KIFCO Water-Reel B140G Operator's Manual

Hide thumbs Also See for Water-Reel B140G:
Table of Contents

Advertisement

Quick Links

E140G
B140G
OPERATOR'S MANUAL
Models B140G & E140G
Serial Number 510,721 +
700 South Schrader Avenue
P.O. Box 290
Havana, IL 62644
Phone (309)543-4425
Fax (309)543-4945
www.kifco.com
193-0261-1
®
Revised on 10/16/17
Copyright © November 30 , 2015 by Kifco
Inc.
