Summary of Contents for TVT Digital Smart Management Terminal

  • Page 1 Smart Management Terminal User Manual Please read this manual carefully before operating the unit and keep it for further reference...
  • Page 2 Notes  Please read this user manual carefully to ensure that you can use the device correctly and safely.  There may be several technically incorrect places or printing errors in this manual. The updates will be added into the new version of this manual. The contents of this manual are subject to change without notice.
  • Page 3 manual and the applicable law, the later prevails.  The storage of the personal data depends on the capacity of the storage devices the users use and all data stored in the device shall be handled by themselves. Our company shall not be responsible for the data loss.
  • Page 4 regulations part 15 subpart B. These limits are designed to provide reasonable protection against harmful interference. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communication.

  • Page 5: Table Of Contents

    SMT User Manual Table of Contents Table of Contents Introduction ........................1 1.1 Summary ........................1 1.2 Features ......................... 1 1.3 Front Panel Descriptions ....................4 1.4 Rear Panel Descriptions ....................5 1.5 Connections ........................8 Basic Operation Guide ....................10 2.1 Startup &Shutdown .....................
  • Page 6 SMT User Manual Table of Contents Statistics ........................49 9.1 Real-Time Statistics ....................49 9.2 Historical Statistics ...................... 49 Record& Disk Management ..................51 10.1 Record Configuration ....................51 10.1.1 Mode Configuration ..................51 10.1.2 Advanced Configuration ................. 53 10.2 Encode Parameters Settings ..................53 10.3 Schedule Settings ......................
  • Page 7 SMT User Manual Table of Contents 12.7.3 Display ......................82 12.7.4 Buzzer ......................83 12.7.5 APP Push Message ..................83 12.8 Manual Alarm......................83 12.9 View Alarm Status ..................... 84 Account & Permission Management ................. 86 13.1 Account Management ....................86 13.1.1 Add User......................
  • Page 8 SMT User Manual Table of Contents 15.4.1 Live View via Web Client ................109 15.4.2 People Management via Web Client ............. 111 15.4.3 Attendance Management via Web Client ............111 15.4.4 Face Greeting ....................112 15.4.5 Playback via Web Client ................113 15.4.6 Search and Backup via Web Client ...............

  • Page 9: Introduction

    1 Introduction 1.1 Summary The smart management terminal (SMT) series is specially designed and developed for AI application management, like body temperature measurement management, time attendance, access control, etc. It supports real-time face capture display, temperature display and alarm out, statistics, video preview, search and playback.
  • Page 10 SMT User Manual Introduction  Statistics of the people information, including staff, allow list, block list, VIP, stranger and staff counts  Statistics of people entry and exiting in recent 24 hours or 7 days  Support smart temperature screening viewing mode (only thermal camera channel available) ...
  • Page 11 SMT User Manual Introduction 1/32 times of the normal speed) and 30s’ addition or reduction to current playing time Record Backup  Support record to be backed up through USB (U disk, mobile HDD)  Support record to be backed up by time/event/image search ...

  • Page 12: Front Panel Descriptions

    SMT User Manual Introduction controller and the mouse  Setting interfaces can be switched to one another conveniently by clicking the main menus on the top of the setting interfaces  Support SMT information viewing including basic, camera status, alarm status, record status, network status, disk and backup status ...

  • Page 13: Rear Panel Descriptions

    SMT User Manual Introduction Name Descriptions Manually record Play/Pause Speed down Speed up Input digital number and select camera 0/-- Input number 0, the number above 10 Direction Key Change direction Multi-Screen Switch Change the screen mode Enter Confirm selection To connect external USB device like USB mouse or USB flash 1.4 Rear Panel Descriptions...
  • Page 14 SMT User Manual Introduction Name Descriptions RS485 Connect to a keyboard. A is TX+; B is TX- interface RS485 Connectors for speed dome. Y is TX+, Z is TX- interface (This interface of some models is unavailable.) ALARM OUT Relay output; connect to external alarm ALARM IN Alarm inputs for connecting sensors Grounding...
  • Page 15 SMT User Manual Introduction Name Descriptions Network port Connect to monitor HDMI Connect to 1920× 1080 high definition display device USB3.0 interface, connect USB storage device or USB mouse Audio input; connect to audio input device, like AUDIO IN microphone, pickup, etc. AUDIO OUT Audio output;...

  • Page 16: Connections

    SMT User Manual Introduction Name Descriptions microphone, pickup, etc. AUDIO OUT Audio output; connect to sound box 1.5 Connections  Video Connections Video Output: Supports VGA/HDMI video output. You can connect to monitor through these video output interfaces simultaneously or independently. ...
  • Page 17 SMT User Manual Introduction Alarm Output: The way to connect alarm output device: Pull out the green terminal blocks and loosen the screws in the alarm-out port. Then insert the signal wires of the alarm output devices into the port of NO and COM separately. Finally, tighten the screws.

  • Page 18: Basic Operation Guide

    SMT User Manual Basic Operation Guide 2 Basic Operation Guide 2.1 Startup &Shutdown Please make sure all the connections are done properly before you power on the unit. Proper startup and shutdown are crucial to extending the life of your device. 2.1.1 Startup ①...
  • Page 19 SMT User Manual Basic Operation Guide Button Function Power Button Switch off—to stop the device Record Button To start recording -/-- /0-9 Input number or choose camera Fn1 Button Unavailable temporarily Multi Button To choose multi screen display mode Next Button To switch the live image To go to sequence view mode Audio...

  • Page 20: Mouse Control

    SMT User Manual Basic Operation Guide Button Function Record manually Search To enter search mode MEUN To enter menu Exit To exit the current interface ENTER To confirm the choice or setup Direction button To move cursor in setup ZOOM To zoom in No function temporarily To control playback.

  • Page 21: Common Button Operation

    SMT User Manual Basic Operation Guide The system includes two input boxes. Refer to the above pictures. The left box is the number input box and the right box is the input box which provides inputs of numbers, letters and punctuation characters.

  • Page 22: Wizard & Main Interface

    SMT User Manual Wizard & Main Interface 3 Wizard & Main Interface 3.1 Startup Wizard The disk icons will be shown on the top of the startup interface. You can view the number and status of each disk quickly and conveniently through these icons ( : no disk;...
  • Page 23 SMT User Manual Wizard & Main Interface Enable pattern lock and click ―Edit‖ to set the pattern lock. Click ―Next‖ to set questions and answers for password security of admin. If you forget the password, please refer to Q4 in Appendix A FAQ for details. Click ―Next‖...
  • Page 24 SMT User Manual Wizard & Main Interface Note:  If you use the SMT with the PoE network ports, the online state of the internal Ethernet port will be shown on the interface. Refer to the picture below. Please refer to 14.1.1 TCP/IP Configuration for detail introduction of the internal Ethernet port.
  • Page 25 SMT User Manual Wizard & Main Interface Click to edit the searched IP camera as shown on the below left. Enter the new IP address, subnet mask, gateway, username and the password of the camera. Click ―OK‖ to save the settings. Click to edit the added camera as shown on the above right.

  • Page 26: Main Interface

    SMT User Manual Wizard & Main Interface Manual: Set the ―Sensor Record‖, ―Motion Record‖ and ―Schedule Record‖ of each camera. Click ―OK‖ to save the settings. See 10.1.1 Mode Configurationfor details. ⑧ QRCode. Enable the NAT function in the interface or set it in the network configuration after exiting the wizard (please refer to 14.1.8 NAT Configuration for details).
  • Page 27 SMT User Manual Wizard & Main Interface The buttons in area ① are introduced in the table below. Button Meaning Start button. Click it to pop up area ③. Full screen button. Click it to show full screen; click it again to exit the full screen.

  • Page 28: Setup Panel

    SMT User Manual Wizard & Main Interface Note: The buttons displayed in the live display interface may be different for different models. The above picture is for reference only. The real product shall prevail. Introduction of area②: Icon / Button Meaning It shows the current login user.

  • Page 29: Main Functions

    SMT User Manual Wizard & Main Interface Here we take Camera module as an example. The Camera module provides convenient links such as ―Add Camera‖, ―Edit Camera‖, ―Image Settings‖, ―OSD Settings‖ and ―Motion Settings‖. Click Camera to go to the camera management interface as shown below. Click the main menus on the top of the camera management interface to go to corresponding interfaces.
  • Page 30 SMT User Manual Wizard & Main Interface Management for details) and Permission Management (see 13.3 Permission Managementfor details) and so on.  System The module covers the functions such as Basic Configuration (see14.2 Basic Configuration for details), Device Information (see14.8 View System Information for details), Log Information (see 14.7 View Log for details) and Configuration File Import &Export (see 14.5 Backup and Restore for details) and so on.

  • Page 31: Camera Management

    SMT User Manual Camera Management 4 Camera Management 4.1 Add/Edit Camera 4.1.1 Add Camera The network of the SMT should be set before adding IP camera (see 14.1.1 TCP/IP Configuration for details). Refer to the pictures below. Click Add Camera in the setup panel or in the top right corner of the preview window to pop up the ―Add Camera‖...
  • Page 32 SMT User Manual Camera Management  Add Manually 1. Select the terminal type according to the device you want to add. IP Panel: all types except thermal network camera can be selectable. Facial panel or attendance terminal is suggested. Facial IPC: The IPC which supports face recognition can choose this one. Please select the terminal type according to the actual usage of the device you want to add.

  • Page 33: Edit Camera

    SMT User Manual Camera Management 4.1.2 Edit Camera Click ―Edit Camera‖ in the setup panel to go to the interface as shown below. Click view the live image of the camera in the popup window. Click to edit the camera (see Add camera in 3.1 Startup Wizard for details).

  • Page 34: Live View Introduction

    SMT User Manual Live View Introduction 5 Live View Introduction 5.1 Live View Interface Introduction You should add IP cameras/panels first after logging onto the system (see 4.1.1 Add Camera for details). Refer to the interface as shown below, drag one camera in the preview window to another window for camera window exchanging.
  • Page 35 SMT User Manual Live View Introduction Button Menu List Meaning Click it to pop up the snap window. Click ―Save‖ in the window to Snapshot save the image. Click ―Export‖ to export the image. Zoom In Click it to go to single channel amplification interface. Click it to go to image adjustment interface.
  • Page 36 SMT User Manual Live View Introduction In the above interface, you can view the detailed information of the captured image, such as snapshot time, temperature, mask status, etc. A dropdown list will be displayed by clicking ―More‖. Click ―Register‖ to add the face picture to the face database; click ―Search‖ to quickly enter the smart search interface;...
  • Page 37 SMT User Manual Live View Introduction For the thermal network camera, you can choose to view its thermal image or optical image as shown below.  Comparison Result View Click to view face match results as shown below, including similarity, personal information, mask status, body temperature, the snapshot camera, etc.
  • Page 38 SMT User Manual Live View Introduction In the above interface, you can view the captured image, the library image, the snapshot information and the person information. Click ―More‖ to view more menus. Click ―Register‖ to add the face picture to the face database; click ―View Original Image‖...
  • Page 39 SMT User Manual Live View Introduction All exception events will be shown under this tab, such as mask off, over temperature or blacklist. Click to choose target box or rule line overlaid on the live image. Introduction of area④ In the live display interface, you can directly view the real-time statistical information as shown below left.

  • Page 40: Smart Temperature Screening View

    SMT User Manual Live View Introduction Click to select more of the real-time statistics.  Single Channel Amplification Right click on the preview window and select ―Zoom in‖ to go to the following interface. Press and drag the blue box to select the zoom in area. Click to zoom in/out the image.

  • Page 41: Corridor Pattern

    SMT User Manual Live View Introduction In this interface, you can view the visible light image and thermal image simultaneously. Additionally, the body temperature, 7-day over temperature statistics, today temperature measurement and over temperature counts, the real-time captured face pictures can be viewed. Disable ―Thermal‖...

  • Page 42: Preview Image Configuration

    SMT User Manual Live View Introduction : Click to view three-screen corridor pattern. 5.2 Preview Image Configuration 5.2.1 OSD Settings Click StartSettingsCameraImageOSD Settings to go to the interface as shown below. Select the camera, enter the camera name (or double click the camera name in the camera list to change the camera name), enable or disable the name and time OSDs (if enabled, drag the red name and time OSDs directly in the image view area to change the OSDs’...

  • Page 43: Image Adjustment

    SMT User Manual Live View Introduction 5.2.3 Image Adjustment Go to live preview interface and then click button on the tool bar under the camera window to go to the image adjustment interface.  Image Adjustment Select the camera and then click ―Image Adjustment‖ to go to image adjustment tab. Refer to the above picture.
  • Page 44 SMT User Manual Live View Introduction Parameter Meaning It relates to the total color degree of the image. It relates to the resolution level of the image plane and the sharpness level of the Sharpen image edge. The wide dynamic range (WDR) function helps the camera provide clear images even under back light circumstances.
  • Page 45 SMT User Manual Live View Introduction The introductions of these parameters and buttons are as follows. Button/Parameter Meaning Click to zoom in/out the image. If manual mode is selected, focus button &―One Key Focus‖&―Day/night mode switch autofocus‖ will be available; if auto mode is selected, the Focus Mode time interval setup will be available.

  • Page 46: People Management

    SMT User Manual People Management 6 People Management Click StartPeople Management to go to the people management interface. The first group is mainly used for attendance management. Please enter the company name, department and personal position as needed.  Add department and position Click to pop up the following window.
  • Page 47 SMT User Manual People Management Click ―Add Position‖ to add the position name. Click to modify the name. to delete the corresponding department or position. Click ―Delete All‖ to delete all Click department or position. A maximum of 50 departments and 20 positions can be added. Then you can add people for each department.
  • Page 48 SMT User Manual People Management 1. Select time and date and then click ―More‖ to choose cameras. 2. Click ―Search‖ to search the captured face pictures. 3. Select a picture and then click ―Select‖ to add this face picture. To add a face picture from external faces 1.
  • Page 49 SMT User Manual People Management Multiple face pictures can be added from ―External faces‖ too. Put pictures and the personal information file (.cvs/.txt) under the same directory of your mobile storage device. Select this directory and click ―Full Entry‖ to add. Click ―Export‖...
  • Page 50 SMT User Manual People Management In this interface, you can view whether the added picture is synchronized to the face database of the camera/panel. Please click to view the detailed synchronization rules.

  • Page 51: Attendance Management

    SMT User Manual Attendance Management 7 Attendance Management 7.1 Attendance Rule Settings Click StartAttendanceRule Settings to go to the rule setting interface. 1. Set the working start and end time, ―late‖ and ―leave early‖ rules. 2. Select work calendar type and set the working day and holiday as needed. Special date settings (customization): Click a date on the calendar to switch between working day and holiday.
  • Page 52 SMT User Manual Attendance Management In the ―Add‖ interface, click ―Add‖ to add the person who wants to ask for leave or go on a business trip. The system will automatically display the people information of the company group. Of course, you can also search the person by entering his/her name.

  • Page 53: Attendance Search

    SMT User Manual Attendance Management You can check multiple people at a time as needed. Select the type, start and end time. Then enter the process number and remark as needed. Finally, click ―OK‖ to add the leave or business trip information of this person. Then the leave/business trip information will be shown on the calendar.
  • Page 54 SMT User Manual Attendance Management 1. Select the attendance date or period as needed. If you search the attendance by day, you can view the temperature/mask status records when punching in /out on that day. 2. Select the department, attendance area and attendance type, or enter the person’s name. Then click ―Search‖.

  • Page 55: Flow Control

    SMT User Manual Flow Control 8 Flow Control Before you use this function, please add the AI camera with line crossing counting function first. (Click StartCameraAdd camera to add a camera) 8.1 Flow Control Settings Click StartAI/EventFlow Control to go to the following interface. ①...
  • Page 56 SMT User Manual Flow Control Click ―Reset‖ and then the number of the people inside will be cleared. Click ―Settings‖ to set the number of people allowed to stay and enable auto reset. Please set the available number and auto reset as needed. If the auto reset is enabled, the system will automatically reset the number of the people inside at the set time every day.

  • Page 57: Statistics

    SMT User Manual Statistics 9 Statistics 9.1 Real-Time Statistics In the live display interface, click Start Statistics to go to the following interface. In the above interface, you can view the bar graph and pie chart of the statistical information. Various statistical information can be viewed, such as over temperature counts, captured face counts, non-mask counts, people entry&...
  • Page 58 SMT User Manual Statistics Select the searched time period. Select the statistical type. Six options: flow control statistics, attendance, personnel records, over temp, captured face statistics and mask off. Click ―Search‖ to view the statistics during the specified time. Click ―Export‖ to export the statistical data. Click the ―Real-time Statistics‖...

  • Page 59: Record& Disk Management

    SMT User Manual Record & Disk Management 10 Record& Disk Management 10.1 Record Configuration 10.1.1 Mode Configuration Please format the HDDs before recording (refer to 10.5.1 Disk Management for details). Click StartSettingsRecordMode Settings to go to the mode settings interface. You can set the record time under the ―Manual Record Settings‖...
  • Page 60 SMT User Manual Record & Disk Management Select one auto mode to pop up the corresponding window. Set the encode, GOP, resolution, FPS, bitrate type, quality, max bitrate and audio of each camera and then click ―OK‖ to save the settings. Please adjust the parameters according to the actual condition. Video Encode: the available options will be H.265 and H.264 if the connected IP camera supports H.265, or the option will be H.264 only.

  • Page 61: Advanced Configuration

    SMT User Manual Record & Disk Management 10.1.2 Advanced Configuration Click StartSettingsRecordAdvanced to go to the following interface. Enable or disable cycle record (cycle record: the earliest record data will be replaced by the latest when the disks are full).Choose the record stream. Set the pre-alarm record time, post-alarm record time and expiration time of each camera and then click ―Apply‖...

  • Page 62: Schedule Settings

    SMT User Manual Record & Disk Management 10.3 Schedule Settings 10.3.1 Add Schedule When the record mode is set to ―Manual‖, you can click StartSettingsRecordRecord ScheduleEdit Schedules or click StartSettingsAlarmEvent NotificationEdit Schedules to go to the interface as shown below (or click StartSettingsAI/EventEvent ⅹ...
  • Page 63 SMT User Manual Record & Disk Management Set the schedule name and schedule time and then click ―Add‖ to save the schedule. You can set day schedule or week schedule. : add button; : delete button.  Set Day Schedule Click and then drag the cursor on the time scale to set record time;...

  • Page 64: Record Schedule Configuration

    SMT User Manual Record & Disk Management  Set Week Schedule and then click ―Manual‖ beside Click to set the week schedule. Refer to the picture below. Set the start and end time, check the days in the window and then click ―OK‖ to save the settings.

  • Page 65: Record Mode

    SMT User Manual Record & Disk Management Go to ―Edit Schedules‖ interface and then click to edit the schedule. The settings of ―Edit Schedule‖ are similar to that of the ―Add Schedule‖. Click to delete the schedule. 10.4 Record Mode 10.4.1 Manual Recording Method One: Click on the tool bar at the bottom of the live preview interface to enable...

  • Page 66: Disk

    SMT User Manual Record & Disk Management The camera will start intelligence recording once you finish the above settings. This function is only available for some devices. 10.5 Disk 10.5.1 Disk Management  Disk Management Click StartSettingsDiskDisk Management to go to disk management interface. You can view the SMT’s disk number and disk status and so on in the interface.

  • Page 67: View Disk And S.m.a.r.t. Information

    SMT User Manual Record & Disk Management There is one disk group. The added cameras will be added into the group automatically. For the model with more than one group, each group can add the disks and cameras from other groups.

  • Page 68: Playback& Backup

    SMT User Manual Playback &Backup 11 Playback& Backup 11.1 Instant Playback Click on the tool bar at the bottom of the preview camera window to play back the record (click on the toolbar at the bottom of the live preview interface to set the default playback time).
  • Page 69 SMT User Manual Playback &Backup On the panel on the right you will see the channel number and the recorded data coded by color. The bar that runs across them represents the playback time being viewed. You can move this bar around to export, highlight a section of the desired recording, click export and follow the prompts.
  • Page 70 SMT User Manual Playback &Backup The buttons on the tool bar (area①) at the bottom of the playback interface are introduced in the table below. Button Meaning Start button. Click it to pop up area ②. Full screen button. Click it to show full screen; click it again to exit the full screen.
  • Page 71 SMT User Manual Playback &Backup Button Meaning Backup button. Drag the mouse on the time scale to select the time periods and cameras, and then click the button to back up the record. Backup status button. Click it to view the backup status. Back button.

  • Page 72: Record Search, Playback &Backup

    SMT User Manual Playback &Backup motion based record; : schedule record; : intelligence record) and finally click the playback window to add camera for playback (the record time scale will show the record data of the checked record type only after the above operations). Introduction of the record time scale (area ⑤): A tool bar will appear after moving the mouse to the record time scale.
  • Page 73 SMT User Manual Playback &Backup ① Select the search time. Click the ―Today‖ tab to select the search time. Please choose the search time as needed. After you select the time and then click ―OK‖ to confirm the time you set.
  • Page 74 SMT User Manual Playback &Backup Select the captured picture, check ―Backup Picture‖ or ―Backup Record‖ and then click ―Backup‖ to back up the captured face picture or record. Select the picture and then click ―Playback‖ to go to the playback interface quickly. If ―Face Matching‖...
  • Page 75 SMT User Manual Playback &Backup The detailed snapshot information and personal information can be viewed from the detail face match box. Click ―More‖ and then choose ―Playback‖ to view the record quickly. Click ―More‖ and then choose ―Export‖ to back up the captured face picture. Click the ―List‖...
  • Page 76 SMT User Manual Playback &Backup Mask: ―All‖, ―Mask On‖ or ―Mask Off‖ can be optional. Temperature: ―All‖, ―Normal‖ or ―Over‖ can be set. You can also click ―Custom Range‖ to set the temperature range you want to search. ④ Click ―Search‖ to search the result. ...

  • Page 77: Smart Human Body Search

    SMT User Manual Playback &Backup 11.3.2 Smart Human Body Search ① Click ―By Attribute‖ under ―Human Body‖ and then select the search time. Click the ―Today‖ tab to select the search time. Please choose the search time as needed. After you select the time and then click ―OK‖...

  • Page 78: Search By Time-Sliced Image

    SMT User Manual Playback &Backup camera. Click ―More‖ to view more menus, including ―Playback‖ and ―Export‖. Click the ―List‖ tab to view the list of the searched information. Click the ―Original‖ tab to view the original pictures. 11.3.3 Search by Time-Sliced Image ①...
  • Page 79 SMT User Manual Playback &Backup cameras will be listed directly by their camera name, not the thumbnail. A maximum of 196 camera names can be listed. If the camera name number is more than 196, the time view mode will be disabled and the camera view mode will be available only. ②...

  • Page 80: Search By Time

    SMT User Manual Playback &Backup Time Slice Mode Selecting: Method One: Click ―Year‖, ―Month‖ or ―Day‖ button under the record time scale to select the time slice mode. In ―Day‖ mode, click on the left/right side of the time scale to view the record of the last/next day;...

  • Page 81: Search By Event

    SMT User Manual Playback &Backup 11.3.5 Search by Event ① Click StartSearch and BackupGeneral SearchBy Event to go to the following interface. ② Check the event type in the interface as required. ③ Click to set the start time and end time on the top left of the interface. ④...

  • Page 82: Search & Playback By Tag

    SMT User Manual Playback &Backup playback interface. 11.3.6 Search & Playback by Tag Only if you add the tags can you play the record by tag search. Click StartPlayback to go to the playback interface and then click on the bottom of the camera window to add tag when you want to mark the playback time point of the selected camera.

  • Page 83: View Backup Status

    SMT User Manual Playback &Backup 11.3.8 View Backup Status Click StartSearch and BackupBackup Status or click on the tool bar at the bottom of the playback interface to view the backup status.

  • Page 84: Ai/Event Management

    SMT User Manual AI/Event Management 12 AI/Event Management 12.1 Body Temperature Settings Click StartSettingsAI/EventTemperature/Mask to go to the following interface. ① Enable the temperature detection for temperature measurement devices. ② Please select Celsius or Fahrenheit temperature as needed. ③ Enable ―Over Temp‖ and set the temperature threshold. If the body temperature measured exceeds this threshold, it will trigger alarm.

  • Page 85: Mask Settings

    SMT User Manual AI/Event Management the schedule of the alarm outputs. See 12.7.1 Alarm-out for details. Pop-up Message Box: if enabled, the system will pop up the corresponding alarm message box automatically when the over temperature alarm is triggered. To set the duration time of the message box, please see 12.7.3 Display for details.
  • Page 86 SMT User Manual AI/Event Management ② Select the alarm type (NO or NC) according to trigger type of the sensor. ③ Enable the sensor alarm of each camera and select the schedule. ④ Check the ―Duration‖, ―Record‖, ―Snapshot‖, ―Push‖, ―Alarm-out‖ and enable or disable the ―Buzzer‖, ―Pop-up Video‖, ―Pop-up Message Box‖...

  • Page 87: Motion Alarm

    SMT User Manual AI/Event Management automatically when the sensor alarm is triggered. You need to set the delay time and the schedule of the alarm outputs. See 12.7.1 Alarm-out for details. Buzzer: if enabled, the system will begin to buzz when the sensor alarm is triggered. To set the delay time of the buzzer, please see 12.7.4 Buzzer for details.

  • Page 88: Motion Alarm Handling Configuration

    SMT User Manual AI/Event Management value according to the practical conditions since the sensitivity is influenced by color and time (day or night). Duration: it refers to the interval time between the adjacent motion detections. For instance, if the duration time is set to 10 seconds, once the system detects a motion, it will go to alarm and would not detect any other motion (specific to camera) in 10 seconds.

  • Page 89: Exception Alarm

    SMT User Manual AI/Event Management 12.6 Exception Alarm 12.6.1 IPC Offline Settings ① Click StartSettingsAI/EventExceptionIPC Offline Settings to go to the interface as shown below. ② Enable or disable ―Snapshot‖, ―APP Push‖, ―Alarm-out‖, ―Buzzer‖, ―Pop-up Video‖, ―Pop-up Message Box‖ and ―E-mail‖. The IPC Offline Settings are similar to that of the sensor alarm (see 12.3 Sensor Alarm for details).

  • Page 90: Alarm Event Notification

    SMT User Manual AI/Event Management ② Enable or disable ―APP Push‖, ―Alarm-out‖, ―Buzzer‖, ―Pop-up Message Box‖ and ―E-mail‖. The exception handling settings are similar to that of the sensor alarm (see 12.3 Sensor Alarm for details). ③ Click ―Apply‖ to save the settings. 12.7 Alarm Event Notification 12.7.1 Alarm-out ①...

  • Page 91: Buzzer

    SMT User Manual AI/Event Management 12.7.4 Buzzer Click StartSettingsAI/EventEvent NotificationBuzzer to go to the buzzer configuration interface. Set the delay time of the buzzer and then click ―Apply‖ to save the setting. You can click ―Test‖ to test the buzzer. 12.7.5 APP Push Message Click StartSettingsAI/EventEvent NotificationAPP Push Message to go to the interface as shown below.

  • Page 92: View Alarm Status

    SMT User Manual AI/Event Management 12.9 View Alarm Status Click StartSettingsAlarmAlarm Status or click on the tool bar at the bottom of the live preview interface to view the alarm status. Three types of alarm status can be viewed, including ―General Alarm‖, ―AI Alarm‖ and ―Exception‖.
  • Page 93 SMT User Manual AI/Event Management...

  • Page 94: Account & Permission Management

    SMT User Manual Account & Permission Management 13 Account & Permission Management 13.1 Account Management Click StartSettingsAccount and AuthorityAccountEdit User to go to the interface as shown below. Area ① displays the user permissions. Area ② displays the user list. Click the user in the list to display its user permissions in area ①.

  • Page 95: Edit User

    SMT User Manual Account & Permission Management ② Set the username, password and group. User can also set the pattern lock here. The e-mail address and MAC address are optional (enter the MAC address after you check it). Click ―Add‖ to add the user.
  • Page 96 SMT User Manual Account & Permission Management  Modify Pattern Lock Click ―Modify Pattern Lock‖ to pop up a window. Input current password and then check ―Enable‖ to set pattern lock.  Recover Password Click ―Recover Password‖ to reset the password to 123456. ...

  • Page 97: User Login & Logout

    SMT User Manual Account & Permission Management 13.2 User Login & Logout Login: Click StartLogin or directly click the preview interface and then select username and enter the password in the popup window. Click the ―Login‖ button to log in the system. Logout: Click StartLogout or click StartShutdown to pop up the ―Shutdown‖...

  • Page 98: Edit Permission Group

    SMT User Manual Account & Permission Management 13.3.2 Edit Permission Group Go to ―Edit Permission Group‖ interface and then click in the group list to edit the permission group (the operations of the ―Edit Permission Group‖ are similar to that of the ―Add Permission Group‖, please see 13.3.1 Add Permission Group for details).

  • Page 99: Preview On Logout

    SMT User Manual Account & Permission Management while the PC client in the black list cannot). ③ Add IP/IP segment/MAC. Click ―Add IP‖ or ―Add MAC‖ and then check ―Enable‖ in the popup window (only if you check it can the IP/IP segment/MAC you add be effective). Enter the IP/IP segment/MAC and then click ―OK‖.

  • Page 100: Password Security

    SMT User Manual Account & Permission Management 13.7 Password Security Click StartSettingsAccount and AuthoritySecurityPassword Security to go to the following interface. In this interface, you can set the level and expiration time of the password. 13.8 View Online User Click StartSettingsAccount and AuthorityUser Status to view the online user information(you can view the online user name, login type, IP address and login time;...

  • Page 101: Device Management

    SMT User Manual Device Management 14 Device Management 14.1 Network Configuration 14.1.1 TCP/IP Configuration Click StartSettingsNetworkTCP/IP to go to the following interface. Check ―Obtain an IPv4 address automatically‖, ―Obtain an IPv6 address automatically‖ and ―Obtain DNS automatically‖ to get the network addresses automatically, or manually enter the network addresses.

  • Page 102: Port Configuration

    SMT User Manual Device Management 14.1.2 Port Configuration Click StartSettingsNetworkPort to go to the interface as shown below. Enter the HTTP port, HTTPS port and server port of the SMT, and then click ―Apply‖ to save the settings. You can also enable and set RTSP port (please check ―Anonymous‖ as required). HTTP Port: the default HTTP port of the SMT is 80.
  • Page 103 SMT User Manual Device Management ② Install a certificate. * You can create a private certificate here. Click the ―Create‖ button to create a private certificate. Enter the country (only two letters available), domain (SMT’s IP address/domain), validity date, password, province/state, region and so on. Then click ―OK‖ to save the settings. * If there is a signed certificate, click ―Browse‖...

  • Page 104: Pppoe Configuration

    SMT User Manual Device Management third-party can further develop through API service. Authentication: Basic authentication and digest authentication are optional. 14.1.3 PPPoE Configuration Click StartSettingsNetworkPPPoE to go to the interface as shown below. Check ―Enable‖ in ―PPPoE Settings‖ and then enter the username and password obtained from the dealer.

  • Page 105: E-Mail Configuration

    SMT User Manual Device Management 14.1.5 E-mail Configuration Click StartSettingsNetworkE-mail to go to the following interface. Enter the sender’s name, e-mail address, SMTP server and SMTP port (you can click ―Default‖ to reset the SMTP port to the default value) and then enable or disable the SSL and attaching image.

  • Page 106: Upnp Configuration

    SMT User Manual Device Management to delete the recipient in the list. Click ―Apply‖ to save the settings. Click column. Click ―Edit Sender‖ to go to the e-mail configuration interface of the sender. 14.1.6 UPnP Configuration By UPnP you can access the SMT through web client which is in WAN via router without port mapping.

  • Page 107: Nat Configuration

    SMT User Manual Device Management To use this function, the SMT shall be connected to a switch supporting 802.1x protocol. The switch can be considered as an authentication system to identify the device in a local network. If the SMT connected to the network interface of the switch has passed the authentication of the switch, it can be accessed via the local network.

  • Page 108: Snmp

    SMT User Manual Device Management Additionally, you also can choose the records and image to upload here. 14.1.10 SNMP ① Click StartSettingsNetworkSNMP to go to the interface for SNMP configuration. ② Check SNMPv1or SNMPv2 to enable this function. ③ Set the port of the SNMP. ④...

  • Page 109: View Network Status

    SMT User Manual Device Management Trap Address: The IP address of SNMP host. Trap Port: The port of SNMP host. Tips: Before setting the SNMP, please download the SNMP software and manage to receive the device information via SNMP port. By setting the trap address, the device is allowed to send the alarm event and exception message to the monitoring center.

  • Page 110: Poe Power Management

    SMT User Manual Device Management Set the system time, date format, time format and time zone of the SMT. The default time zone is GMT+08 Beijing, Hong Kong, Shanghai, Taipei. If the selected time zone includes DST, the DST of the time zone will be checked by default. Click ―Apply‖ to save the settings. You can manually set the system time or synchronize system time with network through NTP.

  • Page 111: Recorder Osd Settings

    SMT User Manual Device Management 14.2.4 Recorder OSD Settings Click StartSettingsSystemBasicRecorder OSD settings to go to recorder OSD setting interface. OSD name and icon can be enabled here. 14.3 Factory Default Click StartSettingsSystemMaintenanceFactory Default to go to the following interface. Please choose the item as needed. Note: Resetting to the factory default settings will not change time zone.

  • Page 112: Backup And Restore

    SMT User Manual Device Management 14.5 Backup and Restore You can back up the configuration file of the SMT by exporting the file to other storage devices; you can recover the configuration to other SMTs which are of the same model with the SMT by importing the configuration file to other SMTs for time saving.

  • Page 113: View System Information

    SMT User Manual Device Management Choose the log file in the list and then click ―Export‖ button to export the log file. Click on the ―Content‖ title bar to pop up a menu list. Check contents in the menu list and then the log list will show the checked log contents only.

  • Page 114: Remote Surveillance

    SMT User Manual Remote Surveillance 15 Remote Surveillance 15.1 Mobile Client Surveillance ① Enable NAT in the SMT. Refer to 14.1.8 NAT Configuration for details. ② Download and install the mobile client ―SuperLive Plus‖ into the mobile device with the Android or iOS system.

  • Page 115: Web Wan Access

    SMT User Manual Remote Surveillance Notes: 1. Please make sure that the IP address of the SMT and the computer are both in the same local network segment. For example, supposing that the IP address of the computer is 192.168.1.41, the IP address of the SMT shall be set to 192.168.1.XXX. 2.

  • Page 116: Web Remote Control

    SMT User Manual Remote Surveillance Enter the serial number (click on the tool bar at the bottom of the live preview interface to see the serial number of the SMT), user name (the user name of the SMT, admin by default) and password (the password of the SMT) of the SMT, select the display language on the top right corner of the interface and then click ―Login‖...

  • Page 117: Live View Via Web Client

    SMT User Manual Remote Surveillance admin: the current login username. Modify Password: click it to change the password of the current login user. Enter the current password and then set a new password in the popup window. Click ―OK‖ to save the new password.
  • Page 118 SMT User Manual Remote Surveillance Click it to close the preview of all cameras. Click it to close the preview of the camera. Click it to display original size Click it to enable audio and then drag the slider bar to adjust the volume. You can listen to the camera audio by enabling audio.

  • Page 119: People Management Via Web Client

    SMT User Manual Remote Surveillance resolution, FPS and bitrate and then click ―Apply‖ to save the settings. Descriptions of Area 3 This area is the real-time captured picture display area, including face pictures and human body pictures. Descriptions of Area 4 This area is the face match view and real-time warning display area.

  • Page 120: Face Greeting

    SMT User Manual Remote Surveillance 15.4.4 Face Greeting Click Home Welcome to go to the face greeting interface. Click to enter the face greeting setting interface. The setting steps are as follows: 1. Enable welcome mode. 2. Select people from VIP group. Click ―Select‖ to select the people. 3.

  • Page 121: Playback Via Web Client

    SMT User Manual Remote Surveillance Click to display full screen. 15.4.5 Playback via Web Client Click ―Playback‖ in the remote interface to go to the playback interface. ① Check camera and set the record date on the calendar beside the time scale. ②...

  • Page 122: Search And Backup Via Web Client

    SMT User Manual Remote Surveillance Button Meaning Screen display mode Click to disable OSD; click it again to enable OSD Full Screen Backup start time button. Click the time scale and then click it to set the backup start time. Backup end time button.

  • Page 123: Upgrade Via Web Client

    SMT User Manual Remote Surveillance 15.4.8 Upgrade via Web Client Click SettingsSystemMaintenanceUpgrade. Get the upgrade file from your supplier and then save it in your local PC. Click ―Browse‖ to select your upgrade file and then click ―Upgrade‖. The upgrade requirement here is the same as the upgrade from the device.

  • Page 124: Appendix A Faq

    SMT User Manual Appendix A FAQ Q1. Why can’t I find the HDD? Please check the power and SATA data cables of the HDD to make sure they are well connected. For some SMTs with the 1U or small 1U case, the power of the adapter may be not enough for operating them.
  • Page 125 SMT User Manual Q6. The IP camera which connects to the PoE port of the SMT cannot be displayed automatically in the camera list, why? Please check whether the resource of the PoE port is occupied by another IP camera that is added through network.
  • Page 126 SMT User Manual to the PoE port through ONVIF protocol are in the same network segment. The internal Ethernet port and the IP camera which directly connects to the PoE port through ONVIF protocol should be in the same network segment, or you will fail to add the IP camera. Log in the IP camera’s web client and then enable DHCP (obtain an IP address automatically);...
  • Page 127 SMT User Manual Please check whether the PC has enabled the firewall or installed the antivirus software. Please try to access the SMT again after you disable the firewall and stop the antivirus software. Allow & block list may have been set in Account and Authority setting. The PC of which the IP address is in the black list or out of the white list cannot access the SMT remotely.
  • Page 128 SMT User Manual Fig 10-1 Fig 10-2 Q11. How to play the backup file? Recorded video backed up by SMT: insert the USB device in which the recorded video backup files is saved to the USB interface of the PC and then open the USB device path. The recorded video can be backed up in the private format and AVI format by SMT.
  • Page 129 SMT User Manual Fig 11-1 Fig 11-2...

  • Page 130: Appendix B Calculate Recording Capacity

    SMT User Manual Calculate Recording Capacity Appendix B Calculate Recording Capacity The recording capacity is mainly up to the record resolution, record stream and bitrate. Different image quality parameters decide different disk capacity occupation in equal times. The bigger the record resolution, record stream and record bitrate is, the more disk capacity is taken up in equal times.
  • Page 131 SMT User Manual Calculate Recording Capacity For instance, there is a 32CH SMT recording 24 hours per day and the record stores for 30 days. The SMT adopts dual stream recording. The main stream is 4096Kbps and the sub stream is 1024Kbps, then the total recording capacity is 49.45TB (39.56TB + 9.89TB).

  • Page 132: Appendix C Compatible Device List

    SMT User Manual Compatible Device List Appendix C Compatible Device List Compatible HDD list Brand and Series Capacity Barracuda Series 500GB/1TB /2TB/3TB Seagate SV35 Series(recommended) 1TB /2TB/3TB /2TB/3TB /4TB Surveillance HDD Series(recommended) /6TB/8TB/10TB Blue Series 500GB/1TB Western Digital Green Series 2TB/3TB /4TB Purple Series /2TB/3TB...

  • Page 133: Appendix D Communication Port List

    SMT User Manual Compatible Device List Appendix D Communication Port List Port Protocol(TCP/UDP) Descriptions Description: HTTP communication port. It is opened by default and used to access the WEB client. Authentication: Username and password Encryption: NO Description: HTTPs communication port. It is opened by default and used to access the WEB client.

  • Page 134: Appendix E Personal Data Collection Description

    SMT User Manual Compatible Device List Appendix E Personal Data Collection Description There are five functions concerning the personal data collection under the network modules of the device, including PPPoE, DDNS, E-mail, 802.1x and FTP. In the device, these functions are used by the client-end of the device to communicate with the server of the customer’s company (or service supplier).

  • Page 135: Appendix F Default Account List

    SMT User Manual Compatible Device List Appendix F Default Account List Username Default Descriptions Password Purpose：log onto the device and its clients Description： When you log in for the first time, a wizard will be displayed. You must set the password, or you cannot access the device. admin Purpose：Test via serial port Description：The default password of ―root‖...

  • Page 136: Appendix G Command List

    SMT User Manual Compatible Device List Appendix G Command List Command Function Command Contents Type add-shell addgroup adduser arp ash awk basename blkid blockdev btools busybox cat chat chmod chpst cmp cp cut date dd delgroup deluser depmod devmem df diff dmesg dnsdomainname dos2unix du echo ed egrep eject env envdir envuidgid expr fbset fgrep find free fsck.vfat fsync getty grep groups halt head hexdump hiddrs himc himd himd.l himm hostname hwclock i2c_read i2c_write id ifconfig ifstat init insmod iostat ip...

Table of Contents
