- Page 1 PA1212 - PoE splitter User Guide Issue 1.1...
- Page 2 Table of Contents Introduction ................3 Installation ................3 Installation Note:..............3 Connections ................3 Connector Pin Configuration ............4 Con3 – DC Jack ..............4 Con1 and 2 ................4 Indication LED ................4 Technical Specifications .............. 5 Trouble Shooting ............... 6 Page 2 of 6...
- Page 3 Once installed there is no periodical maintenance required. Installation 1. Mount the PA1212 splitter unit close to the Powered Device (PD) which is the equipment to be powered using PoE. 2. Connect the PD to the PA1212 using a standard Cat5 Ethernet patch lead.
- Page 4 Connector Pin Configuration Con3 – DC Jack Con1 and 2 These are standard cat5 Ethernet connections which have the data pins on 1,2 and 3,6. Con1 accepts PoE power on pins 5,4 and 7,8 or 1,2 and 3,6. Indication LED LED Light Output Power on LED Off...
- Page 5 April 2009 Technical Specifications Connectors: 2 x RJ-45 and DC Jack (5.5 (OD) x 2.5(ID) mm) Ethernet Supported: 10/100-Base-T IEEE 802.3af Input Voltage: 36 to 57 Vdc Output power: 12W max Output current: 1A @ 12V Ripple: Typical 100mVp-p Dimensions: 22 X 52 X 85 mm Weight: 62 gr Operating Temperature: -30 to +80°C...
- Page 6 Trouble Shooting LED not ON – Check cabling between the Splitter and PoE source (Mid or End Span). Also check PoE source is turned on. LED goes out when connecting the PD – Check power cabling to PD and the power requirements of PD.
