Summary of Contents for Quloos QA890
- Page 1 『Front Panel』 Function Function Input channel option / Remote control ON / OFF Volume Up Infra-red remote control receiving window Volume Down OLED Screen Mode Option 『Rear Panel』 - 1 -...
- Page 2 Function Function Coaxial input 1 Power ON / OFF Coaxial input 2 Right channel balance output Optical input Left channel balance output USB input（Optional） Right channel RCA output AC 110V / 220V Input Left channel RCA output 『Remote Control』 Function Input channel option Mode option OLED Brightness / OFF-Screen Option...
- Page 3 Note: The remote control is optional with the default setting shut OFF. It can be turned on by long pressing the "S" key on the panel and vice versa. When it shows "IR REMOTE ON", it means the remote control is on. When it shows "IR REMOTE OFF", it means the opposite. 『Power Voltage』...
- Page 4 After the channel is picked, OLED screen will show the corresponding channel, and the setting will be saved automatically after 5 sec. 『Mode option』 Under PCM audio source input, there are 6 optional modes. Mode 1-5 is PCM digital filter mode. Mode 6 is all PCM signal convert DSD signal. MODE1: SLOW MODE2: SHORT DELAY SHARP MODE3: SHARP...
- Page 5 automatically saved after 5 sec of setting. 『USB Interface』 Support sampling bits 16Bit / 24Bit,sampling rate 44.1k-192kHz and DSD64（Dop）. Compatible with Mac OS and Linux systems（no need to install driver）. Compatible with systems from WIN XP to WIN10 32 / 64 bit, manual driver installment is necessary for initial connection with PC.
- Page 6 Product QA890 Hi-Fi Audio DAC Date User Name Zip Code Mobile Address Customer Feedback （This part is filled by the manufacturer） Cause Analysis and Solution Remarks Company: ShenZhen QLS Electronic Technology Co.,Ltd （Quloos） E-mail: cxqmcu@cxqmcu.com Web: http://www.qlshifi.com - 6 -...
