Ortronics MM6VML706 Assembly Instructions

STEPS:

1. Before mounting the cable cage, inventory material contents per Sheet 2 of
5 of the instruction sheets.

FIGURE 1 INSTRUCTIONS: Dual rack front mounting.

1. Adjust rack spacing to be 2-1/2" apart. Attach 3 brackets (with hooks pointing up),
starting at the bottom and working up using the #10 x ½" hex washer screws. Place
the last bracket upside down at the top of the cage and place the cage over the
attached brackets and secure the top bracket using the #10 x ½" hex washer head
screws.

FIGURE 2 INSTRUCTIONS: Single rack front mounting.

1. Attach cable cage per Figure 1 (Sheet 3 of 5), using #10 X ½" hex washer head
screws to rack side only.
2. Insert the square plastic nuts into the side of the rack at each bracket location.
3. Secure end support brackets using #10 x ½" hex washer head screws into the nuts.
4. Attach end brackets to cage brackets using #10 x ½" hex washer screws.

FIGURE 3 INSTRUCTIONS: Swing latch replacement installation.

1. Installation can be either right or left hand swing outs.
2. Position latch at end of ring and tap into place with a rubber mallet or piece of wood.
FILE: 716\014191.XLS
INSTRUCTION SHEET:
71601419
125 EUGENE O' NEILL DRIVE
NEW LONDON, CT 06320
PHONE: 860-445-3800
FAX:
6" x 6" CABLE MANAGEMENT CAGE, MIGHTY MO 6
ASSEMBLY INSTRUCTIONS
REV: ECN: SHT:
00 1 OF 5
860-405-2990
BY: DATE:
S. LEVESQUE 03/26/04
6"x 6" CABLE MANAGEMENT
TITLE:
CAGE FOR MIGHTY MO 6
CHK. BY: DATE:
D. Bogue 03/26/04
APP. BY: DATE:
MEM 03/26/04
