- Page 1 WirelessUSB™ Manufacturing Test Kit User’s Guide Cypress Semiconductor 3901 North First Street San Jose, CA 95134 408-943-2600 April 28, 2005 Cypress Semiconductor Corporation Page 1/20...
- Page 2 The highly integrated nature of the WirelessUSB radio device is such that there is very little that can go wrong in the assembly process. The device itself is tested before it leaves the Cypress factory. There are only a few critical components on the customer’s board that affect the operation of the radio.
-
Page 3: Kit Description
RS-232 serial cable or USB-to-serial adapter cable for connecting the computer to the 9-pin D connector of the MTK Test Fixture. Cypress Semiconductor Corporation Page 3/20... - Page 4 <Photo #1 – Manufacturing Test Kit Contents> Cypress Semiconductor Corporation Page 4/20...
-
Page 5: Hardware Setup
The MTK Test Fixture will go through a power-on self-check, which will light all of the LED indicators. Once the green PASS light is lit, the tester is ready for use or to receive serial commands. Cypress Semiconductor Corporation Page 5/20... - Page 6 Fixed attenuator to extend antenna beyond foam. Or use SMA-M to SMA-F extender. <Photo #2 – Fixed Antenna Mounting Example> Cypress Semiconductor Corporation Page 6/20...
- Page 7 <Photo #3 – Completed Installation> Cypress Semiconductor Corporation Page 7/20...
- Page 8 If the test is successful, then the PASS light will come on when the test is completed. If the test exceeded the error threshold settings, the Tester will indicate test failure by lighting the FAIL light. Cypress Semiconductor Corporation Page 8/20...
- Page 9 Cypress Semiconductor Corporation Page 9/20...
-
Page 10: Appendix A - Firmware
1.2 and higher. The CY4632 RDK Mouse and Keyboard uses a compile time define to enter the test mode by detecting a specific grounded pin or a special key Cypress Semiconductor Corporation Page 10/20... - Page 11 LED turns off to indicated that the mouse in the test selection mode. Releasing both buttons and pressing the left button once to select the first test and then pressing the right button to start the first test. Cypress Semiconductor Corporation Page 11/20...
- Page 12 The PSoC can be reprogrammed using the ISSP header on the board. See Photo #5 for the location of the header. ISSP Header Pin 1 = VCC <Photo #5 – Location of the ISSP Header> Cypress Semiconductor Corporation Page 12/20...
-
Page 13: Appendix B - Using The Serial Interface
Send Data to DUT, e.g. PD 5A 00 0A FF 34 ..PD <B1 B2 ... B15> Tester Crystal Adjust (stored in EEPROM) ..CA <0-63> Crystal Clock Output ON=1/OFF=0 ....XO <0-1> Restore Default Settings to EEPROM .... RE Cypress Semiconductor Corporation Page 13/20... - Page 14 START button on the Tester. These values are saved in non-volatile storage and remembered across power cycles. The saved values only take affect when the Standard Test is executed. Cypress Semiconductor Corporation Page 14/20...
- Page 15 37:63 38:64 39:00 3a:00 3b:00 3c:d3 3d:8a 3e:d5 3f:3e ****************************************************************************** MTK> The Standard Test can be executed from the PC by typing the ST command at the command prompt in the terminal window. The first Cypress Semiconductor Corporation Page 15/20...
- Page 16 TE 864 RE 1008 The commands not related to the Standard Test configuration are executed immediately from the command prompt. These are used for interactive testing/debug or with a script for extended automated testing. Cypress Semiconductor Corporation Page 16/20...
-
Page 17: Appendix C - Calibration
Photo #6 – Calibration Setup, below. If the variable attenuator used does not have sufficient range, it may be necessary to install both the variable and some fixed attenuation. The amount of fixed attenuation will have to be determined by trial and error. Cypress Semiconductor Corporation Page 17/20... - Page 18 Once a base line is established by passing the test, the attenuation is increased and the test repeated. Doing this several times, increasing the attenuation each time, will eventually reach the level where the golden DUT fails the test repeatedly at a given Cypress Semiconductor Corporation Page 18/20...
- Page 19 Finally, the golden DUT should be tested once more with the fixed attenuation installed to ensure that the setup is still working. The test should pass repeatedly. If it does not, check the attenuation value and all connections again. Cypress Semiconductor Corporation Page 19/20...
-
Page 20: Appendix D - Test Chambers
CONN157. (A small box nicely sized for a mouse or dongle, or small bare boards.) • Ramsey Electronics model STE3300 with optional CONN157. • Ramsey Electronics model STE4400 with optional CONN157. (Large enough for a full size keyboard in plastic.) Cypress Semiconductor Corporation Page 20/20...
