Summary of Contents for H2O LIFE SOURCE iDUO S5
- Page 1 A Water Science Company Users Manual iDUO S5 Alkaline Water Ionizer Please read these instructions completely before operating this unit.
-
Page 2: Table Of Contents
( Contents ) Electricity Safety Information ---------------- 01 ~ 02 Installation Precautions ---------------- 03 ~ 04 Precautions While Using ---------------- 05 ~ 06 Name of Each Part ---------------- 07 ~ 08 Instructions for Use ---------------- Obtaining Alkaline Water ---------------- Obtaining Acidic Water ---------------- Obtaining Purified Water ----------------... -
Page 3: Electricity Safety Information
Electricity Safety Information ▶ Please follow the following instructions below as they are there to prevent any unexpected risk or damage. ▶ Safety-related information is divided according to the magnitude of the urgency of the risk and the expected loss. If the instructions are not followed, death or serious disability is expected Danger If the instructions are not followed, significant physical or material harm is expected... - Page 4 Cause of electrocution Danger Do not pull or insert power plug with wet hands. It may cause electrocution Use of correct outlet Danger Please only use an outlet that is rated higher than 10A. Octopus wiring may cause fire due to overheating When repairing product Danger Unplug power plug when repairing or...
-
Page 5: Installation Precautions
Installation Precautions Tap water as source water Warning It is recommended to use tap water as water source water. Do not use underground water, polluted water, and water with high hardness as source water Do not use warm water as source water Do not use water unsuitable for drinking (Unsuitable source water based on Waterworks Law) Prohibition of arbitrary... - Page 6 Avoid installing on sloped and shaky areas Danger Do not install product in sloped area. Do not apply excess strength or force on the product. Please install main unit on a level surface. Do not install product in sloped or shaky area. It may cause damage when dropped or due to collision Cause of electrocution and short circuit Danger...
-
Page 7: Precautions While Using
Precautions While Using Elderly, or people with physical disabilities, psychological problems, or those Caution who lack experience and knowledge should not be using this product. Children needs to be supervised to prevent them from using the product as a toy. water In case of water shortage Caution... - Page 8 Alkali Water, Acid Water Supply water for goldfish, tropical fish, etc. Caution Do not use alkali water or acid water as supply water for fish tank with goldfish, tropical fish, etc Don’ t insert any sharp objects Danger Don’t insert any sharp wires or drivers into the product.
-
Page 9: Name Of Each Part
Name of Each Part... - Page 10 No movement of the product while operating Volume Selected level ( 0 ~9 ) FLOW FILTER DARC Acidic water outlet, Cleaning progress Blinking Controller Button After the selection of funcrions, click ON/OFF button and selected water will be dispensed...
-
Page 11: Instructions For Use
Instructions for Use Before Use - Choose a safe place for the installation. - Connect with tap water - Flush generated water for 2-3 minutes after installation is completed. - Prepare a plastic cup or glass container for collectiong the drinking water. Do not use a metallic container. -
Page 12: Obtaining Alkaline Water
Obtaining Alkaline Water 1. Touch ALKALINE button to select desired level (level 1~4) 2. After choosing the desired level of alkali water, touch the start/stop button to get water 3. Press start/stop button to stop the water after getting the desired amount of alkali water... -
Page 13: Obtaining Acidic Water
Obtaining Acidic Water 1. Touch Acidic button to select desired level (level 1~2) 2. After choosing the desired level of Acidic water, touch the start/stop button to get water 3. Press start/stop button to stop the water after getting the desired amount of acidic water... -
Page 14: Obtaining Purified Water
Obtaining Purified Water 1. Touch Purified button. 2. start/stop button to get water 3. Press start/stop button to stop the water after getting the desired amount of Purified water... -
Page 15: Control Volume
Control Volume 1. When the Volume Button is pressed, the screen's volume icon will flash 2. After choosing the desired Volume, As the button is pressed, it will switch in the following order, (1 ~ 9 ) 3. When the desired volume indicator is lit, press on to the volume button for 3 seconds to select that volume. -
Page 16: Measuring Ph / Replacing Fuse
Measuring pH / Replacing Fuse pH measurement method Drop 3 drops of pH measurement liquid in container and fill 10cc with water to be measured. Shake 2~3 times and color changes. Compare color with colorimetric table and read the color’ value to complete measurement. pH concentration color table Do not put pH measured water into eye or drink it. -
Page 17: Filter Configuration
Filter Configuration Compound filter (Lifespan: 6 months) Insist on using iDUO original filter replacement from H2O LIFE SOURCE. 1. High-density FELT Film 2. Granulated activated carbon 3. Powdered activated carbon 4. 1st Depth sediment filter 5. 2nd Depth sediment filter 6. -
Page 19: Installation
Installation... -
Page 20: Troubleshooting
Troubleshooting... -
Page 21: Specifications
Specifications I O N Co., Ltd IONPIA-5100... -
Page 22: Resetting The Filter
Resetting the FiIter 1. HoId the RESET botton for 5seconds to reset the fiIter 2. sound“dding”with fiIter reset is compIete. - Page 23 For more information, please contact our H2O LIFE SOURCE office: For more advanced technical support, WhatsApp H2O LIFE SOURCE (SEA) PTE LTD www.h2olifesource.com +65 8100 6655 No 38 Jalan Pemimpin SINGAPORE |MALAYSIA | PHILIPPINES | MYANMAR | THAILAND | AUSTRALIA...
