- Page 1 INSTRUCTION MANUAL MODEL 501/571 FOR ASSISTANCE CALL 1-800-711-1414 P/N: 60400601 REV: 02/04...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE 1. Safe Use Instructions...………………………………………………………………………………………………….3 a. General b. Installation c. Operation d. Service 2. Introduction………………………………………………………………………………………………………………….4 a. Product Illustration 3. Specifications………………………………………………………………………………………………………………..5 a. Product Specifications b. Approved Solvents c. Certifications 4. Installation and Setup.…………………………………………………………………………………………………..6 a. Unpacking and Setup 5. -
Page 3: Safe Use Instructions
SAFE USE INSTRUCTIONS General KEEP THIS MANUAL AND MSDS IN A PLACE THAT IS READILY AVAILABLE TO THE · USER. Read and understand the Instruction Manual and Material Safety Data Sheet (MSDS) for the · solvent used in the Recycling Parts Washer. Observe all warnings posted in this manual and on the equipment. -
Page 4: Operation
Operation WARNING: Solvent used in this Recycling Parts Washer is a combustible liquid and vapor. Adding · other chemicals to the cleaning solvent, including but not limited to kerosene, fuel oil, gasoline, detergents, or chlorinated solvents may cause hazardous conditions which the manufacturer has no control over and bears no responsibility. -
Page 5: Introduction
INTRODUCTION Model 501 and 571: Unit is designed to operate only in unclassified areas. Product Illustration Figure 1 P/N: 60400601 REV: 02/04... -
Page 6: Specifications
SPECIFICATIONS Product Specifications Power Requirements: 115VAC, 60 Hz, 12A Environment: 41°F to 104°F (5°C to 40°C) Solvent Capacity: 20 gallons US Model Model Specification W (Width) Floor Space 32” 39” D (Depth) Floor Space 27” 29” OH (Operating Height) 68” 70”... -
Page 7: Installation And Setup
INSTALLATION AND SETUP Unpacking and Setup Remove strapping, stretch wrap, and packing material from unit. 1. Attach fire lid bracket to unit as shown in Figure 3. 2. Connect unit to a dedicated 15 ampere branch circuit. Use of an extension cord is not permitted. -
Page 8: Troubleshooting
TROUBLESHOOTING Problem Solution Press on/off button. Check power cord connection. Wash pump not running Check outlet/circuit breaker. Contact customer service. Check for low solvent level by removing the strainer basket. Additional solvent may be transferred to the wash basin. Press and hold Wash pump runs the on/off button for twenty seconds. -
Page 9: Warranty Information
MANUFACTURER’S WARRANTY INFORMATION DEFECTS & PERFORMANCE: SystemOne products (“Equipment”) are warranted by SystemOne Technologies Inc., (“Manufacturer”), to be free of defects in materials and workmanship and to perform in accordance with the Manufacturer’s specifications and operating manual (“Warranty”) for five (5) years commencing on the date of delivery (Warranty Period). During the Warranty Period, the Manufacturer will repair, or at its option, replace the Equipment with like Equipment, free of charge.
Need help?
Do you have a question about the 501 and is the answer not in the manual?
Questions and answers
system one 2501863 is beeping 4 times on repeat. i have put around 20 gallons of solvent in it and still beeping. can you point me in a direction.
The machine beeping indicates an issue that requires contacting customer service. Since 20 gallons of solvent were added, the holding tank may be too full, causing an overflow into the wash basin. To address this, remove excess fluid from the holding tank and run a distillation cycle to return the fluid to the holding tank. If the issue persists, contact customer service.
This answer is automatically generated
ABOUT EVERY 2 DAYS I GET A BLINKING RED /BLUE LIGHT BLINKS 3 TIMES SYSTEM SEEMS FINE I UNPLUG IT AND RESET AND LIGHT RETURNS TO SOLID GREEN
