MASTERLINE 475 Operator’s Manual, Parts List & Service Manual

Outperforms
Operator's Manual, Parts List & Service Manual
STOP!
MAINTENANCE TIP:
SAfETy PRECAUTIONS
1. Before using sprayer with chemicals, fill sprayer with fresh water
to assure that you have it properly assembled; pressurize and
practice spraying. Also, check for any leaks at this time. When
thoroughly familiar with the sprayer operation, follow normal
operating procedures.
2. Ensure all pressure in the sprayer is relieved by locking the shut-
off valve in the open position.
wARNINg:
Chemicals can be harmful to individuals and the environment if improperly used. In addition, some chemicals are caustic, corrosive or poisonous
and should be avoided. Read warnings and chemical manufacturers' instructions. MASTERLINE high density polyethylene sprayers are fitted
with Viton® seals which are resistant to a wide variety of agricultural and household chemicals; however, care should be exercised to ensure that
sprayer components are clean, functioning properly, and in a good state of repair before and during use. If in doubt about a particular chemical,
check with the manufacturer. If you suspect or observe indications that the material may be unsafe in a MASTERLINE sprayer....STOP. DO NOT
USE OR APPLy ChEMICAL. ALwAyS wEAR RUbbER gLOvES, SAfETy gOggLES, AND APPROPRIATE PROTECTIvE CLOThINg.
• Read and follow operating instructions.
• Do not fill with, use or spray flammable materials.
• Do not modify sprayer.
• Never spray in the direction of humans, animals or property
which might be injured or damaged by spray formula.
•
Do not use disinfectants, solvents or impregnating agents unless
first tested to ensure they are not harmful to the environment or
sprayer.
• Do not use liquids with a temperature above 110°F (43°C).
• Rinse and clean sprayer thoroughly after using. Chemicals can
be dangerous and cause serious injury to persons, animals,
plants and environment.
• Wear appropriate protective clothing to prevent contact with
chemical agents.
• Disposal of contaminated rinse should be in accordance with
applicable ordinances. Observe the precautionary instructions of
the chemical manufacturer.
ASSEMbLy INSTRUCTIONS:
SPRAy TIP ASSEMbLy
Spray tips should be assembled as
shown. O-rings are used in place of
gaskets in some sprayers.
See Page 11 for Handle Installation.
MasterLine Manual 2007.indd 1
475
If you are missing parts, instructions or have questions, DO NOT
take this unit back to the store. Call 1-800-888-4897 and MasterLine
will send the missing parts/information to you promptly
Cap gasket is prelubricated for improved sealing. Occasional lubrication
is recommended, use petroleum jelly or non-water soluble grease.
1. Flat Spray Nozzle
2. Filter
3. Jet Stream Nozzle
4. Swirl Plate
5. Brass Adjustable Nozzle
3. Avoid contact with chemicals.
4. Always wear rubber gloves, safety goggles, appropriate
protective clothing.
5. Work in a well ventilated area.
6. Individuals should be trained in the proper use of this sprayer,
chemical handling procedures, and first aid/emergency care.
Where training is not available, individuals should study and
follow the procedures detailed in this menual.
• All servicing personnel should be trained and familiarized with
chemical handling procedures, first aid/emergency care, and
chemical liquid disposal regulations.
• DO NOT USE ANy ACID (INCLUDINg CITRUS) OR CAUSTIC
ChEMICALS INCLUDINg bLEACh.
• Remember that a sprayer with liquid is a significant amount of
weight (8 lbs. per gallon). Use caution when bending, leaning or
walking. Do not bend at the waist when wearing the backpack.
Bend only at the knees and support yourself as required to
ensure personal safety.
• Keep in mind that the sprayer tank is vented at the cap and was
intended to be operated upright.
• Do not climb or mount any equipment from which you might fall.
1
2
5
3
4
2
2
