Summary of Contents for TSI Instruments DustTrak 854041
- Page 1 HEATED INLET SAMPLE CONDITIONER ACCESSORY (854041) FOR DUSTTRAK ™ ENVIRONMENTAL MONITORS INSTALLATION GUIDE _______________ TSI and TSI logo are registered trademarks of TSI Incorporated. DustTrak is a trademark of TSI Incorporated.
- Page 3 Item Thank you for purchasing a DustTrak™ Environmental Qty. Description Reference Picture Monitor Heated Inlet Sample Conditioner Accessory (PN 854041). This guide will help you quickly begin Water Trap using your Heated Inlet Sample Conditioner. Warning Labels Warns that the instrument could be hot to Power and the touch or a burn hazard.
- Page 4 6. Attach the two Installing the Heated Inlet larger (gray) (854041) connectors to side of the photometer. 1. Attach heated inlet control module to the front of the Photometer. This can be done using the 2x 6-32 x 5/16 Socket Head Cap Screws and 2x flat washers. Use a 7/64”...
- Page 5 9. If required, install the 12. Attach the inlet to impactor (PM1, PM2.5 or the column. PM10) per the instructions that came with the impactor kit. NO T E Impactors are not used on DustTrak DRX models. 13. Install O-ring and route cable through the mounting ring.
- Page 6 3. Remove the Ferrite 17. Attach ferrite to Clamp Assembly. cable with one wrap Note that the clamp of the cable and is released by snap the ferrite inserting and together. twisting a small flat 18. Attach heated inlet blade screwdriver. cable to heated inlet Also, for purposes control module (J4).
- Page 7 Operating Instructions Specifications 1. When powered and attached to the DustTrak Power ....12-24 Volts DC; 13 Watts monitor, the Heated Inlet will automatically function. Dimensions ..Heated inlet 2. Select RH set point that will be controlled at the 13 in.
- Page 8 TSI Incorporated – Visit our website www.tsi.com for more information. Tel: +1 800 680 1220 India Tel: +91 80 67877200 Tel: +44 149 4 459200 China Tel: +86 10 8219 7688 France Tel: +33 1 41 19 21 99 Singapore Tel: +65 6595 6388 Germany Tel: +49 241 523030...
