BACnet Protocol Revision: 12 Product Description: Melink Intelli-Hood is a demand ventilation product which conserves energy for the commercial kitchen industry. It is particularly used in conjunction with VFD’s (Variable Frequency Drives) which control the speed of the kitchen EF (Exhaust Fans) and kitchen MUA (Make-Up Air) units.
Page 4
Page | 3 Standard Object Types Supported: All objects are statically created based upon device configuration. Create object and delete object are not supported. See object list at the end of this document for more information. Analog Value Binary Value ...
Page | 4 Object/Property Support Matrix The following table summarizes the Object Types/Properties Supported: Object Type Analog Range or Present Object Binary Value Access Number Active/Inactive Text Type Object Name Binary Analog (Value Text) Value Value System Controller Digital Input 1 Status Closed/Open Read only ...
Page | 5 Device Object Description This section describes in further detail each of the Device Objects in the Object/Property Support Matrix and a brief description of each object associated with each Device Object type. System Controller The System Controller is the main Device Object for the system. It acts as a virtual BACnet router for the other Device Objects populated on the Intelli-Hood system.
Page 7
Page | 6 Remote On/Off with Enable A combination of the Remote On/Off and the Remote Enable/Disable digital inputs. This acts as a Remote Enable/Disable digital input as described above. However, it also requests that fans start in the associated Hood Groups. 50% Minimum Speed through 100% Minimum Speed A Minimum Speed digital input is a level sensitive input.
Page 8
Page | 7 External Alert The External Alert digital input is a level sensitive input. This digital input can be used to alert a non-critical failure for equipment that is external to the Intelli-Hood system. If this digital input is active, an “External Alert” message is displayed in the title on the main screen on the Touchpad.
Page 9
Page | 8 MUA Damper If the Make-Up Air unit has a damper that closes when the Make-Up Air unit is not running, then the damper needs to be opened before the fan should run. A MUA Damper digital output is then used to signal the damper to open. If there is any input which requests an associated Hood Group to turn on its fans (Fans button from either the Touchpad or Auxiliary Touchpad, Schedule, Remote On/Off digital input), then a MUA Damper digital output is energized.
Page 10
Page | 9 Highest The affected Exhaust Fans and Auxiliary Airflows either run at the calculated fan speed or the percent speed governed by this analog input, whichever is highest. The analog input percentage is added to the calculated fan speed for the Exhaust Fans and Auxiliary Airflows.
Page | 10 Exhaust Fans and Auxiliary Airflows Each Exhaust Fan and Auxiliary Airflow can be configured to be present on the BACnet interface or not. By default all Exhaust Fans and Auxiliary Airflows are enabled on the BACnet interface and will populate as a separate Device Object with a DNET matching the configured “BACnet DNET”...
Page 12
Page | 11 Output Current The instantaneous output current reading as reported by the VFD. The output current is not available on all VFD models; be sure it is available on your VFD if you would like to monitor this value. Output Energy The reported kWh counter of the VFD.
Page | 12 Hood Controllers Each Hood Controller houses up to four temperature sensors and one set of optics for temperature and effluent detection. By default there is not a Device Object present for each Hood Controller, but the system can be configured to do so. Below is a list of the Hood Controller Objects.
Page | 13 Virtual Output Module A Virtual Output Module is a virtual device to provide a means to add digital outputs to the system that can be monitored via BACnet. Below is a list of the Objects available on the Virtual Input Module.
BACnet settings for you so it is ready when the system is installed. Below is a quick checklist of settings that could be determined prior to installation. Contact Melink prior to installation with the following configuration settings (either fill in by hand or copy details in some other manner) and these can be configured on your Intelli-Hood system prior to installation.
Page 16
If you unsure of how many Exhaust Fans, Auxiliary Airflows or Hood Controllers your system will have, contact Melink and we can let you know how many of each are scheduled to be included in your system. NOTE: Actual number of Exhaust Fans, Auxiliary Airflows, and Hood Controllers is dependent upon the configuration of the Intelli-Hood system.
Page | 16 Configuring the Intelli-Hood System There are three different methods in which the user can configure the Intelli-Hood system. It can be configured through the Touchpad, directly over the network using the web-based configuration, or a configuration file can be uploaded through a USB Flash drive.
Page | 17 BACnet Configuration through the Touchpad There are system level BACnet configuration settings as well as BACnet configuration settings specific to each Exhaust Fan, Auxiliary Airflow and Hood Controller in the system. This describes how to get to each of these settings through the Touchpad. 1.
Page | 19 Networking Setup and Configuration There are a limited number of network configuration parameters for the Intelli-Hood system. This section describes each in detail. Use DHCP Tells the system whether it should use DHCP to obtain an IP address or not. The Intelli- Hood system defaults to “Yes”.
Page | 20 BACnet Setup and Configuration The Intelli-Hood system has separate system-level, Exhaust Fan, Auxiliary Airflow and Hood Controller specific BACnet configuration parameters. This section describes each in detail. System Controller BACnet Device Instance ID This specifies the Device Instance ID that will be used by the System Controller. The System Controller’s Device Instance ID defaults to 654000.
Page 22
Page | 21 Exhaust Fan, Auxiliary Airflow, Hood Controller, Virtual Input Module and Virtual Output Module Device Instance ID This is the statically assigning the Device Instance ID for each Exhaust Fan, Auxiliary Airflow, Hood Controller, Virtual Input Module and Virtual Output Module. If “BACnet Auto Number”...
Page | 22 Common BACnet Interfacing Use Cases This section describes some common use cases for BACnet interaction with the Intelli- Hood system and how to accomplish such tasks. Monitoring Fan Speeds The most common usage is to monitor the fan speed. There are several points that are useful for monitoring fan speed.
Page | 23 Setting Time on the Intelli-Hood system There are several Intelli-Hood functions, such as Schedules, that are most useful if the Intelli-Hood system is set for the correct time. The Intelli-Hood system can synchronize time using the Network Time Protocol. However, typical installations will segregate the BACnet network from outside internet access.
Page | 24 Appendix A: Device List and Device Instance Numbering The Intelli-Hood 3 System Controller is a scalable device that can control up to 64 VFDs. The items listed in the Object/Property Support Matrix list the points available from the Intelli-Hood 3 system at this time.
Page | 25 7. Virtual Input Modules are numbered immediately after the Virtual Output Modules. 8. Virtual Input Modules are sorted before being assigned a Device Instance Number. They are sorted first by its configured name, then by its address, then by an internal UUID to ensure a consistent sort order.
Page 27
Page | 26 Resulting Device Object List: Device Instance Device Object MAC Device Object Number Address Name 654000 142.51.5.36:0xBAC0 System Controller 654001 36.5.51.1:0xBAC0 KEF-02 654002 36.5.51.2:0xBAC0 KEF-05 654003 36.5.51.3:0xBAC0 MUA-41 654004 36.5.51.4:0xBAC0 HC-01 654005 36.5.51.5:0xBAC0 VOM-01...
Page 28
Page | 27 Scenario 2: System Controller IP Address: 10.20.21.100 Exhaust Fan 1: Fryer EF, Modbus Address 1 Exhaust Fan 2: Island EF, Modbus Address 2 Exhaust Fan 3: Grill EF, Modbus Address 3 Exhaust Fan 4: Banquet EF, Modbus Address 4 Auxiliary Airflow 1: West Supply, Modbus Address 41 Auxiliary Airflow 2: East Supply, Modbus Address 42 Auxiliary Airflow 3: 0-10VDC, Modbus Address 43...
Page | 28 Manual Device Instance Numbering Prior to June 25, 2014, only automated Device Instance Numbering was supported. The FW2014.06.25 firmware release added support for static Device Instance Numbering. This section describes how to statically set the Device Instance Numbers. The System Controller defaults its Device Instance Number to 654000.
Page | 29 Resulting Device Object List: Device Device Object MAC Device Object Instance Address Name Number 10.20.21.100:0xBAC0 System Controller 100.21.20.1:0xBAC0 0-10VDC 100.21.20.2:0xBAC0 Banquet EF 100.21.20.3:0xBAC0 East Supply 100.21.20.4:0xBAC0 Fryer EF 100.21.20.5:0xBAC0 Grill EF 100.21.20.6:0xBAC0 Island EF 100.21.20.7:0xBAC0 West Supply 100.21.20.8:0xBAC0 HC-01 100.21.20.9:0xBAC0...
Page 31
Page | 30 From the Intelli-Hood Touchpad, go to Menu->Status->VFDs. Status on each Exhaust Fan and Auxiliary Airflow is available with the BACnet Device Instance Number shown as the last item. Select Next to go to the next device in the list. If the Device Instance Number for an Exhaust Fan or an Auxiliary Airflow is not what you expected, then check the configuration for that device.
BACnet communication is available. If the serial number starts with “V4”, for example “V400020”, then you have a Lite System Controller and BACnet communication is not available. If you do have a Lite System Controller, contact Melink Corporation on how to obtain a standard System Controller.
Hood system is responding but the Intelli-Hood system’s time is not changing. Diagnosis: There was an issue with Time Synchronization and UTC Time Synchronization in system firmware FW2015.09.16 and earlier. If this is the case, then contact Melink about obtaining a firmware upgrade for your Intelli-Hood system.
Page 34
Page | 33 Virtual Input Module digital inputs and analog inputs keep resetting Problem: The Virtual Input Module’s digital inputs are set through the Operator’s Workstation and the system reacts to the change in state. After several minutes, all the digital inputs on the Virtual Input Module are reset.
Page | 34 Revision History Version Date Description 8-15-2013 Initial document release 2-6-2013 -Corrected Firmware Revision and Application Software Revision -Updated and expanded detail in Object Property Support Matrix -Added description for Device Instance numbering and Device Object MAC Address numbering 5-29-2014 Update formatting 9-16-2014...
