Design: Werner Aisslinger
Montageanleitung
Assembly instruction
just cube bold
Unpacking modules and modules with standard legs
Modules with plinth profiles
Modules with round legs
Modules on base frames with diagonal legs
Modules on base frames
Hanging modules
Stacking modules
Background lighting and user manual
Reinforcing bars of top shelf
Adjustment of wall standing modules, wall fixation as anti topple protection
Adjustment of room divider modules, weight plates and faceplate
Shelves, hinged doors, drawers and flaps
Shoe rack
Rotary column for TV, cable channels, cable covers and CD arrangement
Cover panel
Seite / page
1-2
3-5
6-7
8-10
11-17
18-20
21
22-25
26
27-28
29-30
31-35
36
37-41
42
