Summary of Contents for Hawkins 321591
- Page 1 Optimizer Basket OWNER’s Manual For Part Number 321591 Revised 10.19 308.708.8185 | Hawkins@HawkinsAg.com | Owner’s Manual Part Number (123001) Rev. 10/19...
-
Page 2: Table Of Contents
Table of Contents General Information HOW TO USE THIS MANUAL 1 WARRANTY INFORMATION 2 SAFETY 3 SIGNAL WORDS 3... -
Page 4: How To Use This Manual 1
Safety Information, Installation Guide, Operation Guide, and a Part Number Index. The remaining sections divide the machine into assemblies and sub-assemblies which illustrate and list all parts. Hawkins Ag parts in this manual are specially designed for this machine and should be replaced with Hawkins Ag parts only. -
Page 5: Warranty Information
Thank you for your purchase of Optimizer Basket row units. Putting your trust in our equipment is something we don’t take lightly and are humbled that you chose Hawkins Ag. Having designed all of our equipment with farmers like you in mind, we hope you enjoy years of productive use from it. -
Page 6: Safety
If you have questions not answered in this manual or require additional copies or the manual is damaged, please contact Hawkins Ag, 2120 4th Ave., Holdrege, NE 68949, 308.708.8185, or visit our website: www.hawkinsag.com 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19... -
Page 7: Equipment Safety Guidelines
Observe all safety signs and practice the instructions on them. Never exceed the limits of a piece of machinery. If its ability to do a job, or to do so safely, is in question - DON’T TRY IT. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19... -
Page 9: Safety Signs
REMEMBER: If Safety Signs have been damaged, removed, become illegible or parts replaced without decals, new decals must be applied New decals are available from Hawkins Ag Hawkins Ag 2120 4th Ave. Holdrege, NE 68949 308.708.8185 www.hawkinsag.com 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19... -
Page 10: Safety Sign Care
Replace safety signs that are missing or have become illegible. • Replaced parts that displayed a safety sign should also display the current sign. • Safety signs are available from Hawkins Ag. How to Install Safety Signs • Be sure that the installation area is clean and dry. -
Page 11: Operational Safety
Operational Safety REmember Your best assurance against accidents is a careful and responsible operator. If there is any portion of this manual or function you do not understand, contact Hawkins Ag. Before Operation • Carefully study and understand this manual. - Page 12 If equipment has been altered in any way from the original design, the manufacturer does not accept any liability for injury or warranty. • A first aid kit should be kept readily accessible while performing maintenance on this equipment. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19...
-
Page 14: Installation Guide
4 x 413508 4 x 412058 1/2” Lock Washer 1/2”-13 Nut 1/2”-13 x 1 1/2” Carriage Bolt Pin 1 x 333099 1 x 321590 1 x 321592 Pin Clip 1 x 333021 Basket Adapter Basket Insert 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19... - Page 15 11 - Using 3/4” Wrench and Rubber Mallet, carefully remove Orthman™ 1tRIPr™ Basket. All parts can be set aside and will NOT be reused. CAUTION To avoid crushing hazard, DO NOT place any body part beneath the basket as you remove it. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19...
- Page 16 21 - Using four (4) Carriage Bolts (411785), four (4) 1/2” Lock Washers (413508) and four (4) 1/2” Nuts (412058), attach the Basket Adapter (321590) to the 1tRIPr™ row unit. NOTE: Due to OEM Frame Variations, some bolt heads may be tight to frame. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19...
- Page 17 31 - Pin new Basket Insert (321592) into Basket Adapter (321590) using Pin (333099) and securing with Pin Clip (333021). CAUTION To avoid crushing hazard, DO NOT place any body part beneath the Optimizer Basket while pinning basket into adapter. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19...
- Page 18 To ensure sealing, tube ends need to be cut smooth and square. • Ensure regulator exhaust line is routed out away from regulator and down to prevent moisture from entering into the system. NOTE: See next page for Air Hose Diagram. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19...
-
Page 19: Air Hose Diagram 13
The location of the supply line to the main line is unimportant. • The air flows from the air compressor, to the air regulator, to the supply line, to the row unit line, and finally to the air bag. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19... - Page 20 42 - Plumb all lines in parallel as shown on page 13, from an air regulator to the Optimizer Baskets. NOTE: Length will vary by model of 1tRIPr™. We recommend a 5’ air line for 2009 and newer machines, older will be 6’ or longer. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19...
-
Page 22: Operations
OEM baskets. Running in too wet of conditions could still cause some plugging. In that case, it is recommended to reduce pressure or wait for conditions to improve. NOTE: These settings are recommendations only. Your soil, moisture, and other variables may require you to adjust slightly differently than recommended. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19... -
Page 23: Adjustments 17
Optimizer Basket Removal When field conditions don’t require use of the Optimizer Basket or it is not desired, simply remove the basket assembly by pulling the pin and carefully removing the basket (see Installation Guide Step 3). 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19... -
Page 24: Maintenance
• DO work to regularly maintain your Optimizer Baskets. With proper care, you can expect a lon- ger and more effective lifespan for all of your Hawkins equipment. • DO check that baskets rotate freely before each use. Failure of basket to rotate freely may decrease effectiveness and cause damage to the Optimizer Basket. -
Page 25: Troubleshooting
Clogged up with mud. Or, wait for conditions to improve. Basket not turning properly Seized bearing. Replace bearings with quality Hawkins Parts. Not holding pressure Pressure leak in system. Check system for leak. Repair leak if found. Adjust regulator to operating pressure. - Page 26 (27) (45) (63) 7/16 (41) (72) (100) (61) (110) (155) 9/16 (95) (155) (220) (128) (215) (305) (225) (390) (540) (230) (570) (880) (345) (850) (1320) Bolt Head Identification Grade 2 Grade 5 Grade 8 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19...
-
Page 28: Parts Guide
5/8-11 Hex Jam Nut 411599 3/4-10 x 7.5 GR8 Hex Head Bolt 413072 3/4 Flat Washer SAE 410012 3/4-10 Nut Center Lock 412058 1/2-13 Nut 411785 1/2-13 x 1 1/2 Carriage Bolt 413508 1/2 Lock Washer 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19... -
Page 29: Basket Insert
Socket Head Screw 321218 Spacer Bushing 410012 3/4-10 Lock Nut 321497 Bearing With Block 411508 3/8-16 x 1.25 GR5 Bolt 412006 3/8-16 Nut 321593 Basket Frame 333099 1/2 x 4 bent pin 333021 Cotter pin bow 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 10/19... - Page 30 308.708.8185 | HawkinsAg.com 2120 4th AVE, Holdrege, NE 68949 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 09/19...
