- Page 1 ENGLISH Boiler Control ENGLISH Installation guide Step by step duco.tv instructions L2000022 (Revision C | 19.07.2019) L2000022-C 19.07.2019 Installation guide DucoBox Eco Boiler Control...
-
Page 2: Table Of Contents
DUCO, HANDELSSTRAAT 19 VEURNE, B-8630 Vero Duco - Handelsstraat 19 - 8630 Veurne - Belgium tel +32 58 33 00 33 - fax +32 58 33 00 44 - info@duco.eu - www.duco.eu L2000022-C 19.07.2019 Installation guide DucoBox Eco Boiler Control... -
Page 3: Introduction
ENGLISH 01 Introduction Congratulations on your purchase of a new Boiler Control� We welcome you into the DUCO family as a valued customer� We hope that you will have many years of enjoying the use of our product� 01.A Operation The Boiler control is a control, device which will allow the ventilation heat pump to generate as much heat as possible�... - Page 4 • 1 x 230 V mains lead • 1 x installation guide A1025512 Heaterboard behuizing top A1025450 Powercord 3x2.5mm², 2m, CEE 7/7 plug A1025446 Sluitmoer Kabelwartel M16 A1025445 Kabelwartel - M16 Gatdiam., 4-8mm kabel Index tekeningnr. Aantal Beschrijving L2000022-C 19.07.2019 Installation guide DucoBox Eco Boiler Control...
- Page 5 ENGLISH 01.C Dimensions L2000022-C 19.07.2019 Installation guide DucoBox Eco Boiler Control...
-
Page 6: Regulations And Safety Instructions
Failure to adhere to these safety instructions, warnings, notes and instructions could result in damage to the DucoBox Eco Boiler Control or in personal injury for which DUCO NV cannot be held liable�... -
Page 7: Fitting/Assembly
03 Fitting/assembly 03.A General guidelines The DucoBox Boiler Control is to be positioned a close as possible to the Duco buffer tank, up to a maximum of 2 metres apart� All wiring coming out of the Boiler Control must have a clear and unimpeded passage to its end component�... -
Page 8: Wiring
Remove the screws on the sides� Slide the cover upwards� CLICK 04 Wiring 04.A Associated connecting cables DucoBox Boiler Control Buffer tank heater control cable – 1�5 0000-4412 mm² DucoBox Boiler Control Temperature sensor 0000-4413 L2000022-C 19.07.2019 Installation guide DucoBox Eco Boiler Control... - Page 9 Voltage free contact 2 Voltage free contact 1 Heater Heater Temperature Relay 1 Relay 2 sensors 04.C Cabling diagram Please refer to the information sheet for the chosen product concept� These can also be downloaded from www�duco�eu� L2000022-C 19.07.2019 Installation guide DucoBox Eco Boiler Control...
-
Page 10: Commissioning
ENGLISH 05 Commissioning 05.A Pairing in the network Pair the DucoBox Eco Boiler Control with the DucoBox Eco Activate advanced mode on the DucoBox Eco: • Scroll down to ADVANCED and press enter� • Enter the installer’s code 9876 and press enter�... - Page 11 ENGLISH 05.B Removing and replacing The procedure for removing and replacing the DucoBox Eco Boiler Control is the same as for any other component� Please refer to the DucoBox Eco manual for the instructi- ons� L2000022-C 19.07.2019 Installation guide DucoBox Eco Boiler Control...
- Page 12 ENGLISH Installed by: L2000022 Document last modified on 19.07.2019 (revision C) L2000022-C 19.07.2019 Installation guide DucoBox Eco Boiler Control...
