- Page 1 Courtesy of: DiscountCarStereo.com Serving the internet community since 1995 A2D-C5 (v 4.6.20) QUICK START MUSIC STREAMING INSTALLATION GUIDE FOR 1997-04 CORVETTE WITH FUNCTIONING 12-DISC CD CHANGER Created January 16, 2013 Revised June 3, 2020...
- Page 2 If your C5 has a functional 12-disc changer and looking to add music streaming; the A2D-C5 is for you! Users may opt to connect module to radio or 10-pin CD changer plug at changer location in hatch/trunk. The required 12-disc CD changer remains connected and operational;...
-
Page 3: Fig. 5
Where to get 12V ACC/Switched power? 1997-03 vehicles have a 3-pin plug under passenger seat near BCM (may be covered in black duct tape) -- See Fig.3 Yellow wire is ACC. If vehicle does not have 3-pin plug; go to Alternate 12V Acc. supply. Fig. -
Page 4: Fig
Installation 2: (To 10-pin plug at CD Changer in trunk/hatch) This installation option is completed at the rear and applies to vehicles with CD changer which remains connected and functional. If vehicle does not have a CD Changer or malfunctions, purchase our BLU-C5 instead. -
Page 5: Fig. 8
Where to get 12V ACC/Switched power? 1997-03 vehicles have a 3-pin plug under passenger seat near BCM (may be covered in black duct tape) -- See Fig.3 Yellow wire is ACC. If vehicle does not have 3-pin plug; go to Alternate 12V Acc. supply. Fig. - Page 6 Fig. 6 fuse tap circuit Fig. 5 C5 interior fuse box ( yours may be different How to use the Add-a-fuse circuit connection Noteworthy : If streaming is interrupted when headlights, wipers, defroster, Strip 1/4- 3/8” insolation from included accessory wire. A/C;...
- Page 7 Pairing: Optional equipment: The following options are not required for the module to work; however, these two options enhance user experience. Pairing process varies among devices but the process is the same. These steps are To add remote to order simply tick box on product page done upon initial install and will not have to be repeated.
- Page 8 Remote Control Operation: USB “Fast charge” Kit Use wireless remote to perform the following functions on any iOS7.0 and higher or Optional USB Kit provides a USB port for users to connect and charge those Android 4.4 and higher. power-hungry devices while on the road. Custom install USB port in a convenient location and discover how this charger is a massive improvement over many anemic aftermarket cigar lighter chargers.
- Page 9 USB kit Installation A. Flush to dash/panel requires drilling a ¾” hole in the dash B. Flush with Support bracket (use this option to mount USB terminal without drilling) A. Flush to Dash or Panel (drilling required) Fig. 11 Drill a ¾” hole to dash or panel using a step drill bit or equivalent (See Snap USB head (See Fig.
- Page 10 B. Bracket Mount Test Operation: (No drilling) Locate a flat surface at location of choice within 3.2 ft. of radio to mount Turn Radio “ON” USB support bracket (See Fig. 14) 2. Press “AUX” button on radio Use tape backing or screws to secure bracket 3.
- Page 11 Hands-free calling (HPF) hands free calls Music Streaming (A2DP) Will I be able to install the A2D-C5 at the radio instead of trunk/hatch? Connection (To Radio) YES, The A2D-C5 connects to radio (PXHGM4 harness or 10-pin plug at cd Connection (trunk) changer location (PXHGM2 harness).
- Page 12 For additional questions, email support@discountcarstereo.com © 1995- Discount Car Stereo, Inc. All rights reserved. Information in this 2020-06-03 document is subject to change without notice. Other products and companies referred to herein are trademarks or registered trademarks of their respective companies or mark...
