- Page 1 Installation and User Manual DTS Pro Series surround encoder A Full-Featured Suite for Today’s Digital Audio Workstation...
- Page 2 Confidential Contains confidential proprietary information owned by Digital Theater Systems, Inc., including but not limited to trade secrets, know-how, technical and business information. Not for disclosure except under terms of a Non-Disclosure Agreement accepted by recipient and by an actually authorized agent of Digital Theater Systems, Inc. Unauthorized disclosure is a violation of State, Federal, and International laws.
-
Page 3: Table Of Contents
Installation and User Manual – Contents INSTALLATION 1.1. PC Standalone Installation 1.2. Mac Standalone Installation OVERVIEW USING THE PRO PACKER ENCODING IMMEDIATELY AFTER PACKING USING THE ENCODER IN STANDALONE MODE ENCRYPTING A FILE 6.1. Decrypting a File DVD AUTHORING FOR DTS UNINSTALLING THE SOFTWARE DIALOG NORMALIZATION DTS Pro Series Surround Encoder... -
Page 4: Installation
DTS Pro Series Surround Encoder Installation PC Standalone Installation System requirements PC computer, Pentium 4, 1GHz or higher (recommended) 256 MB RAM 1 hard drive, 7200 RPM minimum, 200 MB free disk space Greater than 20 GB disk space for audio files USB port for the license adapter key (dongle) Windows XP Home edition or XP Professional (SP1) Surround Encoder installation procedure... -
Page 5: Mac Standalone Installation
Install the adapter key (dongle) (DTS #E907-02) into a USB port on your PC after It is the responsibility of the owner of the DTS Pro Series Surround Note: Encoder to keep the adapter key (dongle) in a safe and secure location. If the adapter is lost, DTS has no obligation to replace it. - Page 6 DTS Pro Series Surround Encoder Proper privileges are required to install and uninstall Surround Important: Encoder software, including the WIBU driver for the auto-detected adapter key. Displaying System information Click the Apple icon at the top left of the screen and select The operating system name will display in a pop-up box, along with the version number.
- Page 7 Double-click the blue WIBU Vise icon to launch the installer. Choose Easy Install . The wizard will take you through the rest of the procedure. Install the DTS Encoder. Double-click on the icon DTSProSeriesEncoder.pkg to start the installer. The wizard will take you through the rest of the procedure.
-
Page 8: Overview
DTS Pro Series Surround Encoder 2. Overview There are three components to the Pro Series Surround Encoder system, Pro Packer, Pro Encoder, and Pro Encrypter utility. All audio files to be encoded must first be processed using the Important: Pro Packer. Start with the Pro Packer The purpose of the Pro Packer is to bring all the source audio files together into a single file. -
Page 9: Using The Pro Packer
3. Using the Pro Packer Start the DTS Multi-channel Pro Packer (activate the Pro Packer icon). The Pro Packer screen will display. Figure 2. Pro Packer — Initial screen Our example In this example, 48 kHz files are being packed and then encoded to produce a DTS 5.1 DVD. - Page 10 DTS Pro Series Surround Encoder LFE is set to ON. See Table 1, page 11. Sample rate is set to 48 kHz. The Sample rate here must match the sample rate of the source files. See 3 dB Rear channel attenuation is left OFF. 3 dB rear channel attenuation is used in cases where you have a theatrical master that has not been remixed or repurposed for DVD, and the rear surrounds (right and left) are typically 3 dB higher than they should be for...
- Page 11 If the audio track is intended to sync with video, be sure to 10. Frame rate: match its frame rate. If the video reference is drop frame , you MUST select drop frame here. If it is important to match the start of the audio track to some specific point in the video, enter the Start time (hh:mm:ss:ff) format.
- Page 12 DTS Pro Series Surround Encoder Repeat step 11 for the other channels. Input files have been selected for all channels. For each input file, the sample rate, bit depth, and duration is identified. See note 1, below. Use the duration information to check that the input files are identical in length.
- Page 13 Click “Pack and Encode” encoder. (If the output file already exists, the Packer will prompt you to overwrite it.) The above prompt will display when the packing is finished. Then the Surround Encoder program will be automatically activated (next step). At this point, the packed file(.agm extension) will be found in the output directory.
-
Page 14: Encoding Immediately After Packing
DTS Pro Series Surround Encoder 4. Encoding Immediately after Packing Since we chose “Pack and Encode” program starts automatically when the Packer is finished (Figure 3) and runs in a separate window on the desktop. Figure 3. DTS Pro Series Surrounf Encoder Screen Almost all the settings on this page are carried over from the Packer program. - Page 15 These fields are automatically filled with information carried in the packed file. — click this button to reload the values from the packed file, if Reset necessary. 4. Bit Rate and Output type For 44.1 kHz and 88.2 kHz source files, only one bit rate (1234800) and output type (.wav) are possible.
-
Page 16: Using The Encoder In Standalone Mode
DTS Pro Series Surround Encoder Click the Encode A window will prompt you to review the encoder settings and confirm. Click Encode. A progress bar will display. When encoding is finished, a output file name and location. Click In the Output directory, you will see two additional files, the .log (encoding report) and the .cpt (encoded) file. - Page 17 Click “Pack local file” exists, the Packer will prompt you to overwrite it.) This prompt will display when the packing is finished. In the selected output directory, you will see an additional file — the .agm packed file. In the Source file section, use the Browse function to select the packed.agm file that you want to encode.
- Page 18 DTS Pro Series Surround Encoder In the DTS Settings section, choose the Normalization 3dB rear channel attenuation the Packer. (See step 5 on page 8 for explanation.) Bit Rate Output type rate of the source material. For 44.1 kHz and 88.2 kHz source files, only one bit rate (1234800) and output type (.wav) are possible.
- Page 19 Click the button. Encode A confirmation prompt will appear. Review the settings and, if they are OK, click A status bar at the bottom of the screen will indicate the progress of the encode task. Next, a prompt will inform you that the encoding task is finished. Click In the output directory, the output file (.cpt in this example) and the encoding report (.log) will be listed.
-
Page 20: Encrypting A File
DTS Pro Series Surround Encoder 6. Encrypting a File Use the Pro Encrypter program to encrypt an .agm packed file for sending over an unsecure network to another location. The DTS Pro Encrypter screen will display. Figure 4: Encryption Utility screen In the Source section, use the Browse function to select the source .agm file to be encrypted. -
Page 21: Decrypting A File
Enter a password (at least 8 characters long), and type the password again to confirm. Click the Encrypt button to begin the process. A confirmation prompt will display. Review the choices, then click Yes to proceed. A progress bar will display at the bottom of the screen while the encryption is processing, then this confirmation prompt will display when the file has been encrypted. -
Page 22: Dvd Authoring For Dts
DTS Pro Series Surround Encoder 7. DVD Authoring for DTS A complete discussion of audio encoding for DTS can be found in Production with DTS Coherent Acoustics Audio, which can be downloaded from the DTS website at: http://www.dtsonline.com/media/uploads/pdfs/DVD_Authoring.pdf 8. Uninstalling the Software PC Version For the Windows version, open the Settings\Control Panel and click Add/Remove Programs . -
Page 23: Dialog Normalization
Move any aliases you manually created to the Trash. Empty the Trash after deleting the above files and folder. 9. Dialog Normalization Dialog Normalization is the use of metadata to control playback level. It has no effect on encoding or decoding. It is an instruction to playback equipment to adjust the level of all channels, post-decoding. - Page 24 DTS Pro Series Surround Encoder – Installation and User Manual The purpose of is to achieve a consistent level of dialog from one DIALNORM program or program source to the next. End-users set volume to achieve a pleasing and intelligible level of dialog. However, dialog level varies considerably across different program types.
- Page 25 Installation and User Manual – DTS Pro Series Surround Encoder...
- Page 26 DTS Pro Series Surround Encoder – Installation and User Manual...
- Page 27 Installation and User Manual – DTS Pro Series Surround Encoder...
- Page 28 DTS Pro Series Surround Encoder – Installation and User Manual DTS Pro Series surround A Full-Featured Suite for Today’s Digital Audio Workstation DTS technologies deliver the highest quality audio available on the market today. With more than 280 million DTS-licensed consumer electronics products available worldwide, there s a compelling reason for content owners and producers to be releasing DTS-encoded software for movies, music and more.
