Aegis Air Spoiler Quick Start Manual

Installation of the Universal Mount

Congratulations on purchasing your own Aegis Air Spoiler. We greatly appreciate your business and are excited that
you have taken the next step in truly "Changing the Ride." We have designed this system to have the capability to
fit multiple widths and roll bar diameters for most machines on the market today. The Universal system is highly
durable and offers numerous options for adjustments for multiple applications. This system has been tested in
very strong windy conditions and freeway speeds. We do however, recommend that either the spoiler is tilted
down to prevent resistance or that the spoiler is removed with open trailering and freeway speeds. This can be
done simply with the removal of two bolts and a quick removal of the spoiler. The support arms can be lifted off
and stored for your travel.
Please remove all items from their individual boxes and make sure there is no damage in shipment. Any damage
should be reported to Aegis immediately. We recommend that you read through the instructions first and view
installation videos to understand the basic concepts and functionality of your system.
1.Install the arc unions and mount them to the spoiler with the included ¼"x ¾" Truss Head
screws and ¼" nylon lock nuts. Position the spoiler facing down so you can view the underneath portion of the
spoiler. Locate the three designated holes and place the curved arc unions on top. The circular keyhole union of
the arc will be placed facing the lower backside of the spoiler. Place the truss head screws through from the top
side of the spoiler so the finished heads of the screws will be displayed on the facing outside of the spoiler when
mounted. Secure with lock nuts in all six holes (3 on each side) and be very cautious to not tighten too tight!
These bolts are actually designed to have the tops pop off in case of limb contact in-order to prevent major
structural damage to your air system. For this reason, there is one extra nut that is included in the hardware
package.
2.It is advised to lay out your Aegis Air Spoiler in a manner that represents the top photo. This will give you
further visual clues to how the system should look upon completion. You can now start to mount the adjoining
support arms that have a twist in the top. You will mount these support arms by installing the 3/8"
x 1 ½'' carriage bolt and nylon lock nut in the top hole of the support arm and through the circular keyhole union
of the arc union. Do not over tighten as you will need to adjust and rotate while mounting this on
your UTV for final angle adjustment. When mounting the support arms to the arc union, you will want to mount
