Boston Acoustics DJ030105-V1 Connecting Manual

Connecting the Apple
to your MicroSystem CD
1a. Connect iPod to Front Input
Using the required cable, connect the headphone output
on the iPod to the Front "AUX 3" input located on the
front right hand side of the MicroSystem CD.
Required Cable: Stereo
2. Turn On iPod and Set Volume
Turn on the iPod and set the volume to 50% to 70% of
total output.
Note: As there is no display on the iPod Shuffle
may need to re-adjust the volume on the iPod Shuffle to
better match the input's sensitivity (after you complete
step 3) if the output level is not loud enough on the
Microsystem CD.
3. Select "Aux 1" Input on MicroSystem CD
If using the Front Input "Aux 3":
Select "Aux 3" on the MicroSystem CD by pressing the "AUX"
button three times, the Microsystem CD display will read "AU-3".
If using the Rear Input "Aux 1":
Select "Aux 1" on the MicroSystem CD by pressing the "AUX"
button once, the Microsystem CD display will read "AU-1".
® iPod
1 ⁄ -Inch to Stereo 1 ⁄ -Inch Cable
8 8
Boston Acoustics, Inc.
300 Jubilee Drive
Peabody, MA 01960
www.bostonacoustics.com
®
1b. Connect iPod to Rear Input
Using the required cable, connect the headphone output
on the iPod to the Rear "AUX 1" input located on the
rear right hand side of the MicroSystem CD.
Required Cable: Stereo
® , you
Boston, Boston Acoustics, and the Boston Acoustics logo are registered
trademarks of Boston Acoustics, Inc. iPod, iPod Shuffle, and the iPod design
are registered trademarks of Apple Computers. Inc.
© 2005 Boston Acoustics, Inc. All rights reserved.
1 ⁄ -Inch to Stereo RCA Cable
8
VOLUME
DJ030105-V1
