POWER-FC
APEX FULL COMPUTER UNIT
Instruction Manual
Thank you for purchasing this unit.
Please read this manual to ensure proper use of this product.
Also, be sure to keep this manual in a safe place for future
reference.
Be sure to include this instruction manual when transferring
ownership of this product.
Please note:
THIS PRODUCT SHOULD HAVE BEEN PURCHASED FROM AN
OFFICIAL APEX POWER EXCEL SHOP. ALTHOUGH A BASE
PROGRAM HAS BEEN PROVIDED TO START A FACTORY
ENGINE, PROGRAMMING FROM AN OFFICIAL APEX POWER
EXCEL SHOP IS REQUIRED FOR THIS PRODUCT TO WORK
PROPERLY ON YOUR APPLICATION. THIS IS NOT A PLUG
AND PLAY UNIT AND DOES REQUIRE PROFESSIONAL
TUNING TO PROPERLY OPERATE YOUR ENGINE.
Product Name
Product Code
V e h i c l e
This product is meant for the following vehicles
Application Chart
●
P r o d u c t
Vehicle
Code
414-H001
Civic EX, Integra GS-R
Chasing Our Dreams - A complete line of customized car and automotive parts developed with state of the
technology art and new ideas. Our company is A'PEX which means the highest in quality.
www.R33-GTR.org
POWER-FC
Below
Table
（
１ ）
Below
Table
（
１ ）
Type
Engine Type
EJ8, DC2
D16Y8, B18C1
Notes
1996-98 M/T

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWER-FC and is the answer not in the manual?

Questions and answers

Summary of Contents for A’PEX POWER-FC

  • Page 1 POWER-FC APEX FULL COMPUTER UNIT Instruction Manual Thank you for purchasing this unit. Please read this manual to ensure proper use of this product. Also, be sure to keep this manual in a safe place for future reference. Be sure to include this instruction manual when transferring ownership of this product.

  • Page 2: Table Of Contents

    Table of Contents ■ Safety Precautions ■ ………………………………… ●Glossary …………………………………………………………………… ●Display ……………………………………………………………………… Warning ……………………………………………………………………… Caution ……………………………………………………………………… To Begin ■ ……………………………………………… Part Name and Function ■ ………………………… ●Parts List …………………………………………………………………… ●Control Unit ………………………………………………………………… Installation ■ ……………………………………………… ●Installation …………………………………………………………………… ●ECU Location ………………………………………………………………… Before Starting the Engine ■...

  • Page 3: Safety Precautions

    Safety Precautions ■ ＝ Please be sure to read the Safety Precautions Please keep this manual in a readily accessible location for future reference Signal Words and their Meanings ● We have included warnings throughout this manual to protect both the user and others from harm and injury.
  • Page 4 S a f e t y P r e c a u t i o n s ■ > CAUTION modified vehicle. ● Never install this product on a vehicle that is not listed in this manual No warranty claim will be honored if the unit has been installed on a modified vehicle.

  • Page 5: Caution

    Safety Precautions (cont'd) ■ CAUTION ● ● Always connect the wiring EXACTLY Do not adjust the unit while driving. as shown in the instruction manaul. Obey all of the rules and regulations of the highway while driving Failure to do so may result in product failure and engine damage.

  • Page 6: To Begin

    ● Do not use this product with any other vehicle than the one listed above. ● No claims for any accidents, damage, or malfunction will be honored if the POWER FC is Product Name POWER-FC Product Code Above Table （...

  • Page 7: Part Name And Function

    ■ P a r t N a m e s a n d > Parts List ● POWER-FC Warranty Card １． ２． Instruction Manual Double Sided Tape ３． ４． １ ２ CAUTION ● Be sure to check the contents of the box BEFORE attempting installation. Please contact our office if there is any missing or broken parts.

  • Page 8: Control Unit

    Part Names and Function ■ > Product ● Product Features ～ ～ Ideal Setting Data ① The data preprogrammed into the POWER FC is a result of hard engine dyno testing and is meant to maintain the power and torque levels of the factory engine. However units should be tuned by a professional tuner and require initial setting modification BEFORE use on engines with ANY modifications.

  • Page 9: Installation

    ■ Installation Installation ● ① Remove the negative terminal (-) of the battery advice! Disconnecting the negative terminal of the battery may erase memory settings of car audio, and navigation components. Please be sure to write down the settings before disconnecting the battery.

  • Page 10: Ecu Location

    Installation (cont'd) ■ ⑥ Be sure that the harness is securely connected to the POWER FC ⑦ Connect the negative terminal (-) of the battery Warning Do not perform installation while the battery is connected ● Caution ● Apex is not responsible for any data lost due to disconnecting the battery It is the responsibility of the installer to note all data before disconnecting the power Be sure to mount the POWER FC in a location that does not interfere with driving ●...

  • Page 11: Before Starting The Engine

    ■ Before starting the engine Before starting the engine, please confirm the ● following points: Has the vehicle harness been properly installed? ・ Is there any excessive strain on the vehicle harness? ・ Has the POWER FC been securely mounted? ・...

  • Page 12: Before Driving

    ■ Before Driving... Please perform the following procedures before driving. The POWER-FC performs the same fundamental operations as the factory ECU but also incorporates an engine idle correction feature. This self learning function is designed to stabilize rough idling vehicles.

  • Page 13: When Driving

    ■ When Driving Be sure that all of the operations above have been completed BEFORE driving the vehicle. If the engine check lamp illuminates at startup... ● When lit... ① ・ If lit, there is a possibility that either the map sensor, throttle position sensor, intake air temp sensor, or water temp sensor is damaged.Turn the engine OFF immediately and have your local Power Excel shop inspect the vehicle.

  • Page 14: Optional Parts

    When Driving...(cont'd) ■ CAUTION Be sure to perform the Self Learning Idle Adjustment ● Failure to do so may produce rough idle or cause the engine to stall. The POWER FCis meant for use with high octane fuel only ● Failure to do so may result in detonaion and engine damage.

  • Page 15: In Case Of Malfunction

    C a s e M a l f u n c t i o n WARNING If there is any unusual odor or noise coming from the unit, please discontinue ● use immediately and kindly repack ALL the contents of this unit and return the unit to the dealer of purchase.

This manual is also suitable for:

414-h001

Table of Contents
