- Page 1 Controlpro User manual...
- Page 2 The product names mentioned in this document may be brands or registered trademarks of their respective owners. These are not explicitly labeled with “™” or “®”. © DOGAWIST Investment GmbH Otto-Röhm-Straße 69 64293 Darmstadt Germany www.peaknx.com info@peaknx.com Document Version 2.1.0 (May 2020)
-
Page 3: Warning Symbols And Signal Words Used In This Manual
Controlpro - User manual Warning symbols and signal words used in this manual Obey warning to avoid death or serious injury Obey instructions to avoid personal injury or damage to property Instructions and facts to be followed Note Additional, useful hints Important safety instructions, please read before installation! The device can carry dangerous voltages if improperly installed! -
Page 4: Table Of Contents
3.1.1 Operating system ..........7 3.1.2 Operation with the PEAKnx Software YOUVI ..... . . 7 3.1.3 Operation with third-party software . - Page 5 About PEAKnx ........
-
Page 6: Target Audience
■ Intercom station for compatible door stations A list of all compatible door stations can be found in our FAQ: www.peaknx.com/FAQ under the topic “compatibility”. ■ Indoor operation, note the ambient conditions, see chapter 10 The following applications are not part of the intended use: ■... -
Page 7: Product Description
Other programs for the visualization of building information and for building control can be installed later. PEAKnx provides no service and no war- ranty for software products from other companies as well as in case of OS driver updates. -
Page 8: Operation With Third-Party Software
A list of compatible software can be found in the FAQs: www.peaknx.com/FAQ, topic “compatibility”. Note: PEAKnx does not guarantee the function of third-party software on the panel. Further instructions for setting up the panel can be found in the download area: www.peaknx.com/downloads#controlpro 3.2 Variant overview... -
Page 9: Components
Controlpro - User manual 3.3 Components Position Description Dimensions (H x W x D) Flush-mounted box 312 x 528 x 65 mm Panel with touchscreen 320 x 535 x 50 mm Glass cover 330 x 560 x 1.8 mm... -
Page 10: Touch Panel, Front View
Controlpro - User manual 3.4 Touch panel, front view Position Description 4 x screw holes for fixing the panel 4 x intake for glass cover Microphone Camera Ventilation openings Touchscreen 2 x USB 2.0, status LED Cooling element On/Off button... -
Page 11: Touch Panel, Rear View
Controlpro - User manual 3.5 Touch panel, rear view Position Description Power supply 15 - 20 V DC Power supply GND KNX terminals (KNX WAGO 243 211, conductor diameter: 0.6 - 0.8 mm) 3.6 Touch panel, top view... -
Page 12: Product Features
Controlpro - User manual Position Description HDMI out VGA out 2 x USB 3.0, not suitable for permanent use! Gigabit Ethernet 2 x USB 3.0, not suitable for permanent use! Audio, Mic in Audio, Line out 3.7 Product features ■ LED backlit color TFT display 1920 ×... -
Page 13: Notes On The Panel's Ports
Note: The device cannot be used as a line coupler for KNX lines! Note: The KNX fieldbus can only be used with PEAKnx software. 3.8.2 Ethernet port Note: Make sure to install the correct cabling standard to fully use the 1 GB LAN (at least Cat 5). -
Page 14: Graphical User Interface
Controlpro - User manual 3.9.1 Graphical user interface Touch the panel to operate. A brief touch of the panel is interpreted as a mouse click. A right mouse click is obtained by a prolonged touch (approx. 3 seconds). Text may be entered using the Windows on-screen keyboard. Avoid damage to front glass and display! ■... -
Page 15: Important Safety And Handling Information
Controlpro - User manual Necessary components for the installation of the panel: ■ Flush-mounted box (PNX-018-A19-00069) ■ Power supply unit 15-20 V DC for DIN rail (PNX-019-A18-00057) ■ Power supply 15-20 V DC for the flush-mounted box (PNX-019-A19-00065) 5 Important safety and handling information The Controlpro may only be installed and commissioned by qualified electricians! Observe the national regulations applicable in your country... -
Page 16: Installation And Start-Up
A slightly lower screen prevents fatigue of the arms during operation. Tip: If you have ordered a PEAKnx flush-mounted box for the panel you can use the supplied template to mark the recess. -
Page 17: Installing The Flush Mounted Box In Brickwork
Controlpro - User manual 6.2.1 Installing the flush mounted box in brickwork ■ Mark a 312 x 528 mm recess on the wall, but leave bevels in the corners. These will later be used for fixing the flush-mounted box. ■ Make the recess in the wall with a depth of 65 mm. -
Page 18: Connecting The Power Supply
Controlpro - User manual 6.3 Connecting the power supply Avoid electric shock when touching live parts! ■ Disconnect all associated circuit breakers before working on the device. ■ Cover live parts in the surroundings. 6.3.1 Prepare the voltage source for the DIN rail (recommended) ■... - Page 19 Controlpro - User manual ■ Screw the power supply unit to the flush- mounted box at its mounting feet using the 2 cm two supplied self-tapping screws. ■ Mounting position: at central height approx. 2 cm from the left side of the flush-mounted box.
-
Page 20: Connecting And Fastening The Panel
Controlpro - User manual 6.4 Connecting and fastening the panel Avoid damage to the panel due to early commissioning! ■ Note the climatic conditions at the installation site! ■ Before switching on the mounted device, the device must have adapted to the climatic conditions at the installation site. -
Page 21: Initial Commissioning And Operation
Controlpro - User manual 7 Initial commissioning and operation Tip: We recommend to create a backup with PEAKnx’ optional Recovery USB flash drive before installing additional software, see section 7.3 Creating a backup on the Recovery USB flash drive. Avoid damage to the panel! ■... -
Page 22: Setting Up The Visualization
Controlpro - User manual Note: In normal operating conditions, it is not necessary to switch off the Cont- rolpro. 7.2 Setting up the visualization After commissioning, set up the visualization as described in the enclosed quick reference guide. It is assumed that all KNX actuators have already been parame- terised via the ETS. -
Page 23: Maintenance
The glass cover and touchscreen must be cleaned regularly to ensure proper ope- ration. This will prevent residues caused by use (e.g. fingerprints) or dust from impairing the touch function. Suitable cleaning cloths are available in the PEAKnx Shop. Avoid damage to the glass cover and display! ■... -
Page 24: Troubleshooting
Controlpro - User manual ■ In the YOUVI visualization, switch to the settings. ■ Tap on “Activate cleaning mode” in the upper left corner. Now, active elements are deactivated for 20 seconds to prevent you from accidentally changing device values during cleaning. Cleaning the touchscreen ■... -
Page 25: Windows Has Unrecoverable Problems
Controlpro - User manual panel from the power supply. ■ Disconnect the circuit breaker of the panel in the building’s control cabinet for at least one minute. 9.2 Windows has unrecoverable problems If the Windows user interface shows unrecoverable problems, the operating system can be reset to factory settings. -
Page 26: Technical Support
Remove the Recovery USB flash drive. ■ Restart the panel. ■ Attach the glass cover. 9.3 Technical support If you experience problems with your Controlpro, please contact our PEAKnx Support Team: ■ Mail: support@peaknx.com ■ Create a support ticket: support.peaknx.com/?lang=en_US ■... - Page 27 Controlpro - User manual Display Type TFT color screen Backlighting Color resolution 16.7 million colors Size (diagonal) 46.9 cm (18.5 inch) Aspect ratio 16:9 Resolution 1920 x 1080 pixels Maximum brightness 350 cd/m² Viewing angle horizontal (left/right) 89°/89° vertical (up/down) 89°/89° Touch technology Projected-capacitive touch (PCAP), Multi-touch Peripherials...
- Page 28 Controlpro - User manual Ports 2 x USB 2.0 (Front) 4 x USB 3.0 Ethernet Gigabit Ethernet External screen HDMI out, VGA out Fieldbus 2 x KNX Audio 1 x Line out, phone jack, 3.5 mm 1 x Mic In, phone jack, 3.5 mm Environment Ambient temperature Operation: 0 to 35 °C...
-
Page 29: Subject To Change Without Notice
Controlpro - User manual Subject to change without notice Content changes in this documentation, which serve the technical progress, are made without prior notice. This documentation has been prepared with great care and will be revised at regular intervals. Nevertheless, we cannot guarantee complete accuracy. - Page 30 Controlpro - User manual...
-
Page 31: About Peaknx
As the newest division of the PEAK group headquartered in Darmstadt, Germany, PEAKnx can draw from more than 25 years of experience in hardware and soft- ware development. Through a broad network of certified partners, PEAKnx also offers the associated services - from consulting to the installation and implemen- tation of automation projects. - Page 32 www.peaknx.com...
