interface cable at no charge, provided that the controller and/or
temperature sensor are returned to Sound Solutions, LLC, during the
warranty period
To obtain warranty service contact Sound Solutions for an RMA # by
phone: 1-252-746-3367 or email:
Return the component(s) along with a copy of the sales receipt to:
Sound Solutions, LLC
4205 Holly Street
Ayden, NC 28513
THE ABOVE STATED WARRANTY IS EXCLUSIVE AND REPLACES
ALL OTHER WARRANTIES EXPRESSED OR IMPLIED INCLUDING
THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. SOUND SOLUTIONS, LLC WILL NOT BE HELD LIABLE
FOR ANY OTHER DAMAGES OR LOSS INCLUDING INCIDENTAL
OR CONSEQUENTIAL DAMAGES AND LOSS OF PROFITS OR
REVENUES FROM WHATEVER CAUSE, INCLUDING BREACH OF
WARRANTY OR NEGLIGENCE.
