- Page 1 5 TONNE FORKLIFT/TRACTOR JACK MODEL NO: CFT5B PART NO: 7624007 OPERATION & MAINTENANCE INSTRUCTIONS GC0619 - ISS2...
-
Page 2: Technical Specifications
INTRODUCTION Thank you for purchasing this CLARKE jack. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
Only use the product for the purpose for which it is intended. 5. Do not use the jack if an oil leak is apparent. Consult your Clarke dealer. 6. Check the condition of the labels regularly and replace as required. -
Page 4: Environmental Protection
4. Never climb on, or attempt to ride on the jack. 5. Take care not to trap fingers in the moving parts of the jack. Ensure that you can see the contact and jacking point throughout the jacking operation in case there is any relative movement. 7. -
Page 5: Before Use
1. Remove the filler plug and check the oil level. • Oil should be up to the edge of the filler hole. 2. Top up if necessary with Clarke hydraulic oil available from your local Clarke dealer (part number 3050830). -
Page 6: Operation
OPERATION RAISING A LOAD WARNING: BEFORE LIFTING, ENSURE THE SAFETY PRECAUTIONS ARE STRICTLY FOLLOWED. NO RESPONSIBILITY CAN BE ACCEPTED FOR INCORRECT USE OF THE JACK. WARNING: PLEASE NOTE THAT THE SCISSOR ACTION OF THE JACK WILL CAUSE THE JACK TO MOVE SLIGHTLY AS IT IS RAISED AND LOWERED. IT IS MOST IMPORTANT THAT THIS MOVEMENT IS NOT RESTRICTED IN ANY WAY. -
Page 7: Maintenance
6. If an oil leak is seen, check the oil level as described on page 5. 7. In the case of a persistant oil leak which requires the dismantling of the hydraulic parts to correct, the jack should be taken to your Clarke dealer for overhaul. -
Page 8: Troubleshooting
Purge the system as described on system page 5. Jack will not Control valve may Return to your Clarke dealer for lower completely be faulty repair If any of these remedies fail to restore your jack, consult your Clarke dealer... -
Page 9: Component Parts
COMPONENT PARTS PART NO DESCRIPTION PART NO DESCRIPTION Nut M16 Not Used Washer Not Used Main Supporting Axle Set Screw Screw Ball Washer Cylinder Cap Penny Washer O-Ring Side Plate O-Ring Circlip Screw-in Plug Washer Oil Reservoir Front Wheel Bush Ram Piston Rod Front Wheel Axle Ram Cylinder... - Page 10 PART NO DESCRIPTION PART NO DESCRIPTION Spring Back-up Ring Ball 3mm Wiper Ring O-Ring Plunger Not used Piston Not used O-Ring Plug Seal...
-
