Summary of Contents for chinesport AV3 Series
- Page 1 CHINESPORT SPA Via Croazia, 2 33100 – Udine – IT www.chinesport.com A V 3 Standing Frames User and maintenance manual REV. 1.2 (06/2018) .docx AV3 - User Manual rev.1.2 - EN 1/47...
- Page 2 CHINESPORT Spa – ITALIA 2/47 AV3 - User Manual rev.1.2 - EN.docx...
-
Page 3: Table Of Contents
CHINESPORT Spa – ITALIA GENERAL INFORMATION 1.1 P URPOSE CONTENT AND RECIPIENTS OF THESE INSTRUCTIONS 1.2 M ANUFACTURER 1.3 I NTENDED USE AND EQUIPMENT DESCRIPTION 1.4 B IOCOMPATIBILITY 1.5 P RODUCT DESCRIPTION 1.6 S TORAGE AND OPERATING ENVIRONMENT 1.7 S... -
Page 4: General Information
(SPECIAL WARNINGS AND USE RESTRICTIONS). For every additional information, observation or requests for clarification you can contact the reseller or the company Chinesport S.p.A. 1.1 Purpose, content and recipients of these instructions This manual is intended to provide the necessary information to permit a proper use of the equipment and to be able to use it independently and safely. -
Page 5: Biocompatibility
Do not charge batteries if they are frozen or have a temperature higher than 45°C Products insights Further documentation can be found on our website www.chinesport.com You can download declaration of conformity and other product documents in their latest version and in colour format directly from website. -
Page 6: Symbols
CHINESPORT Spa – ITALIA 1. Switch off the equipment by setting to “O” position the thermomagnetic switch located on the tray (see “Stop functions” – electric models only). 2. Recharge batteries, if not used at all, at least every six months (see “Recharging the equipment’s batteries”... -
Page 7: Special Warnings And Use Restrictions
CHINESPORT Spa – ITALIA Expected product life 10 years Protection degree IP21. The IP Code classifies and rates the degree of protection provided against intrusion (body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. -
Page 8: Use Indication
CHINESPORT Spa – ITALIA USE INDICATION 3.1 Indications AV3 standing frame is suitable for people with disabilities or spinal cord injuries, paraplegia, multiple sclerosis, Parkinson's disease or muscular pathologies, muscular dystrophies and those who are in difficulty in actions that require lifting, for example elderly people. -
Page 9: Unsafe Use
CHINESPORT Spa – ITALIA Diagnosis Monitoring Measurement Sport training Outdoor moving 3.5 Unsafe use Do not use AV3 (electrical versions) In combination with other devices that emits ionizing radiation (e.g. radiotherapy, nuclear medicine, etc.) ... - Page 10 CHINESPORT Spa – ITALIA Without knee support. Indicated A V 3 _ _ 0 _ _ _ _ _ _ for special customizations. KNEE Adjustable in depth and width. A V 3 _ _ 1 _ _ _ _ _ _ SUPPORT Pos.
- Page 11 CHINESPORT Spa – ITALIA Polyethylene service tray – large A V 3 _ _ _ _ _ _ _ _ E size. Plexiglass service tray - large size. A V 3 _ _ _ _ _ _ _ _ G .docx...
- Page 12 CHINESPORT Spa – ITALIA 12/47 AV3 - User Manual rev.1.2 - EN.docx...
-
Page 13: Latest Improvements
CHINESPORT Spa – ITALIA 4.1 Latest Improvements Chinesport constantly improves his product trying to implement all the changes dictated by the market and by user feedback as well as constant post marketing surveillance in order to keep safety and conformity to the most recent medical devices regulations, testing and deploying the most recent available technology. -
Page 14: Standard Accessories
CHINESPORT Spa – ITALIA If you have a less recent version of the AV3 device, you can contact your local distributor or manufacturer (Chinesport) to have more information on the possibility to upgrade your product. 4.2 Standard accessories Here the list for the standard accessories available for the AV3 device. -
Page 15: Unpacking
CHINESPORT Spa – ITALIA SERVICE TRAY Hand grip Hand-wrist grip Coloured padding for medium service tray Coloured padding for large service tray. Large ABS service tray Medium ABS tray The W option on some accessories refers to the possibility of having a different color compared to the standard black color. -
Page 16: Switching Off
CHINESPORT Spa – ITALIA TURN ON Switch to “1” the main INDEPENDENT switch placed under the MOBILITY service tray A V 3 _ _ _ _ _ _ _ _ AFFECTED MODELS Push the power button to turn ON the green light (JA) 5.2 Switching off... - Page 17 CHINESPORT Spa – ITALIA STOP By stopping to press the A V 3 _ _ _ _ 3 _ _ _ _ VERTICALIZATION blue button PA and/or PB AFFECTED MODELS on the hand switch. VERTICALIZATION A safety sensor (SA, yellow...
-
Page 18: Security Locking And Unlocking Of Joystick
CHINESPORT Spa – ITALIA STOP MOVING By releasing the joystick AROUND knob (JM) By pushing the off button to A V 3 _ _ _ _ _ _ _ _ turn the green light off (JA) AFFECTED MODELS 5.3 Security locking and unlocking of Joystick Sometimes is useful to lock the joystick functions for security reasons (e.g. -
Page 19: Initial Settings
CHINESPORT Spa – ITALIA 1) Push the on button (JA). The LEDs (JE) in the odd positions (1, 3, 5) will blink shortly and the use of the device will not be possible 2) Push twice the horn button (JB) within 10 seconds. -
Page 20: Normal Use Of The Device
CHINESPORT Spa – ITALIA Item “A” allows to open and close the clamp in order to move the Joystick support and reach the required position on the table or on the handle. Once the positioning has been reached clamp the support with the knob “A”. The support must be firmly clamped in order to guarantee a good stability of the joystick. - Page 21 CHINESPORT Spa – ITALIA BEFORE EACH USE PLEASE CHECK THAT ALL THE REGULATION ITEMS ARE PROPERLY LOCKED AND BATTERY ARE FULLY CHARGED Warning Please read carefully the instructions to find the correct use according to the owned device configuration. 5.5.1 Height Adjustment Before transfer to the device, make sure that the height of the structure is already in the correct position and all adjustments are done.
- Page 22 CHINESPORT Spa – ITALIA In this case the height adjustment isn’t performed very often, so can be executed when the device is adjusted for the first time and when little adaptations are necessary. Pull the height adjustment lever to unlock the gas...
- Page 23 CHINESPORT Spa – ITALIA First steps 1- Lock the devices wheels by pushing down the levers on the rear wheels and front wheels (if present) 2- Lock the wheelchair wheels (see wheelchair user manual) 3- Put the feet on the...
- Page 24 CHINESPORT Spa – ITALIA harness support. When ready: Pull the Verticalization lever to unlock the gas spring and lift. The gas spring will help to lift partially reducing the weight of the body. The lifting phase could be performed in various step...
- Page 25 CHINESPORT Spa – ITALIA Warning A WRONG SETUP OF THE SERVICE TRAY COULD GENERATE COMPRESSION ON THE USER WHEN STANDING UP PLEASE CHECK THE CONDITIONS AND REACTIONS OF THE USE WHILE THE LIFTING IS ON A WRONG SETUP OF THE KNEE SUPPORTS CAN STRESS...
- Page 26 CHINESPORT Spa – ITALIA 5.5.3 Moving Around When the patient is safely positioned on the device, it can be moved around. There are two main options based on the models: First steps Before moving around remember to unlock the device wheels by pulling up...
- Page 27 CHINESPORT Spa – ITALIA In this case there are electric motors for move the device around. 1) Turn on the joystick by pushing the on button (JA) 2) The control box turn on and the LED strip (JE) indicates the level of battery charge.
-
Page 28: Emergency Lowering
CHINESPORT Spa – ITALIA 1) Turn on the device using the Main Switch. The Main Switch must be on “I” position to activate the recharge. 2) Plug the battery charger XLR Plug (JP) on the Joystick XLR connector (JN right side) and connect it to the power network. -
Page 29: Adjustments
CHINESPORT Spa – ITALIA 1) Turn on the device using the Main Switch. The Main Switch must be on “I” position to activate the recharge. 2) Connect the battery charger on the plug placed on the front of the device and connect it to the power network. - Page 30 CHINESPORT Spa – ITALIA 1) Reach / move close to a support surface (chair, wheelchair, sofa, etc.) in a way that the patient support is faced towards this support 2) The user MUST lay on the service tray with his own...
- Page 31 CHINESPORT Spa – ITALIA WOODEN DEPTH Adjustment A V 3 _ 1 _ _ _ _ _ _ _ FOOT-PLATES AFFECTED MODELS A WRONG SETUP OF THE FOOT PLATES COULD GENERATE COMPRESSION ON THE USER WHEN STANDING UP Warning 1) Loosen the screws (S)
- Page 32 CHINESPORT Spa – ITALIA 1) Push the lever on the side handle. 2) Grab the side handle at the same time and move to the desired height. 3) Release the lever to block the device at the expected height HEIGHT adjustment...
- Page 33 CHINESPORT Spa – ITALIA 1) Loosen the fixing handle 2) Reach the desired position 3) Tighten the fixing handle Fixing handle SIDE HANDLES WIDTH adjustment A V 3 _ _ _ _ _ _ AFFECTED MODELS 1) Loosen the respective T-...
-
Page 34: Accessories Adjustments
CHINESPORT Spa – ITALIA SERVICE TRAY A V 3 _ _ _ _ _ _ _ TILT adjustment AFFECTED MODELS BEFORE THE USE CHECK THAT THE PINS ARE CORRECTLY LOCKED AND THE T-KNOBS ARE WELL TIGHTENED WHEN ADJUSTING THE DEPTH OF THE TABLE, CHECK THAT IT WON’T... -
Page 35: Maintenance
CHINESPORT Spa – ITALIA 5.8 Accessories adjustments Here are summarized adjustments of the accessories. Please refer also on the dedicated and detailed manual of the single accessory. ADJUSTABLE WIDTH adjustment HEELRESTS Loosen the knob A C 0 6 8 6 ... -
Page 36: Extraordinary Maintenance
CHINESPORT Spa – ITALIA ADJUSTABLE LATERAL/BACK DEPTH adjustment SUPPORTS 1) Loosen the knobs A C 0 7 0 3 2) Adjust the lateral supports depth 3) Tighten the knobs ANTI-CRUSHING DEPTH adjustment SAFETY SYSTEM 1) Push the blue button on the pin... -
Page 37: Troubleshooting
TROUBLESHOOTING TABLE, CONTACT THE CHINESPORT SERVICE CENTRE Warning 6.2 Spare parts The spare parts list is provided directly by Chinesport S.p.a. on request and includes order codes and price list 6.3 Non routine maintenance Non routine maintenance is required when devices fail to work as intended use. If for some reason or for some event (e.g.: after a device fail apart, liquid spills, violent... -
Page 38: Taking Care Of Parts And Cleaning
CHINESPORT Spa – ITALIA TROUBLESHOOTING If you find a problem try to follow the troubleshooting chart below. If none of the proposed solutions works, please contact your local distributor or Chinesport customer service. PROBLEM CAUSE SOLUTION Unplug the battery charger, Main switch is set to “0”,... -
Page 39: Cleaning
SERIAL NUMBER Remember: Equipment to be repaired at Chinesport’s premises must bear the “AUTHORIZATION NUMBER” on the package. This identification number, which must be obtained from our Customer Service Department, helps reduce waiting times and improves service quality. -
Page 40: Batteries Notes
CHINESPORT Spa – ITALIA CLEANING OF ELECTRICAL EQUIPMENT MUST BE CARRIED OUT UNPLUGGED FROM THE POWER GRID AND WITH MAIN SWITCH SET TO “0” Warning The structure of the equipment is of metal and plastic. Resistance and easy maintenance make it particularly suitable for use in hospitals, nursing homes, etc. -
Page 41: Electromagnetic Compatibility Informations
CHINESPORT Spa – ITALIA DO NOT USE: ALCOHOL-BASED GLASSES CLEANING PRODUCTS, ABRASIVE COMPOUNDS OR SOLVENTS SUCH AS ACETONE, GASOLINE, BENZENE, ALCOHOL, CARBON TETRACHLORIDE OR SIMILAR PRODUCTS. THESE CAN SCRATCH THE SURFACE CAUSING SMALL CRACKS BATTERIES NOTES These indications are only for models that have internal batteries. - Page 42 CHINESPORT Spa – ITALIA We suggest to place the labels in a comfortable place in order to consult the charging instructions in an easy way. CHARGING INSTRUCTIONS SET THE WHITE POWER BUTTON ON “I” CONNECT THE BATTERY CHARGER TO THE POWER SUPPLY AND...
-
Page 43: Warranty
CHINESPORT Spa – ITALIA covered with synthetic material, the relative humidity must be at least 30%. Fast Transient / Network power quality must be in Electric Burst Not Applicable accordance with typical commercial or IEC 61000-4-4 hospital applications. Network power quality must be in... -
Page 44: Disposal Of Electrical Or Electronic Equipment
WARRANTY GENERAL AFTER-SALES SERVICE CONDITIONS FOR CHINESPORT ITEMS The warranty shall be valid for a period of 24 months from the date of delivery. The warranty does not cover consumable items, rechargeable batteries, and generally all materials subject to wear, breakdowns caused by knocks, falls, misuse or improper use, accidental events and damage while being transported. -
Page 45: Maintenance Record Sheet
CHINESPORT Spa – ITALIA Products are to be shipped in their original packaging, carriage paid. A fiscal document (bill of sale, purchase invoice or cash receipt) is required to make a warranty claim; the purchase date indicated must fall within the warranty time period. - Page 46 CHINESPORT Spa – ITALIA MAINTENANCE RECORD SHEET DATE OF INSTALLATION SERIAL NUMBER EQUIPMENT ACCESSORIES OPERATIONS CARRIED OUT 46/47 AV3 - User Manual rev.1.2 - EN.docx...
- Page 47 CHINESPORT Spa – ITALIA PAGE LEFT BLANK .docx AV3 - User Manual rev.1.2 - EN 47/47...
