Instruction Sheet
IL211024 EN
Sliding Keyboard/Pedestal Bracket
Overview
•
The Sliding Keyboard/Pedestal Brackets are designed to
accommodate both 30" (762mm) and 36" (914,4mm) deep
worksurfaces.
•
They can be used with laminate, phenolic and maple
worksurfaces.
•
Both units can only be used with 36"" (914,4mm) thru 96"
(2438,4mm) Linear TechBenches.
•
Each unit is rated for 150 lbs (330,0 kg).
•
The Keyboard Bracket has a mounting hole pattern to accept a
"KB" Cobra style mounting track.
•
The Pedestal Bracket has (2) sets of hole patterns. One hole
pattern is for a C38X series Pedestal, the other is for a "KB"
Cobra style keyboard track.
•
A safety locking feature prevents accidental disengagement on
the units.
•
A synthetic grease must be applied to both front and rear
TechBench
Bracket assemblies. This will ensure smooth motion of loaded
units.
•
A knob located on the front of each Sliding keyboard/Pedestal
Bracket locks the unit in place during use.
Effective May 2018
Supersedes 91647
stiffeners as well as the Sliding Keyboard/Pedestal
™
Advertisement
Summary of Contents for Eaton Sliding Keyboard
- Page 1 A synthetic grease must be applied to both front and rear TechBench stiffeners as well as the Sliding Keyboard/Pedestal ™ Bracket assemblies. This will ensure smooth motion of loaded units. • A knob located on the front of each Sliding keyboard/Pedestal Bracket locks the unit in place during use.
- Page 2 TechBench™ manual two Plastic Rollers, Locking Knob and nylon #91398. washer from the Sliding Keyboard/Pedestal Bracket assembly. See figure 1. Do not discard! Apply synthetic grease to entire top and underside of the two flanges as shown in figure 1.
- Page 3 Instruction Sheet Sliding Keyboard/Pedestal Bracket IL211024EN Effective May 2018 3. To install the Sliding Keyboard/Pedestal Bracket assembly to the underside of the TechBench , align ™ To install the Sliding Keyboard/Pedestal Bracket the cut-out in the assembly with the front Stiffener assembly to the underside of the TechBench™, align...
- Page 4 3/8” x 1-1/2” hex head bolts Figure 4 Figure 4. (Worksurface not shown) (Worksurface not shown) Eaton Eaton is a registered trademark. 1000 Eaton Boulevard Cleveland, OH 44122 * All trademarks are property United States of their respective owners. Eaton.com...
