1120 BARE FIBER ALIGNER
USER'S GUIDE
Photon Kinetics, Inc.
9305 S.W. Gemini Drive
Beaverton, Oregon 97008 USA
tel: +1 503 644 1960
fax: +1 503 526 4700
Technical Response Center tel: +1 503 526 4678
Technical Response Center fax: +1 503 526 4633
Technical Response Center e-mail: support@pkinetics.com
www.pkinetics.com
90-0588-00
Rev. H
July 2019
Advertisement
Table of Contents
Summary of Contents for PK 1120
- Page 1 1120 BARE FIBER ALIGNER USER’S GUIDE Photon Kinetics, Inc. 9305 S.W. Gemini Drive Beaverton, Oregon 97008 USA tel: +1 503 644 1960 fax: +1 503 526 4700 Technical Response Center tel: +1 503 526 4678 Technical Response Center fax: +1 503 526 4633 Technical Response Center e-mail: support@pkinetics.com...
- Page 2 © Copyright 2019 Photon Kinetics, Inc. Printed in the United States of America. All Rights Reserved Worldwide. No part of this publication may be copied or distributed, transmitted, stored in a retrieval system, or translated in any form or by any means, electronic, mechanical, magnetic, manual or otherwise, without the express written permission of Photon Kinetics, Inc., 9305 S.W.
-
Page 3: Table Of Contents
MATERIAL SAFETY DATA SHEET ........7 1120 BARE FIBER ALIGNER OPTIONS ......9... -
Page 4: Product Overview
PRODUCT OVERVIEW The 1120 Bare Fiber Aligner can be purchased in several different configu- rations to provide the optimal aligner for your application. The integrated 1120M Production Aligner shown above should be ideal for most production testing applications. However, it may be preferable to assemble a complete aligner from the components shown below. -
Page 5: Unpacking Instructions
UNPACKING INSTRUCTIONS Carefully remove the components of your 1120 from their shipping packages and take an inventory of the parts included. 1120P and 1120F Aligner Configurations parts include: • 1120 Bare Fiber Aligner Coupling Module (1120P-000, 1120F-000) or module integrated with buffer fiber module (1120P-XXX, 1120F-XXX) •... -
Page 6: Operation
OPERATION The 1120 Bare Fiber Aligner is used to quickly connect bare optical fiber to a test equipment optical connector. Before using the 1120, ensure that a 112X- IMC or 112X-RMC Index Matching Cartridge is loaded into the 1120’s coupling module (see previous section) and that the opposite end of the 1120 is connect- ed to the OTDR or other test equipment bulkhead. - Page 7 re-insert it back into the ceramic sleeve. Re-secure the ferrule by rotating the retaining ring (2) clockwise, being careful not to overtighten the ring. Note that over time the connector will wear, but they can be refurbished. Replacement jumper cables and jumper/buffer fiber assemblies are also available. Coupling Module Assembly For more thorough cleaning, remove the coupling module assembly and gel car- tridge (2-7) from the 1120F base (8) or the 1120M/P end cap (9) by unscrewing...
-
Page 8: Index Matching Gel Cartridge Replacement
(112X-SYR) that is purchased separately or included as part of the 112X-RFK Refill Kit. To refill the RMC, remove it from the 1120 Coupling Module as described in the previous section. Next, unscrew the RMC cap and then, after removing the syringe dust cap, attach the RMC to the syringe’s tip adapter. -
Page 9: Troubleshooting
SERVICING AND REPAIRS If you need to return your 1120 Bare Fiber Aligner for service, return the unit in its original shipping carton. Inadequate packaging may lead to serious damage and may invalidate your remaining warranty. Before returning the 1120, you must obtain a Return Materials Authorization (RMA) number from Photon Kinetics. -
Page 10: Material Safety Data Sheet
INDEX MATCHING GEL MATERIAL SAFETY DATA SHEET... -
Page 12: 1120 Bare Fiber Aligner Options
OPTIONS FOR REFILLING 112X-RMC MATCHING GEL CARTRIDGES 112X-RFK Refill Kit (includes 1oz. index matching gel and syringe) 112X-GEL Index Matching Gel (1 oz.) 112X-SYR Index Matching Gel Filling Syringe 112X-RMC Refillable Index Matching Cartridge (one, filled) DISPOSABLE MATCHING GEL CARTRIDGES 112X-IMC-03 Disposable Index Matching Cartridge (pack of 3) 112X-IMC-12...
