Installation - oneConcept Safety-First Manual

Place the door and the left side
element next to each other.
Remove the last pole (if pre-
installed) by raising it slightly.
1
Combine the door and the
side part on the spot of the
removed door. Insert the pole
again with the spring on top.
Connect the door with the
2
right side element. Repeat the
steps of number 1.
Connect the wall fittings
with the side elements in
the same manner.
Mark two drill holes on the
3
wall. Drill the holes with a
drilling machine. Place the
dowels. Then attach the
wall fittings to the wall.
Producer: Chal-Tec GmbH Wallstr. 16 10179 Berlin, Germany

Installation

A
4
B
2
1
2
1
C
3
2
1
1
