Split type room air conditioner wall mounted type
Hide thumbs Also See for ASYG07LMCE:
Table of Contents

Advertisement

Quick Links

SPLIT TYPE
ROOM AIR CONDITIONER
WALL MOUNTED TYPE
Indoor unit
ASYG07LMCE
ASYG09LMCE
CO NT ENT S
SPECIFICATIONS. . . . . . . . . . . . . . . . . . .
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . .
REFRIGERANT SYSTEM DIAGRAM. . . .
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . .
PCB CIRCUIT DIAGRAM . . . . . . . . . . . . .
ERROR DETECTION . . . . . . . . . . . . . . . .
PARTS (INDOOR UNIT) . . . . . . . . . . . . .
PARTS (OUTDOOR UNIT) . . . . . . . . . . .
ACCESSORIES . . . . . . . . . . . . . . . . . . .
Outdoor unit
AOYG07LMCE
AOYG09LMCE
1
2
4
5
6
8
9
16
19

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu ASYG07LMCE

Summary of Contents for Fujitsu ASYG07LMCE

  • Page 1 SPLIT TYPE ROOM AIR CONDITIONER WALL MOUNTED TYPE Indoor unit Outdoor unit ASYG07LMCE AOYG07LMCE ASYG09LMCE AOYG09LMCE CO NT ENT S SPECIFICATIONS....DIMENSIONS ..... .
  • Page 2 S P E C IFI CAT I ON S ELECTRICAL DATA FAN MOTOR AND FAN REVOLUTION NOISE LEVEL INDOOR UNIT MFD-12CYBL High 43 dB ASYG07LMCE ASYG09LMCE INDOOR UNIT’S Discrimination MFE-22AVAL Medium 40 dB OUTDOOR UNIT AOYG07LMCE AOYG09LMCE OUTDOOR UNIT’S Discrimination...
  • Page 3 D IM EN SI ON S INDOOR UNIT 870 mm 204 mm Drain hose Diameter Outside Inside : 13.8 mm 2016.11.21...
  • Page 4 OUTDOOR UNIT 663 mm 293 mm 454 mm 2016.11.21...
  • Page 5 R E FR I GE R A N T SY ST EM D I A GR A M Heat exchanger (indoor unit) Refrigerant direction Cooling 2-way valve 3-way valve Heating Compressor Refrigerant pipe diameter Muffler Strainer Liquid : 1/4" (6.35 mm) Gas : 3/8"...
  • Page 6 CI RCU IT DI AG R A M Models : ASYG07LMCE / AOYG07LMCE ASYG09LMCE / AOYG09LMCE OUTDOOR UNIT INDOOR UNIT Reactor Main PCB CN201 Orange White Yellow White Louver ( Up / Down ) Brown CN10 Pink Gray White White...
  • Page 7 P CB CI RC UI T D IA GR A M EARTH TERMINAL CONTROL UNIT ASYG07LMCE : EZ-0124CHSE ASYG09LMCE : EZ-0120MHSE OUTDOOR UNIT CN4 Thermistor Characteristics. CN7 DC Fan motor Temperature ( 20 ( 30 Thermistor TERMINAL Terminal Lead wire Pin No.
  • Page 8 I NVERTER ASSEMBLY AOYG07LMCE : EZ-0122CHUE AOYG09LMCE : EZ-012PHUE Compressor Winding resistance ( 07,09 Type ) 3.268 3.220 3.296 Compressor Winding resistance ( 12 Type ) EMI FILTER ESD-R-16C e.t.c. 1.30 REACTOR 2 TURNS TERMINAL 13mH 8A EMI FILTER UL3271 ZCAT2132-1130 AWG18 TO I NDOOR UNIT...
  • Page 9 Error display Display PCB microcomputers Wired E RR OR DET EC TION ● ● ◊ (10) communication error remote OPERATION TIMER ECONOMY Description controller Discharge temp. sensor error lamp lamp lamp ● ● ◊ Error code (green) (orange) (green) Serial communication error Compressor temp.
  • Page 10 P AR T S Ref. Description Part number INDOOR UNIT Remote Control 9319208008 ASYG07LMCE ASYG09LMCE Remote Control Holder 9318912005 Bracket Panel 9332882025 Electric Filter Holder 9332911008 Air Clean Filter Assy 9317250009 Air Filter 9332875010 Screw Cap 9309002074 2016.11.07...
  • Page 11 INDOOR UNIT ASYG07LMCE ASYG09LMCE Wire Shield Ref. Description Part number Wire Cover 9333504018 Louver Assy 9333353043 Diffuser Assy 9332998085 Front Panel Sub 9333525051 Assy (FUJITSU) 2016.11.07...
  • Page 12 INDOOR UNIT ASYG07LMCE ASYG09LMCE Front panel sub assy Ref. Description Part number Intake Grille Assy 9333526010 Front Panel C 9333497020 Under Cover 9333503011 Front Panel Cover R 9333502014 Front Panel R 9333500003 Front Panel Cover L 9333501017 Front Panel L 9333499000 2016.11.07...
  • Page 13 Ref. Description Part number Control Box 9332892000 Box Shield Assy Main PCB (ASYG07LMCE) 9709427033 Main PCB (ASYG09LMCE) 9709427019 Terminal 9900720001 Display Assy 9709430019 Room Thermistor Holder 9332868005 Thermistor Assy 9900930011 Cover Shield INDOOR UNIT ASYG07LMCE Earth Terminal ASYG09LMCE Control box...
  • Page 14 INDOOR UNIT ASYG07LMCE ASYG09LMCE Evaporator Ref. Description Part number Evaporator Total Assy 9332989090 Fan Motor 9603269005 Crossflow Fan Assy 9316830004 Bearing C Assy 9306628017 Casing Assy 9333009001 2016.11.07...
  • Page 15 INDOOR UNIT ASYG07LMCE ASYG09LMCE Casing assy Ref. Description Part number Casing 9332890006 Casing Cover F 9332909005 Casing Cover B 9332908008 R and L Louver 9332891003 Fan Guard 9332905007 Drain Cap 9316177017 Drain Hose Assy 9316904002 2016.11.07...
  • Page 16 INDOOR UNIT ASYG07LMCE ASYG09LMCE Casing assy Ref. Description Part number Motor Holder L/R 9332859003 Cable Guide 9332903003 Step Motor 9900790004 Step Motor 9900790011 2016.11.07...
  • Page 17 P A R TS Ref. Description Part number OUTDOOR UNIT Protective Net 9332855005 AOYG07LMCE Thermistor Holder 9332505009 AOYG09LMCE Top Panel Assy 9332977004 Front Panel Assy 9332965001 Cabinet Left Assy 9332962000 Emblem 9319151007 Cabinet Right Assy 9332963007 Switch Cover A Assy 9332964011 Switch Cover B 9332843002...
  • Page 18 OUTDOOR UNIT AOYG07LMCE AOYG09LMCE Ref. Description Part number Reactor Assy (AOYG07LMCE) 9900872014 Reactor Assy (AOYG09LMCE) 9900787028 PCB Holder 9332506013 Main PCB with Terminal (07) 9709434147 Main PCB with Terminal (09) 9709434031 Heat Sink B 9332522006 Thermistor Assy 9900901011 Thermistor 9900880019 2016.11.09...
  • Page 19 OUTDOOR UNIT AOYG07LMCE AOYG09LMCE Ref. Description Part number Condenser Total Assy 9332924008 Compressor Assy 9317083034 Solenoid 9970079030 4-way Valve Assy 9333012001 Expansion Valve Coil 9970137013 Pulse Motor Valve Sub Assy 9333023007 2016.11.09...
  • Page 20 A C C ES S O RI ES INDOOR UNIT OUTDOOR UNIT Name and Shape Part number Name and Shape Part number Name and Shape Bracket Panel Cloth tape 9310519004 Drain pipe assy 9332574005 9332882025 Tapping screw 0700076046 (M4 x 25 mm) Remote Control 9319208008 Tapping screw...
  • Page 21 1611G4556...
  • Page 22 SPLIT TYPE ROOM AIR CONDITIONER WALL MOUNTED type INVERTER SERVICE INSTRUCTION Models Indoor unit Outdoor unit AO*G07LMCA AS*G07LMCA AO*G09LMCA AS*G09LMCA AS*G12LMCA AO*G12LMCA AS*G14LMCA AO*G14LMCA ASYG07LMCE AOYG07LMCE ASYG09LMCE AOYG09LMCE AOYG12LMCE ASYG12LMCE AOYG14LMCE ASYG14LMCE R410A...

  • Page 23: Table Of Contents

    CONTENTS 1. DESCRIPTION OF EACH CONTROL OPERATION 1. COOLING OPERATION....................01-01 2. HEATING OPERATION....................01-02 3. DRY OPERATION......................01-03 4. AUTO CHANGEOVER OPERATION................01-04 5. INDOOR FAN CONTROL....................01-05 6. OUTDOOR FAN CONTROL..................01-07 7. LOUVER CONTROL..................... 01-08 8. COMPRESSOR CONTROL..................01-09 9.

  • Page 24: Description Of Each Control Operation

    R410A WALL MOUNTED type INVERTER 1 . DESCRIPTION OF EACH CONTROL OPERATION...

  • Page 25: Cooling Operation

    1. COOLING OPERATION A sensor (room temperature thermistor) built in the indoor unit body will usually perceive difference or variation between a set temperature and present room temperature, and controls the operation frequency of the compressor. * If the room temperature is 2°C higher than a set temperature, the compressor operation frequency will attain to maximum performance.

  • Page 26: Heating Operation

    2. HEATING OPERATION A sensor (room temperature thermistor) built in the indoor unit body will usually perceive difference or variation between a set temperature and present room temperature, and controls the operation frequency of the compressor. * If the room temperature is lower by 3°C than a set temperature, the compressor operation frequency will attain to maximum performance.

  • Page 27: Dry Operation

    3. DRY OPERATION The compressor frequency shall change according to the temperature, set temperature, and room temperature variation which the room temperature sensor of the indoor unit body has detected as shown in the Table 5. However, after the compressor is driven, the indoor unit shall run at operation frequency of 64rps (07/09 type), 61rps (12/14 type), for a minute.

  • Page 28: Auto Changeover Operation

    4. AUTO CHANGEOVER OPERATION When the air conditioner is set to the AUTO mode by remote control, operation starts in the optimum mode from among the Heating, Cooling, Dry and Monitoring modes. During operation, the optimum mode is automatically switched in accordance with temperature changes. The temperature can be set between 18°C 30°C...

  • Page 29: Indoor Fan Control

    5. INDOOR FAN CONTROL 1. Fan speed ( Table 6 : Indoor fan speed ) ( ) model 14 ( ) model 14 Speed (rpm) Speed (rpm) Operation mode Air flow mode Operation mode Air flow mode Powerful Powerful Heating 1380 (1420) 1380 (1420) Cooling/ Fan...
  • Page 30 6. COOL AIR PREVENTION CONTROL (Heating mode) The maximum value of the indoor fan speed is set as shown in Fig.6 based on the detected temperature by the indoor heat-exchanger sensor on heating mode. ( Fig.6 : Cool air prevension control ) <Powerful operation>...

  • Page 31: Outdoor Fan Control

    6. OUTDOOR FAN CONTROL 1. Outdoor Fan Motor Following table shows the type of the outdoor fan motor. The control method is different between AC motor and DC motor. ( Table 8 : Type of Motor ) AC Motor DC Motor Model 07/09/12/14 2.

  • Page 32: Louver Control

    7. LOUVER CONTROL 1. VERTICAL LOUVER CONTROL (Function Range) Each time the button is pressed, the air direction range will change as follow: Fig.9 : Air Direction Range The Remote Controller's display does not change. If you set the angle to position 4.7 for more than 30 minutes in COOL or DRY mode, they automatically return to position 3.

  • Page 33: Compressor Control

    8. COMPRESSOR CONTROL 1. OPEARTION FREQUENCY RANGE The operation frequency of the compressor is different based on the operation mode as shown in the Table 12. (Table 12 : Compressor frequency range) Cooling / Dry Heating Model Minimum Maximum Minimum Maximum 22rps 79rps...

  • Page 34: Timer Operation Control

    9. TIMER OPEARTION CONTROL 9-1 WIRELESS REMOTE CONTROLLER The Table 14 shows the available timer setting based on the product model. ( Table 14 : Timer Setting ) Model ON TIMER / OFF TIMER PROGRAM TIMER SLEEP TIMER 07/09/12/14 1. OPEARTION FREQUENCY RANGE OFF timer : When the clock reaches the set time, the air conditioner will be turned off.
  • Page 35 3. SLEEP TIMER If the sleep is set, the room temperature is monitored and the operation is stopped automatically. If the operation mode or the set temperature is change after the sleep timer is set, the operation is continued according to the changed setting of the sleep timer from that time ON. In the cooling operation mode When the sleep timer is set, the setting temperature is increased 1°C.
  • Page 36 9-2 WIRED REMOTE CONTROLLER (OPTION) The Table15 shows the available timer setting based on the product model. ( Table15 : Timer Setting ) ON TIMER / OFF TIMER WEEKLY TIMER TEMPERATURE SET BACK TIMER Model 07/09/12/14 ON TIMER / OFF TIMER Same to 9-1 1.ON TIMER / OFF TIMER and shown in those.

  • Page 37: Electronic Expansion Valve Control

    10. ELECTRONIC EXPANSION VALVE CONTROL The most proper opening of the electronic expansion valve is calculated and controlled under the present operating condition based on the Table16. The compressor frequency, the detected temperature by the discharge temperature sensor, the indoor heat exchanger sensor, the outdoor heat exchanger sensor, and the outdoor temperature sensor. ( Table16 : The pulse range of the electronic expansion valve control ) Operation mode Pulse range...

  • Page 38: Auto Restart

    14. AUTO RESTART When the power was interrupted by a power failure, etc. during operation, the operation contents at that time are memorized and when power is recovered, operation is automatically started with the memorized operation contents. When the power is interrupted and recovered during timer operation, since the timer operation time is shifted by the time the power was interrupted, an alarm is given by blinking (7 sec ON/2 sec OFF) the indoor unit body timer lamp.

  • Page 39: Compressor Preheating

    17. COMPRESSOR PREHEATING When the outdoor heat exchanger temperature is lower than 5°C and the all operation has been stopped for 30 minutes, power is applied to the compressor and the compressor is heated. (By heating the compressor, warm air is quickly discharged when operation is started.) When operation was started and when the outdoor temperature rises to 7°C or greater,...

  • Page 40: Powerful Operation

    21. POWERFUL OPERATION The POWERFUL OPERATION functions by pressing POWERFUL button on the remote controller. The indoor unit & outdoor unit will operate at maximum power as shown in Table22. (Table22) Powerful operation COMPRESSOR FREQUENCY Maximum FAN CONT. MODE Powerful SETTING LOUVER Cooling/ Dry : 3, Heating : 6 Release Condition is as follows.

  • Page 41: Defrost Operation Control

    22. DEFROST OPERATION CONTROL 1. CONDITION OF STARTING THE DEFROST OPERATION The defrost operation starts as shown in the following Table 23. (Table 23 : Condition of starting Defrost Operation) Compressor integrating operation time Normal defrost Less than 25 minutes More than 25 minutes Outdoor heat exchanger temp.
  • Page 42 3. Defrost Flow Chart The defrosting shall proceed by the integrating operation time, outdoor temperature and outdoor heat exchanger temperature as follows. Heating operation start : Compressor ON (Not defrosted for 10 minutes) Integrating defrost Normal defrost Intermittent operation Continuous operation utside air temp.

  • Page 43: Off Defrost Operation Control

    23. OFF DEFROST OPEARTION CONTROL When operation stops in the [Heating operation] mode, if frost is adhered to the outdoor unit heat exchanger, the defrost operation will proceed automatically. In this time, if indoor unit operation lamp flashes slowly (7 sec ON / 2 sec OFF), the outdoor unit will allow the heat exchanger to defrost, and then stop.

  • Page 44: Various Protections

    24. VARIOUS PROTECTIONS 1. DISCHARGE GAS TEMPERATURE OVERRISE PREVENSION CONTROL The discharge gas thermosensor (discharge thermistor : Outdoor side) will detect discharge gas temperature. When the discharge temperature becomes higher than Temperature , the compressor frequency is decreased 20rps, and it continues to decrease the frequency for 20rps every 120 seconds until the temperature becomes lower than Temperature .
  • Page 45 3. ANTIFREEZING CONTROL (Cooling and Dry mode) The compressor frequency is decrease on cooling & dry mode when the indoor heat exchanger temperature sensor detects the temperature lower than Temperature . Then, the anti-freezing control is released when it becomes higher than Temperature . (Table 27 : Anti-freezing Protection Operation / Release Temperature) Outdoor temperature Temperature...

  • Page 46: Appending Data

    R410A WALL MOUNTED type INVERTER 3 . APPENDING DATA...

  • Page 47: Function Setting

    3-1. FUNCTION SETTING 3-1-1 INDOOR UNIT Follow the instructions in the Local Setup Procedure, which is supplied with the remote control, in accordance with the installed condition. After the power is turned on, perform the Function Setting on the remote control. The settings may be selected between the following two: Function Number or Setting Value.
  • Page 48 1-5. Indoor room temperature sensor switching function (Only for Wired remote controller) The following settings are needed when use the control by Wired remote controller temperature sensor. Factory setting) Setting Description Function Number Setting Value * If setting value is "00" : Room temperature is controlled by the indoor unit temperature sensor. * If setting value is "01"...

  • Page 49: Procedures To Change The Function Setting For Wireless Rc

    3-1-2 Procedures to change the Function Setting for wireless RC This procedure changes to the function settings used to control the indoor unit according to the installation conditions. Incorrect settings can cause the indoor unit malfunction. After the power is turned on, perform the "FUNCTION SETTING" according to the installation conditions using the remote controller.
  • Page 50 Selecting the Remote Controller Signal Code (1) Press the START/STOP( ) button until only the clock is displayed on the remote controller display. (2) Press the MODE button for at least 5 seconds to display the current signal code. (initially set to (3) Press the SET TEMP.( ) ( ) buttons to change the signal code between Match the code on the display to the air conditioner signal code.

  • Page 51: Thermistor Resistance Values

    3-2. Thermistor Resistance Values 3-2-1 INDOOR UNIT Room temperature thermistor Indoor heat exchanger thermistor Resistance(k ) Voltage(V) Resistance(k ) Voltage(V) Temp ( C) Temp ( C) -10.0 55.46 0.76 -30.0 977.6 0.24 -5.0 42.36 0.95 -25.0 713.2 0.33 32.67 1.17 -20.0 526.8 0.43...
