KEY CONCEPTS DUPLEX SEQUENCE DUPLEX RECEPTICALS The duplexes must be attached to the harness in a specific order. Arrange the duplexes in the correct order by following the sequence. The duplex recepticals are designated as circuit 1, 2, 3, or 4. The number is printed on each duplex.
IMPORTANT NOTES ELECTRICAL SPECIFICATIONS Connections to the building wiring must be done by a qualified electrician according to national, state, and local codes. Never connect components while system is under load. All unused outlets must be capped. WARNING Risk of fire or electric shock. Do not electrically connect a distribution harness to more than one supply source.
COMPONENTS CABLE TRAYS ELECTRICAL 36" Power Harness 36" Power Harness BPDH60 BPDH60-8 Distributes Power to 8 Outlets Distributes Power to 16 Outlets Narrow Cable Tray Wide Cable Tray BNCT BCTX Use with Side by Side Workstations Use with Facing Workstations and 48"...
Page 6
18 INCH POWER HARNESS BPDH18-4 COMPONENTS CONT. RECEIVES 4 DUPLEXES OPTIONAL ACCESSORIES ATTACH THE DUPLEXES IN THE CORRECT ORDER BY FOLLOWING THE SEQUENCE STANDARD SEQUENCE Desktop Combo Unit Desktop Data Unit Desktop Power Unit BMFDA 2 Power Outlets + 2 Data Ports BPDMA BPMA 2 Data Ports...
36 INCH HIGH CAPACITY POWER HARNESS 36 INCH POWER HARNESS BPDH60-8 BPDH60 RECEIVES 4 DUPLEXES RECEIVES 8 DUPLEXES ATTACH THE DUPLEXES IN THE CORRECT ORDER BY FOLLOWING THE SEQUENCE ATTACH THE DUPLEXES IN THE CORRECT ORDER BY FOLLOWING THE SEQUENCE STANDARD SEQUENCE STANDARD SEQUENCE REPEAT...
POWER/DATA ASSEMBLY Mount Power Harness to Risers Place Power/Data Assembly in Cable Tray Align power harness C-bracket holes with riser holes. Slide risers into cable tray from the end. Insert plastic push rivets through the hole sets. The shape of the risers interlocks with the shape of the trays. EXPANDS PRESS Insert Duplexes...
INFEED LOCATION TYPES INFEED A. Ceiling Infeed A POWER POLE CAN BE USED TO GUIDE THE INFEED FROM THE CEILING TO THE CABLE TRAY B. Wall Infeed PASS THE INFEED DIRECTLY FROM THE WALL INTO THE CABLE TRAY C. Floor Infeed A VERTEBRAE CAN BE USED TO GUIDE THE INFEED FROM THE FLOOR TO THE CABLE TRAY For installation questions call...
Bracket Box POWER POLE Power Pole Bracket BPPBRK 2 part bracket with 4 bolts and 4 tapping screws. Power Pole BPP2 Bracket Collar Join the top and bottom halves with 2 connecting plates and 8 bolts. Top Half Bottom Half Position Power Pole Mount Power Pole Bracket Secure the Bracket...
J-CHANNEL & J-CLIP VERTEBRAE Remove Adhesive Tape Backing Assemble Vertebrae Links Stick the J-channel or J-clip to a clean dry surface. Insert the pegs of one link into the holes of the next link. Insert Wood Screws Attach Vertebrae to Surface If applicable, insert wood screw(s) to secure the J-channel or J-clip to the underside of a worksurface.
