Features:
AL-Muakkita is a digital calendar and clock.
Displaying the five prayer times and the sunrise time.
Displaying the remaining time for Iqama with possibility to set this time for each
prayer individually.
Flashing alarm when it's the time for a prayer or Iqama.
It is easy to use and control by a remote control and a local keypad.
Displaying temperature.
Automatic and manual switching between summer/winter time modes.
Low power consumption (10W).
The main power cut doesn't affect the time in AL-Muakkita.
AL-Muakkita can be configured according to the authorized prayer times in the cities
and villages all over the world.
Different sizes and designs, front panels with different languages and backgrounds, a
new design is welcome at customer request.
For more details contact our authorized agents or visit our web site www.al-awail.com.
The authorized prayer times in AL-Muakkita:
The prayer times and the sunrise time are stored in AL-Muakkita according to the
authorized prayer times in each city; these are not related to any astronomic or
mathematic calculations, so they can't be changed by the user.
If you want to change these times, you need to advise the manufacturer, the sales
agent, or the authorized maintenance agent.
AL-Muakkita description:
The displays:
AL-Muakkita consists of ten displays: date display, clock (time) display, six displays for
the prayer times and the sunrise time, temperature display, and Iqama display.
The display of the remaining time for Iqama:
This display operates when it is the time for a prayer only; the remaining time for Iqama
appears on this display in minutes, and starts decreasing minute by minute, at the last
minute the display starts flashing and decreasing second by second to zero. When the
remaining time for Iqama is Zero, the display continues flashing for one more minute
then it turns off till the next prayer time.
AL-Muakkita
User's guide
1
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Al-Awail AL-Muakkita
- Page 1 For more details contact our authorized agents or visit our web site www.al-awail.com. The authorized prayer times in AL-Muakkita: The prayer times and the sunrise time are stored in AL-Muakkita according to the authorized prayer times in each city; these are not related to any astronomic or mathematic calculations, so they can't be changed by the user.
- Page 2 The local keypad: It is located at the back side of AL-Muakkita and consists of seven keys and two light indicators: Reset key. PM light indicator.
- Page 3 The symbol indicates that the instructions can be achieved by both the remote control and the local keypad. When you are adjusting AL-Muakkita, you can cancel the whole process and return back to the normal operation mode as follows: Press ( )key on the remote control.
- Page 4 When the main power is off; the displays are all off, but the internal timing circuit is still working by means of an internal battery, so AL-Muakkita doesn't need to be readjusted even if the main power cut lasted one month.
- Page 5 Hijri date and the actual one; you can adjust it as follows: When AL-Muakkita is in the normal operation mode press and hold the ( key, AL-Muakkita will display three consecutive probabilities of the Hijri date (the calculated Hijri date plus one day, the calculated Hijri date, and the calculated Hijri date minus one day);...
-
Page 6: The Advanced Settings
The remaining time for Iqama display doesn't operate at AL-Duhr prayer on Friday. The advanced settings: AL-Muakkita has several advanced settings which are already programmed and no need to be changed except when it's necessary. Warning: Don't change these settings before you advise the technical support in your region and before you read the following sections carefully, because this may cause defect to AL- Muakkita. - Page 7 AL-Muakkita according to the number of cities stored in AL-Muakkita memory. In some cases; AL-Muakkita has prayer times for one city only, so /A/ equals to /1/ and can't be changed. B, the time difference in minutes from a city: This is used for the regions (villages) that have constant time difference from the main city which it's number has already set in the setting A.
- Page 8 ) key. The number of the digit displays: AL-Muakkita has ten displays; each one consists of several digit displays (each digit display represents one decimal digit). The number of these digit displays differs from one AL-Muakkita to another. The date display consists of /8/ digit displays.
- Page 9 ) key simultaneously, release the ( ) key first then the ( ) key, AL-Muakkita starts the test program which is an incremental count (0 ……. 9) on all the displays. You can pause the incremental count any time by pressing (...
