AUTOTECH AT-8070-D Installation And Programming Manual

Control board for 230 vac swinging gates motor
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

INSTALLATION AND PROGRAMMING MANUAL FOR AT-8070-D CONTROL BOARD
FOR 230 Vac SWINGING GATES MOTOR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-8070-D and is the answer not in the manual?

Questions and answers

Summary of Contents for AUTOTECH AT-8070-D

  • Page 1 INSTALLATION AND PROGRAMMING MANUAL FOR AT-8070-D CONTROL BOARD FOR 230 Vac SWINGING GATES MOTOR...

  • Page 2: Declaration Of Conformity

    INTRODUCTION AT-8070-D Control Board for swinging gates AT-8070-D control board is suitable for two 230VAC actuators for single or double swinging gate. The max absorption of the device is 650 W per 230Vac 50Hz. The setup of the parameters must be carried out after the installation of all the equipment.

  • Page 3: Installation

    INSTALLATION OPERATION MODES CONDOMINIUM AUTOMATIC: Prior to the electric connection shut down the 230V 50Hz power supply and adjust motor torch to If the door is closed or closing and you press START button the door opens. If the door is opening, START command is minimun.
  • Page 4 100 % = Slow Speed Disabled REMOTE CONTROL PROGRAMMING AT-8070-D control board has a built in receiver that can store upt o 128 Rolling coded remote controls or one fixed coded remote control. Remote control programming for total door open If the door is closed, press RADIO and hold it until TEST LED starts blinking.
  • Page 5 OPERATION TIME PROGRAMMING FOR TWO LEAFED SWINGING GATE WITH SLOW SPEED START START START Set trimmer TORQUE at minimum needed to move the door leaf correctly and adjust trimmer SLOW for slow speed at minimum needed to move the door leafs correctly Totally close the door.
  • Page 6 OPERATION TIME PROGRAMMING FOR TWO LEAFED SWINGING GATE WITHOUT SLOW SPEED Set trimmer TORQUE at minimum needed to move the door leaf correctly and adjust trimmer SLOW for slow speed at maximum needed to move the door leafs correctly. Totally close the door. START START START...
  • Page 7 OPERATION TIME PROGRAMMING FOR SINGLE LEAFED SWINGING GATE WITH SLOW SPEED OPERATION TIME PROGRAMMING FOR SINGLE LEAFED SWINGING GATE WITHOUT SLOW SPEED Set trimmer TORQUE at minimum needed to move the door leaf correctly and adjust trimmer SLOW for slow speed Set trimmer TORQUE at minimum needed to move the door leaf correctly and adjust trimmer SLOW for slow speed...

  • Page 8: Operation Commands

    INTERNAL PHOTOCELLS EXTERNAL PHOTOCELLS 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 6,10 TOTAL STOP OPERATION COMMANDS LIGHT PEDESTRIAN 24V / 2W START STOP START ELECTRIC LOCK...
