ALARM SETTING
The maximum alarm duration is 80 seconds. To set the alarm function:
1.
Press the ALM key for about 1 second or until the digits start flashing in the LCD to enter into the
Alarm setting mode. The hour digits start flashing.
2.
Press the + key to set the hour.
3.
Press the ALM key to enter the minute mode. The minute digits start flashing.
4.
Press the + key to set the minutes.
5.
Press the ALM key or the SNOOZE key to exit the Alarm setting mode or wait for 15 seconds
automatic timout.
Note:
If the ALM key is pressed for a short time, the alarm toggles between ON/OFF. At the same time, the
current alarm time will be displayed for about 4 seconds.
TO ACTIVATE / DEACTIVATE THE ALARM:
The alarm will automatically be ON upon entering and exiting the Alarm setting mode. To desactivate
the alarm (OFF), use the ALM key in normal mode display.
SNOOZE SETTING
When pressing the SNOOZE key during alarm sounding, the snooze function is activated for a
duration of 9 full minutes.
When keeping the SNOOZE key during alarm sounding for 1 second, after confirmation of a
"beep" sound, the alarm will switch OFF for the next 24 hours and no snooze f u nction will be
activated.
Note:
If the SNOOZE key is pressed for about 1 second, except during alarm ringing, it will display the alarm
time for about 4 seconds.
POSITIONING THE MOON PHASE CLOCK
The Moon Phase Clock can be either free standing or hanging on a wall:
To free stand:
Simply unfold the 2 stands at the back of the clock and place on a flat surface.
To wall mount:
1.
Fix a screw into the desired wall, leaving the head extended out by about 5mm
2.
Using the Moon Phase Clock's hanging hole, carefully hang it onto the screw.
Note:
Always ensure that the Moon Phase Clock locks onto the screw before releasing.
CARE AND MAINTENANCE
Avoid placing the unit in areas prone to vibration and shock as these may cause damage.
Avoid areas where the unit can be exposed to sudden changes in temperature, i.e. direct sunlight,
extreme cold and wet/moist conditions as these will lead to rapid changes which reduces the
accuracy of readings.
When cleaning the LCD and casing, use a soft damp cloth only. Do not use solvents or scouring
agents.
Do not submerge the unit into water.
Immediately remove all low powered batteries to avoid leakage and damage. Replace only with
new batteries of the recommended size.
Do not make any repairs to the unit. Please return it to the original point of purchase for repair by a
qualified engineer. Opening and tampering with the unit may invalidate its guarantee.
SPECIFICATIONS
Indoor temperature measuring range :
Indoor temperature checking interval :
Power source
:
Battery life
:
Dimensions (L x W x H)
:
LIABILITY DISCLAIMER
The manufacturer and supplier cannot accept any responsibility for any incorrect readings and any
consequences that occur should an inaccurate reading take place.
This product is only designed for use in the home
This product is not to be used for medical purposes or for public information.
The specifications of this product may change without prior notice.
This product is not a toy. Keep out of the reach of children
No part of this manual may be reproduced without written authorization of the manufacturer.
R&TTE Directive 1999/5/EC
To be used in EC Member and EFTA States.
Summary of the Declaration of Conformity : We hereby declare that this wireless transmission device
does comply with the essential requirements of R&TTE Directive 1999/5/EC.
0ºC to +50ºC with 0.1ºC resolution
32ºF to +122ºF with 0.2ºF resolution
("--.-" displayed if outside this range)
every 10 seconds
2 x AA, IEC LR6, 1,5V batteries
(Alkaline batteries recommended)
about 12 months
290 x 25 x 190mm
