Instruction Manual for

SEPAREL PF Modules

Before using the SEPAREL® PF series, be sure to read this instruction manual to ensure safe and

proper use.

DIC will not have any liability to a customer or end user in connection with any costs and damages

arising directly or indirectly from any defective modules.

We are not responsible for any usage, installation, or any other handling done by the customer.

The module must be used, installed, and handled responsibly by the customer.

Application Materials Product Division

Hollow Fiber Membrane Module

PF (Internal Perfusion Flow) Series

PF-001D Series

PF-004D Series

EF-015

EF-030

PF-001D

PF-004D

Series

PF-015

Ver. 1. 2

June 3, 2016

PF-030

www.separel.com/en

Table of Contents

Need help?

Do you have a question about the SEPAREL PF Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DIC SEPAREL PF Series

Page 1 Before using the SEPAREL® PF series, be sure to read this instruction manual to ensure safe and proper use. DIC will not have any liability to a customer or end user in connection with any costs and damages arising directly or indirectly from any defective modules.
Page 2 Although the content of this instruction manual is based on reliable testing and measurement results, no guarantees are provided for its accuracy. DIC does not have any responsibility for anything described or not described in this manual. The details of this instruction manual may be modified for improved reliability of the SEPAREL®...
Page 3 INSTRUCTION MANUAL Warranty, Warranty Period Warranty At the time of delivery, DIC warrants that the Separel module will be free from defects in material and workmanship and meet the specifications supplied to the customer by DIC. Warranty Period The following Warranty Period is applied only if customer use of the Separel module is in accordance with the instructions contained in this manual, the specification sheet, any applicable Cleaning Guides and the Warranty Statement.
Page 4 During the applicable warranty period as specified in the Warranty Statement, any defective module will be replaced free of charge by DIC in cases where a defect is found under normal use in accordance with this instruction manual and under use and storage conditions specified in the specification sheet and Warranty Statement.
Page 5: Table Of Contents
INSTRUCTION MANUAL Contents 1. General Precautions P. 6 2. Upon Receipt P. 6 3. Installation P. 7 4. Start-Up P. 11 5. Shutoff and Storage P. 12 6. Restart P. 12 7. Maintenance P. 13 Reference Data 1. Basic Principles of Degassing P.14 2.
Page 6: General Precautions
1-10. Refer to the cleaning guidelines before cleaning with. In cases where liquid that has not been deemed compatible by DIC is used, no warranty will apply to the product. 2. UPON RECEIPT 2-1.
Page 7: Installation
INSTRUCTION MANUAL 3. Installation 3-1. Place of Installation: Install SEPAREL in accordance with conditions specified in the specification sheet, No exposure to direct sunlight No physical shock or shaking No contact with dust, moisture, corrosive gas, or liquid Easy access for maintenance, inspection, repair, and replacement 3-2.
Page 8 If you have any questions, please contact DIC Corporation. In regard to the shell side, refer to the table below:...
Page 9 There is a possibility that particles are generated by the SEPAREL module. To prevent a problem with such particle occurrence, install a filter behind the module. The most suitable filtration size depends on your use conditions. For more details, please contact DIC. Note that back pressure to the SEPAREL module should be avoided.
Page 10 INSTRUCTION MANUAL 3. Installation Example of Installation Liquid OUT Filter SEPAREL Degassing Module Pressure Vacuum Gauge Valve Pump Trap Filter Liquid Delivery Pump Liquid IN It is possible particles may be present and pass through the module. If there is any trouble with such particles, please install a filter and filter the liquids after they exit the SEPAREL module, but before application.
Page 11: Start-Up
4-3. Do not flow oxidizing agents, such as highly concentrated chlorine water and ozone water, strong acids, strong bases, organic solvents, oil, or any other liquid which has not been confirmed as compatible by DIC. The warranty will not apply if liquid, which has not been confirmed as compatible by DIC, is used.
Page 12: Shutoff And Storage
INSTRUCTION MANUAL 5. Shutoff and Storage 5-1. Shutdown Procedure (1) Open the leak valve of the vacuum exhaust pipe. Upon confirming that the vacuum has been released, shut down the vacuum pump. (2) Close the valve on the liquid supply side then close the valve on the treated liquid side. 5-2.
Page 13: Maintenance
It is necessary to have regular checkups to maintain the performance of the degasification module. Check the items described in the following table and record the results. Frequency Items of Measure Guideline for Set Value Item to Check Measurement More than once a Water Supply Value Design value Make sure that it does not exceed the maximum water...
Page 14: Basic Principles Of Degassing
INSTRUCTION MANUAL REFRENCE DATA 1: Basic Principles of Degassing Liquid OUT Sealing Resin Vacuum Image of Hollow Fiber Cross-section Liquid Hollow Fibers Vacuum Hollow Fiber Sealing Resin Membrane Vacuum By vacuuming inside the hollow fiber, only gas can pass through hollow fiber membrane and is removed from liquid.
Page 15: Vacuum Pressure Degree
INSTRUCTION MANUAL REFRENCE DATA 2: Vacuum Pressure Degree Note that the vacuum pressure degree in our data sheet is mainly indicated by absolute pressure, not by gauge pressure. 1 atm 0.65 atm 0.35 atm Absolute =101.3 kPa(abs) = 65.8 kPa(abs) = 35.5 kPa(abs) = 1013 mbar(abs) = 658 mbar(abs)
Page 16: Setting Value Of Vacuum Pressure Degree
However, if the vacuum pressure degree is too strong yet close to perfect pressure, liquid may evaporate and penetrate through the membrane. As a result, the composition of liquids may change. Therefore, DIC recommends following the exact vacuum pressure degree.
Page 17 On the other hand, if the flow rate is too low, degassing cannot be efficient. Therefore, DIC supplies recommended flow ranges in the table below. The recommended flow range below was calculated when using water. In the case of high viscosity liquid, a suitable flow range will be more narrow.
Page 18: Inner Volume
INSTRUCTION MANUAL REFRENCE DATA 5: Inner Volume The above values are for reference and are not guaranteed values. Actual volume may differ by connection type. Application Materials Product Division...
Page 19: Troubleshooting
If it is not, redo the piping. - Remove the vacuum pumping line from the degasification module. If the water leak exceeds 20ml/min, contact DIC. - Since flocculated water tends to collect easily, have the vacuum manifold insulated.
Page 20 - Send the sweep gas until no water droplets are found at the gas exit port. - If the above treatments are not successful, contact the DIC Corporation. Find the water-blocked area inside the vacuum pipe. - If the vacuum line is connected to the vacuum system and...
Page 21 The central seal nut is loose. Confirm that plumbing is correct. the hollow fiber. If problems persist, please contact DIC. The O-ring on the lumen side of the Same steps as above. degasification module is not attached.
