- Page 1 User Manual User Manual Countertop Electric Range 02/2020 Models: 177CER200 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
-
Page 2: Table Of Contents
User Manual Index Important Safety Information �������������������������������������������������������������� 3 Specifications �������������������������������������������������������������������������������������� 4 Installation ������������������������������������������������������������������������������������������ 4 Operation �������������������������������������������������������������������������������������������� 5 Cleaning ���������������������������������������������������������������������������������������������� 5 Troubleshooting ���������������������������������������������������������������������������������� 6 Parts Diagram �������������������������������������������������������������������������������������� 7 Equipment Limited Warranty ��������������������������������������������������������������� 8 www.AvantcoEquipment.com... -
Page 3: Important Safety Information
User Manual Important Safety Information WARNING! When using electrical appliances, basic safety precautions should always be followed, including the following: 1. Read all instructions carefully and completely. 2. For commercial use only. 3. Do not touch hot surfaces. 4. Protect against electrical shock by keeping all cords, plugs, and other electrical components away from water or other liquids. -
Page 4: Specifications
User Manual Specifications OVERALL MODEL # DESCRIPTION VOLTAGE WATTAGE PLUG DIMENSIONS Dual 9" Solid 177CER200 15"L x 25"W x 9"H 208-240V 3000-4000W NEMA 6-20P Plate Electric Range Installation CAUTION! This unit should be installed in a non-combustible location only. CAUTION! The installation must be performed by qualified personnel or the warranty will be void. -
Page 5: Operation
User Manual Electrical Connections Check the serial plate to determine what voltage this unit requires. WARNING: IMPROPER GROUNDING COULD RESULT IN ELECTRICAL SHOCK. This unit is equipped with a three-prong (grounded) electrical plug for your protection against shock hazard. It should be plugged directly into a properly grounded three-prong receptacle. DO NOT CUT OR REMOVE THE GROUNDING PRONG FROM THIS PLUG. -
Page 6: Troubleshooting
User Manual Troubleshooting PROBLEM CAUSE REMEDY The equipment is not plugged in Plug in the equipment Indicator light does not come on when the selector switch is in a position other than Indicator light malfunction Replace pilot light “OFF” or 0 Selector switch malfunction Replace selector switch Selector switch malfunction... -
Page 7: Parts Diagram
User Manual Parts Diagram DESCRIPTION ITEM # DESCRIPTION ITEM # Burner 177PCER2001 10 Triangle Plate Burner Insulation 11 Foot 177PCER20011 Insulation Plate 12 Control Panel Shell 13 Knob 177PCER20013 Wire Buckle 14 Control Panel Sticker Power Cord 177PCER2006 15 Working Indication Light 177PCER20015 Terminal Block 177PCER2007... -
Page 8: Equipment Limited Warranty
Equipment Limited Warranty Avantco warrants its equipment to be free from defects in material and workmanship for a period of 1 year. This is the sole and exclusive warranty made by Avantco covering your Avantco brand equipment. A claim under this warranty must be made within 1 year from the date of purchase of the equipment.
